ONE WORLD ONE TEAM ALL GASES LPG, LNG, CNG, INDUSTRIAL MANAGEMENT ENERGY SAFETY COMPETENCE E-v2 2019-2020 © Flüssiggas Anlagen GmbH (FAS) 2019 © FAS-Modern Industrial Solutions 2019 © v-1 CONTENTS LPG A Compressors 4 B Pumps 16 C Dispensers LPG • Refueling stations LPG 25 D Measurement LPG 40 E Vaporizers LPG 57 F Road tanker equipment 68 G Shut off valves • Bypass valves • Change-over valves • Solenoid valves • Ball valves • Quick acting ball valves 78 H Pressure regulators • Safety shut off valves 92 I Safety valves 100 J Excess flow valves • Back check valves (non return valves) 103 K Filling valves • Quick-acting filling valves • Unloading adaptor • Safety breakaway couplings • Fittings 108 L Strainers • Traps • Fine filters • Methanol Dewatering equipment 117 M Fittings for refilling facilities • Swivel joints • Loading arm stations 122 N Electrical components • Gas alarms systems 129 O Connections parts 131 INDUSTRIAL A Compressors 134 B Pumps 139 C Measurement 147 D Road tanker equipment 148 LNG-CRYO A Refueling stations LNG, L-CNG 150 B Regasification units 152 C Dispensers 154 D Tanks 155 E Road tanker equipment 156 F CRYO equipment 158 Important Notes ENERGY • SAFETY • COMPETENCE LPG 2019-2020 2 . • .The appearance and the disposition of elements and components may be different from the illustrations. The manufacturer retains the right to execute some technical changes without any prior advertising without any influence on the quality of the products. CAUTION! Hydrocarbon gas es and refinery products are flammable products! Danger of freezing! Installation and servicing have to be carried out by qualified personnel only . Professionals have to be trained and qualified especially to work with the equipment for flammable gases and liquids. The operation with liquefied gas installations is only permitted, if every safety rule and regulation is strictly observed and considered . Please read and follow all instructions, guidelines and rules as per description in the accompanying documents. The guarantee obligations will be invalid in case of contempt against rules and instructions . The manufacturer resumes no liability for damages which were a result of the improper use of the installations. DISCLAIMER • The information of this catalogue are compiled with utmost care and according to current knowledge . However company FAS resumes no warranty for accuracy, completeness and actuality o f the contents. All written texts and stated dimensions in this catalogue are non-binding. The graphics and illustrations are exemplary. Construction and design changes are expected. With over 40 years of experience, our international team provides an independent and safe energy supply to consumers worldwide. Our team of highly qualified engineers develop environmentally friendly and cost-effective solutions for the Petrochemical and LPG, LNG and CNG industries (gas filling stations, industry facilities, municipal utilities). Flüssiggas-Anlagen GmbH (FAS), established in 1975, specializes in the development and production of technological equipment for the oil and gas industry. Flüssiggas Anlagen GmbH In recent years, FAS and FAS-Modern Industrial Solutions have formed a solid technologi- cal foundation allowing our customers to achieve roughly any objective in the oil and gas industry. Effective cooperation with a number of leading manufacturers in Europe and the United States, complemented by cooperation with regional engineering centers, allows to imple- ment the full range of tasks at the highest engineering level. Today the company has one of the largest stock of gas- and petrochemical equipment in Eu- rope. This catalogue reflects only a small part of the complete production and supply program and has the following sections: • equipment for Liquefied Petroleum Gas (LPG, propane-butane) • equipment for the industrial gases and petrochemical industries • equipment for Liquefied Natural Gas (LNG) and CRYO generally LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .3 A Compressors ENERGY • SAFETY • COMPETENCE LPG 2019-2020 4 . • .Dry run piston compressor • vertical execution • oil-free dry run piston compressor • V-belt drive • air cooler • suction and pressure gauge Order No. Type Corken Max. capacity (m3 /h) 21 050 91 13 21 054 291 27 21 055 491 60 21 056 691 102 21 0595 891 200 Order No. Type Blackmer Max. capacity (m3 /h) 21 104 161 26 21 105 361 58 21 106 601 100 21 097 942 200 Single stage compressors (gas compression proportion less than 5:1) are normally used to transfer propane/butane from rail tankers and tank ships. Two staged compressors are used for a gas compression proportion greater than 5:1. Compressors with water coolers are used for great differential pressures and high temperatures. Compressor Liquid phase pump Rail tanker Pipe line gas phase Pipe line gas phase Storage tank Unloading of liquid gas Compressor Pipe line gas phase Liquid phase valve (closed by gas withdrawal) Pipe line gas phase Storage tank Storage tank Vapor withdrawal ENTFLAMMBAR ENTFLAMMBAR A LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .5 *Attention! Quantity of item 2.1 is depending on the quantity of items 1.3-1.6. Each devise needs 1 pc. of item 2.1. **HG compressors are equipped with one strainer only. Compressor unit Type FAS № Compressor unit Type FAS 91 291 491 691 891 HG Capacity, m³/h 14 28 61,2 103,3 200 375 1 Compressor unit consisting of: compressor, base plate, gas trap, electrical motor, V-belt drive, safety relief valve 210141 210930 210952 210640 218201 46300 1.1 Four-way ball valve, strainer incl. Pipe line DN 50 PN 40 210142 210932 210953 210641 218202 14018* 1.2 Buffer tank – – – – 939854 – 1.3 Min. oil pressure switch – 1 pc. per compressor unit 184621 – EU / 18462 – CIS 1.4 Max. pressure switch, (pressure side) – 1 pc. per compressor unit 184563 – EU / 18456 – CIS 1.5 Min. pressure switch (suction side) – 1 pc. per compressor unit 184573 – EU / 18457 – CIS 1.6 Level sensor, Type VEGA SWING 61 – 1 Stk. per compressor unit 26130 1.7 Resistance thermometer PT 100 – 1 Stk. per compressor unit 26312 1.8 Welding thermometer well for РТ 100 – 1 Stk. per compressor unit 26316 1.9 Bracketry for mounting of pressure switches – 1 Stk. per compressor unit 21195 2 Electrical control box for installation inside the building and outside of protection zone 26932 463206 2.1 Isolating switch amplifier, type of protection – EEx ia II C – 4 pcs.* per compressor unit 26301 2.2 Measuring transmitter PMT 50 Ex for PT 100 – 1 pc. per compressor unit 263140 3 Flexible hose PN 40, stainless steel, L=1000 mm on both sides lapped flanges – 2 pcs. per compressor unit – 21175 21191 21192 21193 82739 A 100 583 437 45 16 5 7 8 119 600 500 1740 290 ca.169 448 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 6 . • .FAS 46 300 horizontal compressor unit Type FAS-Corken HG601BB • medium – LPG • cylinder number/stage number – 2/1 • capacity – up 375 Nm3 /h • min. inlet pressure – 0,5 bar • speed – 1100 U/min • with pressure monitoring system (gas/oil), liquid gas trap, strainer, four-way ball valve, safety relief valve (adjustable), V-belt drive with protection plate • 3-phase motor with a capacity of: 58 kW, EEx IICT3, 400/690 V, 50 Hz A DN80 689 100 1081 1475 132 2053 437 57 105 1165 583 DN80 80/50 462 288 610 695 804 539 669 120 200 370 1000 12 448 M30 80/50 80/50 DN80 610 491 600 864 900 1165 821 1000 1800 388 1007 2000 2000 534 534 18 12 4 17 19 3 1 2 4 14 6 13 11 15 9 10 19 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .7 Dimensional drawing for FAS 46 300 horizontal compressor unit Type FAS-Corken 601 A ENERGY • SAFETY • COMPETENCE LPG 2019-2020 8 . • .Mobile compressor unit • for use in Ex zone • dry running piston compressor unit with three phase motor 400/690 V in EX-execution • with pressure monitoring and safety fittings • Ex-control unit for three phase motor with 30 m connection cable • 2 LPG hoses a’ 12 m with shut-off valves • mounted on a light ground plate, grounded and painted, mounted on a hand cart (up to 60 km/h) Additional equipment for liquid phase: high pressure hoses, sight flow indicator, strainer, valves. Can be designed on a base frame for the mounting in a car. Compressor Type 161 161 361 361 601 291 491 691 Order No. FAS 21221 21093 21223 21223/21095 21226/21064 Connection Compressor (NPT IG) ¾” ¾” 1¼” 1¼” 1½” Unit (flange DN) 20 25 32 32 40 Cylinder number 2 2 2 2 2 Piston stroke, mm 63 63 76 76 102 Max. capacity, m3 /h 26 26 58 58 100 Min. inlet pressure, bar 0,21 0,21 0,21 0,21 0,21 Max. outlet pressure, bar 24,1 24,1 20,7 22,4 24,1 Speed, U/min-1 790 790 790 790 770 Max. approved consuption of electricity, kW 8,0 8,0 15,0 15,0 30,0 Motor capacity, kW 5,0 5,0 10,0 10,0 17,5 Weight of compressor, kg 104 104 153 153 322 Weight of complete compressor unit, kg 140 265 214 400 630 A Основные компоненты: 1. Тележка буксируемая 2-осная тип Humbaur HB2326 Компрессорный агрегат Corken 291 с дизелем HATZ 1D81Z (10,5 кВт) 2. 3. Шланговые барабаны 4. Кожух 885 1960 1890 1 2 3 3080 1550 2030 4 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .9 Mobile compressor unit • for use in Ex zone • dry running piston compressor unit with Diesel motor Hatz 1D81Z for Ex-protection area • with pressure monitoring and safety fittings • 2 LPG hoses l=12 m • mounted on a light base construction, primed and painted, mounted on a trailer (up to 60 km/h) Additional equipment for liquid phase: high pressure hoses, sight flow indicator, strainer, valves. Can be designed on a base frame for the mounting in a truck. Order No. FAS 933930 Compressor Type 291 Connection Compressor (NPT IG) ¾” Unit (flange DN) 25 Cylinder number 2 Piston stroke, mm 63 Max. capacity, m3 /h 26 Min. inlet pressure, bar 0,21 Max. outlet pressure, bar 24,1 Speed, U/min-1 790 Max. approved consumption of electricity, kW 8,0 Motor Type Hatz 1D81Z Cylinder number and capacity, l 1/0,67 Compression grade 20.5 Max. motor capacity (3000 U/min-1), kW 10,3 Fuel consumption (2000 U/min-1), g/kW•h 240 Dimensional drawing of mobile compressor unit with diesel motor drive A ENERGY • SAFETY • COMPETENCE LPG 2019-2020 10 . • .9 8 7 6 A Б В FAS-942 FAS-942 FAS-942 FAS-942 2600 222700 2700 2700 2700 200 150 2280 150 2280 950 1200 1400 1200 1500 1200 1200 100 1500 1550 2600 650 750 650 750 850 550 750 650 1900 1900 1900 2700 2700 1520 1900 1420 1213 1068 1762 419 8000 1016 1213 197 197 240 750 210 240 750 210 790 790 160 790 790 160 240 750 210 160 790 790 160 160 160 160 790 790 160 240 750 210 1782 2700 Complete pump-compressor station for transferring of propane / butane from tankers, rail tanks and road tankers. “Ready to use” design including all necessary pipe lines, process and safety equipment. Available with all types and numbers of pumps and compressors. Inlet/Outlet Pump group Inlet: DN 150 Outlet DN 80 Bypass line DN 65 Compressor group Inlet: DN 80 Outlet DN 100 A Example versions: • FAS 93 374 – 3 compressor units 200 m3 /h each, 2 pump units 40 m3 /h and 18 m3 /h • FAS 93 3740 – 4 compressor units 200 m3 /h each, 2 pump units 40 m3 /h each • FAS 93 3748 – 4 compressor units 200 m3 /h each, 4 pump units 40 m3 /h each (see drawing below) • FAS 93 3733 – 2 compressor units 100 m3 /h each, 3 pump units 18 m3 /h each • FAS 93 3740 – 4 compressor units 100 m3 /h each, 4 pump units 40 m3 /h each Other versions are available on request. LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .11 2 1 3 5 4 FAS NZ 40-18-5 FAS NZ 40-18-5 FAS NZ 40-18-5 FAS NZ 40-18-5 000 2700 2700 2700 2700 2002230 4860 3250 1750 600 560 1750 600 1750 1750 600 600 2500 2000 2000 1100 900 1160 1160 1000 1100 1000 1100 1760 1100 1000 1100 2695 2750 1400 1400 850 1000 850 1400 1400 945 605 6410 695 355 197 197 1760 A ENERGY • SAFETY • COMPETENCE LPG 2019-2020 12 . • .Accessories, additional equipment and safety devices for piston compressors Mechanical liquid trap type FAS • made from steel • with ball valve 3 /8” NPT made from steel for condensate drainage • available connection for installation of an electrical filling-level sensor Order No. Type compressor Connection Execution Content, l Weight, kg 21 130 161/162 DN 20 TKW 5,8 18,4 21 131 161/162 DN 25 for stationary systems 5,8 18,7 21 132 361/362 DN 32 5,8 19,1 21 133 601/602 DN 40 7,8 21,3 21 134 942 DN 50 30,0 49,4 26 130 Filling-level sensor type VEGASWING, probe – stainless steel L=69 mm, case: synthetic, operating temperature range 40…150°C, operating pressure – up to 64 bar 26 301 Switch amplifier for stationary systems, 1 channel intrinsically safe circuit (EEx i) IIC with relay outlet, 1 changeover contact, supply voltage: 230 V, 45…65 Hz, NAMUR 21 137 Shut-off device, pneumatic, PN25 (for trucks), connection 2” NPT AG, control pressure 1,4 – 4,1 bar Mechanic liquid trap Type FAS • made from steel Order No. Type Compressor Connection Content, l Weight, kg 21 171 Blackmer 161/162/361/362 1¼” 9,7 14,4 21 170 Corken 290/291/D291/490/491/D491 9,7 14,4 21 172 Blackmer 601/602 13,0 16,3 Safety relief valve PN 40 for stationary systems • angled form • soft seal • free of non-ferrous metal • set at 19 bar Order No. Inlet, “ Outlet, “ Weight, kg 21 145 G¾ AG G½ IG 2,3 A LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .13 Pneumatic actuator for 4-way ball valve • without spring reset • operating angle 90° • designed to handle a pilot pressure of 5-8 bar • complete with mounting bracket and screws Order No. Execution 21 180 with NPT female thread (order No. 21140-21143) 21 020 with DIN flanges DN 20-32 (order No. 21147-21149) 21 181 with DIN flanges DN 40-50 (Order No. 21150 and 21144) 21 200 Limit switch in housing, Ex-proof, for position feedbacks, without display 19 748 5/2-way solenoid valve, Ex-proof, with NAMUR connection, for compressed air max. 10 bar, thread connection G¼”, operating voltage 230 V-AC, 50 Hz 19 749 5/2-way solenoid valve, Ex-proof, with NAMUR connection, for compressed air max. 10 bar, thread connection G¼”, operating voltage 24 V-DC 4-way ball valve PN 40 • from forged steel • acc. to AD A4 requirements • seals from PTFE/Viton Executions: A – with manual lever B – with pneumatic actuator without spring reset, operating angle 90°, designed to handle a pilot pressure of 5-8 bar Order No. Execution Weight, kg Connection Type Compressor 21 140 А 5,1 ¾” NPT 161/162 21 141 А 7,3 1” NPT 161/162 21 142 А 7,3 1¼” NPT 361/362 21 143 А 7,4 1½” NPT 601/602 21 240 B 16,3 ¾” NPT 161/162 21 241 B 18,5 1” NPT 161/162 21 242 B 18,5 1¼” NPT 361/362 21 243 B 18,6 1½” NPT 601/602 21 147 A 5,7 DN 20 161/162 Order No. Execution Weight, kg Connection Type Compressor 21 148 A 7,1 DN 25 161/162 21 149 A 12,5 DN 32 361/362 21 150 A 14,2 DN 40 601/602 21 144 A 16,1 DN 50 942 21 247 B 16,9 DN 20 161/162 21 248 B 18,3 DN 25 161/162 21 249 B 23,7 DN 32 361/362 21 250 B 25,4 DN 40 601/602 21 244 B 27,3 DN 50 942 with NPT-thread with NPT-thread with DIN-flanges with DIN-flanges A ENERGY • SAFETY • COMPETENCE LPG 2019-2020 14 . • .Temperature monitoring at the compressor outlet Order No. Description 26 130 Filling-level sensor, process connection – 1“NPT, PN25, output – 2-wire NAMUR-signal, designed for use in Ex zone 26 301 Switch amplifier 1 channel intrinsically safe circuit (EEx i) IIC with relay outlet, 1 changeover contact, supply voltage: 230 V, 45…65 Hz, for installation in an electrical switch box, NAMUR, type of protection (EEx i) II C 26 312 Resistance thermometer PT 100, M18×1,5 AG connection, stainless steel probe Ø 6 mm, length 100 mm, 3-wire-connection, for temperature monitoring of compressed gas 26 3140 Measuring amplifier PMT 50 Ex, intrinsically safe inlet (Ex ia) for resistance thermometer PT 100, with relay outlet for 2 limits 110°C/130°C, with temperature indication, with voltage and current outlet for additional level indicator. Operating voltage: 230 V AC. 26 316 Welding Thermometer well for temperature sensor acc. to DIN 43769. Form D1, material C 22.8 Art. 26 312 Order No. Nominal diameter, DN Length, mm Weight, kg 21 175 25 1000 4,0 21 191 32 5,0 21 192 40 6,3 21 193 50 7,6 82 739 80 14,5 Flexible hose PN40 • from stainless steel • on both sides lapped flanges acc. to DIN2656 from C-steel • welded execution • with single stainless steel covering • for flexible connection of compressors to the pipeline A LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .15 Pressure monitoring for compressor suction and pressure line Order No. Description High pressure switch (pressure side), setting range 4-25 bar, set at 15 bar EU 18 4561 non EU 18 456 Pressure switch with Ex I – equipment, for intrinsically safe circuits, break contact with resistance combination for break of circuit and short circuit monitoring, single pole changing over, gilt contacts, differential gap 1,0 bar, only for suitable switch amplifiers (FAS 26301 against more cost). Low pressure switch (suction side), setting range 0,5-6,0 bar, set at 0,8 bar EU 18 4573 non EU 18 457 Pressure switch with Ex i – equipment, for intrinsically safe circuits, break contact with resistance combination for break of circuit and short circuit monitoring, single pole changing over, pressure side connection – nipple G½”-AG, gilt contacts, differential gap 0,25 bar, only for suitable switch amplifiers (26301 against more cost). Pressure switch oil-pressure control, setting range 0,5-6,0 bar, set at 1 bar EU 18 4621 non EU 18 462 Pressure switch with EX I – equipment, for intrinsically safe circuits, break contact with resistance combination for break of circuit and short circuit monitoring, single pole changing over, gilt contacts, differential gap 0,2 bar, only for suitable switch amplifiers (FAS 26301 against more cost). Accessories for pressure switches 21 195 Bracketry for securing pressure switch to steel base plate including pulse conductors and assembly A B Pumps ENERGY • SAFETY • COMPETENCE LPG 2019-2020 16 . • .LPG-Pumps (for LPG filling stations, trucks and stationary facilities) • housing from ductile cast iron ASTM A536 • mechanical seal • with free shaft end Executions: • A – with NPT thread flanges • B – with flanges acc. to DIN 2635 • C – with ANSI-flanges for internal valve Order No. Execution Pump Type Capacity, l/min (capacity data at 5 bar differential pressure) Max. differential pressure, bar Weight, kg Corken-Pumps EU 21 608 B FD150 180 13,5 28,0 non EU 21 7088 21 296 A Z2000 309 8,6 39,0 21 297 C Z3200 424 8,6 71,0 21 788 C Z4200 1390 8,6 96,0 21 718 C Z4500 1390 8,6 92,0 Blackmer-Pumps 21 301 A LGB 1” C 20 8,6 9,0 21 302 A LGB 1” PC 35 8,6 9,0 21 303 A LGL 1¼” 50 10,5 14,0 21 304 A LGL 1½” 90 10,5 14,0 21 305 A LGL 2” E 220 10,5 40,0 21 306 A LGL 3” E 490 10,5 74,0 21 337 B LGL 4” 950 10,5 99,0 B Inlet DN 40 PN 40 DIN 2635 Outlet DN 25 PN 40 DIN 2635 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .17 Pump unit type FAS-Corken FD-150 • housing from ductile cast iron ASTM A536 • flow rate – up to 180 l/min • max. differential pressure – 13,5 bar • speed – up to 3000 U/min • inlet – flange DN 40 (PN 40, DIN 2635) • outlet – flange DN 25 (PN 40, DIN 2635) • dimensions – 800×385×260 mm • mechanical seal • coupling • Ex-Motor 400/690 V/50 Hz AC, E Ex II T3 • coupling protection • mounted on a base plate, primed and painted Order No. Motor capacity, kW EU 91 434 4,6 EU 91 501 5,5 non EU 91 5025 5,5 Dimensional drawing of the pump unit FAS-Corken FD-150 B ENERGY • SAFETY • COMPETENCE LPG 2019-2020 18 . • .Order No. Pump Type Motor, kW Capacity, l/min Speed, RPM Weight, kg 21 225 FAS-Corken Z 2000 5,0 190 (power rating at 7 bar differential pressure) 560 120 21 3160 FAS-Corken Z 3500 10,0 480 (power rating at 7 bar differential pressure) 560 243 21 808 FAS-Corken Z 4500 15,0 950 (power rating at 5 bar differential pressure) 560 413 The pump units can be equipped with other motors of different capacities or speed as well in various types of protection (for example flameproof / Ex d) 21 311* FAS-Blackmer LGL 1“E 1,0 18 1500 32,0 21 312* FAS-Blackmer LGL 1“PE 1,0 34 1500 32,0 21 313 FAS-Blackmer LGL 1,25“E 2,0 60 1500 56,0 21 314 FAS-Blackmer LGL 1,5“E 2,0 94 1500 61,0 21 354** FAS-Blackmer LGL 1,5“E 3,6 94 1500 64,0 21 315 FAS-Blackmer LGL 2“E 5,0 220 560 130,0 21 316 FAS-Blackmer LGL 3“E 10,0 400 580 230,0 21 317 FAS-Blackmer LGL 4“E 15,0 800 580 420,0 Pump unit FAS-Corken or FAS-Blackmer • for positive suction head • pump case of ductile iron ASTM A536 • with single-acting mechanical seal • complete unit mounted on a common base plate from steel • ready for connection, primed and painted • with Ex-spur-gear-motor 400/690 V, 50 Hz, including coupling and coupling protection * These pumps are equipped with an internal by pass valve (for interrupted cut operation) with connection to the return line in the tank, during continuous rating an external by pass valve must be used additionally ** This pump unit with a higher motor capacity can reach a max. differential pressure of approx. 10 bar at smaller delivery rate B LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .19 Pump unit Type FAS-Corken • for positive suction head • pump case of ductile iron ASTM A536 • with single-acting mechanical seal • complete unit mounted on a common base plate from steel • ready for connection, primed and painted • With Ex-V-belt-motor 400/690 V, 50 Hz, speed – 610 RPM, class of protection – Ex II 2 G Ex e II T3 Gb, including V-belt drive and V-belt pulley Pump unit with hydraulic motor • for positive suction head • pump case of ductile iron ASTM A536 • with single-acting mechanical seal • complete unit consisting of pump hydraulic adaptor, coupling and hydraulic motor • ready for connection mounted, primed and painted Order No. Pump Type Motor, kW Capacity, l/min Speed, RPM Weight, kg 21 2251 FAS-Corken Z 2000 5,5 270 610 143,0 21 8089 FAS-Corken Z 3500 11,0 490 610 266,0 21 8088 FAS-Corken Z 4500 15,0 950 610 332,0 Order No. Pump Type Motor, kW Capacity, l/min Speed, RPM Oil recirculated quantity, l/min Oil pressure, bar Pump with NPT-threaded flanges, right-handed, execution A (Corken/Danfoss) 21 5720 FAS-Corken Z 2000/OM 80 5,5 220 640 58,0 100 21 299 FAS-Corken Z 3200/OM 100 10,0 450 550 29,0 232 21 2993 FAS-Corken Z 3200/OM 80 8,0 400 750 52,0 110 21 2995 FAS-Corken Z 3500/OM 100 10,0 450 550 60,0 140 Pump units left-handed on your request. Power rating at 5 bar differential pressure. Inlet flange 3” ANSI 300 lbs Pump with welding ends, right-handed, execution A (Blackmere/Danfoss) 21 572 FAS-Blackmer LGL 2”E/OM 80 5,0 220 650 58,0 100 21 573 FAS-Blackmer LGL 3“F/OM 100 10,0 380 550 29,0 232 21 574 FAS-Blackmer LGL 3“F/OM 100 10,0 380 550 60,0 140 21 576 FAS-Blackmer LGL 2”E/OM 80 5,0 220 650 58,0 100 21 577 FAS-Blackmer LGL 3“F/OM 100 10,0 380 550 29,0 232 21 578 FAS-Blackmer LGL 3“F/OM 100 10,0 380 550 60,0 140 Pump units left-handed on your request. Power rating at 5 bar differential pressure. B FAS-Corken pump unit Z 3500 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 20 . • .Complete „ready to use” pump unit for refueling of cars • side channel pump • coupling with coupling protection • Ex-motor 400/690 V/50 Hz AC, E Ex II T3 • gas bubble trap • mounted on a ground frame, grounded and painted Order No. Pump unit / motor capacity, kW Connection DIN (Inlet/Outlet) Max. differential pressure, bar Capacity, l/min (at differential pressure 10 bar) 93 3113 NZ 36-6/5 50/32 10 50 93 3112 NZ 36-8/5 50/32 14 100 Order No. Description Connection 92 156 Ball valve DIN 50 18 593 Sight flow indicator DIN 50 14 016 Strainer DIN 50 12 534 Back check valve DIN 50 18 382 Flow detector dip sensor ½“ NPT 18 381 Flow detector analysing device 230 VAC Additional equipment B 547 1230 930 1050 1763 2063 2474 411 100 100 50 10 50 U80 DIN1026 300 DN50 1/2″NPT 451 3/4″NPT 150 DN25 DIN2635 DN65 DIN2635 DN32 DIN2635 bar 40 DN32 DIN2635 Kl.1 0 10 20 30 Ø10 655 700 100 907 282 700 751 150 DN25 DIN2635 220 400 Ø20 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .21 Complete suction pump unit for the transfer of LPG from underground tanks • side channel pump • coupling with coupling protection • Ex-motor 400/690 V/50 Hz AC, E Ex II T3 • gas bubble trap • mounted on a ground frame, grounded and painted Executions: • A – with 3-phase motor 5 or 6,8 kW, with sight flow indicator • B – with 3-phase motor 5 or 6,8 kW, without sight flow indicator The complete side channel pump unit is equipped with two types of pump units: • capacity 50 l/min (for one or two dispensers); • capacity 100 l/min (for two or three dispensers), • with three phase motor 5 or 6,8 kW. The gas bubble trap facility is equipped with a mechanical liquid gas trap, by-pass valve, pressure gauge with shut-off valve, back check valve, ball valve and differential valve, strainer and pipe line. Order No. Pump unit type Connection DN (Inlet/Outlet) Max. differential pressure, bar Capacity l/min at differential pressure 10 bar Weight, kg Execution A Execution B Execution A Execution B 21 707 21 776 AP 31-8 50/32 14 50 300,0 220,0 21 708 21 777 AP 36-8 50/32 14 100 320,0 240,0 Dimensional drawing of complete suction pump unit capacity 50/100 l/min with 3-phase motors 5/6,8 kW B ENERGY • SAFETY • COMPETENCE LPG 2019-2020 22 . • .LPG side channel pump unit for above ground and underground tanks • for positive suction heads • mechanical seal • flanges in PN 25/40 with flat seal strip • Ex 3-phase motor 400/690 V/50 Hz AC, E Ex II T3 • coupling with coupling protection • mounted on a ground frame, grounded and painted Horizontal, self-priming pump unit in a link-body version with open impellers Executions: • A – side channel pump unit for above ground tanks; with mechanical seal, coupling and coupling protection • B – side channel pump unit for underground tanks; with mechanical seal, coupling and coupling protection Order No. Execution Type Max. differential pressure,bar Motor capacity, kW Connection, DN Capacity, l/min Inlet Outlet 21 720 А FAS NZ 12-5 6 1,0 40 20 10 21 783 А FAS NZ 31-6 10 3,6 65 32 50 21 781 А FAS NZ 31-7 14 3,6 65 32 50 21 784 А FAS NZ 36-6 10 5,0 65 32 100 21 729 А FAS NZ 36-8 14 5,0 65 32 100 21 807 А FAS NZ 51-6 14 13,5 100 50 200 21 787 А FAS NZ 51-8 14 15,0 100 50 300 21 795 A FAS NZ 61-8 14 24,0 100 65 500 21 785 B FAS AP 31-8 14 5,0 65 32 50 21 786 B FAS AP 36-8 14 6,8 65 32 100 B LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .23 Order No. Type Capacity, m3/h (l/min) Differential pressure,bar Motor capacity, kW Connection, DN (Inlet/Outlet) 46 001 NZ 40-6-12,5 40 (6 60) 6 12,5 80/65 46 002 NZ 40-8-15 8 15,0 46 003 NZ 40-10-20 10 20,0 125/100 46 004 NZ 60-5-15 60 (990) 5 15,0 46 005 NZ 60-7-20 7 20,0 46 006 NZ 60-10-28 10 28,0 46 007 NZ 80-6-24 80 (1320) 5 24,0 46 008 NZ 80-7-28 7 24,0 46 009 NZ 80-11-47 11 47,0 46 010 NZ 100-5-24 100 (1660) 5 24,0 46 011 NZ 100-7-28 7 28,0 46 012 NZ 100-10-47 10 47,0 125/100 46 013 NZ 150-7-36 150 (2490) 7 36,0 B Order No. Type Capacity, m3/h (l/min) Differential pressure,bar Motor capacity, kW Connection, DN (Inlet/Outlet) 46 015 NZ 150-10-58 150 (2490) 10 58,0 125/100 46 016 NZ 200-5-55 200 (3320) 5 58,0 46 017 NZ 200-7-80 7 80,0 46 018 NZ 200-10-100 10 100,0 Privileged pump group for cylinder carousels (filling of cylinders) and road tanker refueling (execution A) 46 0204 NZ 30-9-15 30 (500) 9 15 80/65 46 0203 NZ 30-9 pump only 46 0206 NZ 25-13-15 25 (400) 13 15 80/65 46 0209 NZ 25-13 pump only 46 0207 NZ 30-14-24 30 (500) 14 24 80/65 46 0208 NZ 30-14 pump only ENERGY • SAFETY • COMPETENCE LPG 2019-2020 24 . • .Complete pump unit for the transfer of LPG • side channel pump • coupling with coupling protection • Ex-motor 400/690 V/50 Hz AC, E Ex II T3 • gas bubble trap • mounted on a ground frame, grounded and painted Order No. Pump unit Inlet/Outlet/by pass line Max. differential pressure, bar Capacity l/min at differential pressure 10 bar Weight, kg 93 2487 NZ 28-10-15 DIN 80 / 65 / 40 11,3 500 860 93 3098 NZ 40-8-15 DIN 80 / 65 / 40 9,5 660 775 Dimensional drawing of complete suction pump unit 93 2487 Dimensional drawing of complete suction pump unit 93 3098 B LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .25 C Dispensers LPG • Refueling stations LPG FAS 35 4736 electronic LPG dispenser type FAS-120 Operation pressure, bar up to 25 Flow capacity, l/min min. 5 max. 50 Weight, kg 110 Dimensions, mm: Height (entire dispenser) 1500 Height (mechanical part) 1000 Width 500 Depth 400 Power supply 230 V AC, 50 Hz Counter-Display (kg)/LCD-Display 1 (inside)/1 Hydraulic PN 25 Coriolis flow meter 5-50 l/min Equipment: vapor eliminator with fine mesh filter, differential pressure valve, back check pressure valve, safety relief valves, expansion vessel, high pressure hose LPG 19 (length 5 m) with excess flow valve and breakaway coupling Connection: liquid phase / gas return line Ball valve ¾ G IG / Ball valve ¾ G IG Information data at LCD-Display “price per liter”, “filling volume liter”, “total sum” Protocols: Easy Call, DART, Pumalan, Nara Information data at internal counter-display: volume, kg, density and temperature data of LPG Additional equipment (against extra cost): solenoid valve (single- or double-acting), heating for electronic part, insulating flange set for underground pipe lines C 10 0 40 0 30 400 150 0 100 0 500 42 0 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 26 . • .Dimensional drawing of LPG-dispenser type FAS-120 C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .27 FAS 35 4737 electronic LPG dispenser type FAS-220 HM BC (one hose) FAS 35 4738 electronic LPG-dispenser type FAS-230 HM BC (two hoses) Operation pressure, bar up to 25 Flow capacity, l/min min. 5 max. 50 Weight FAS-220/FAS-230, kg 190/220 Dimensions, mm: Height (entire dispenser) 2109 Width 1200 Depth 520 Power supply 230 V AC, 50 Hz Housing execution High Mast (HM), from stainless steel Counter-Display (kg)/ LCD-Display 1 (inside)/1 (FAS-220 HM) 2 (inside)/2 (FAS-230 HM) Hydraulic PN 25 Coriolis flow meter (0…50 l/min) 1 (FAS-220 HM)/1 (FAS-220 HM) Equipment: vapor eliminator with fine mesh filter, differential pressure valve, back check pressure valve, safety relief valves, expansion vessel, high pressure hose LPG 19 (length 5 m) with excess flow valve and breakaway coupling Connection: liquid phase / gas return line Ball valve ¾” G IG / Ball valve ¾” G IG Information data at LCD-display “price per liter”, “filling volume liter”, “total sum” Information data at internal counter-display: volume, kg, density and temperature data of LPG Protocols: Easy Call, DART, Pumalan, Nara Additional equipment (against extra cost): solenoid valve (single- or double-acting), heating for electronic part, insulating flange set for underground pipe lines Dispensers FAS-230 differ from dispensers FAS-220 in their con – struction in so far that all components required for delivery of product are doubled. C ENERGY • SAFETY • COMPETENCE LPG 2019-2020 28 . • .Dimensional drawing of electronic LPG-dispenser Type FAS-220 HM/FAS-230 HM Front view Side view right/left C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .29 FAS 35 4739 combined electronic LPG dispenser type FAS-220 WM BC Operation pressure, bar up to 25 Flow capacity, l/min min. 5 max. 50 Weight, kg 270 Dimensions, mm: Height (entire dispenser) 2450 Height (mechanical part) 718 Width 500 Depth 760 Power supply 230 V AC, 50 Hz Counter-Display (kg)/LCD-Display 1 (inside)/1 (FAS-220) 2 (inside)/2 (FAS-230) Hydraulic PN 25 Equipment: vapor eliminator with fine mesh filter, differential pressure valve, back check pressure valve, safety relief valves, expansion vessel, high pressure hose LPG 19 (length 5 m) with excess flow valve and breakaway coupling Connection: liquid phase / gas return line Ball valve ¾” G IG / Ball valve ¾” G IG Information data at LCD-Display “price per liter”, “filling volume liter”, “total sum”, “tare”, “filling weight, kg”, “total weight, kg” Protocols: Easy Call, DART, Pumalan, Nara Information data at internal counter-display: volume, kg, density and temperature data of LPG Additional equipment (against extra cost): solenoid valve (single- or double-acting), heating for electronic part, insulating flange set for underground pipe lines With filling device for filling of 27- and 50-liter gas cylinders and a filling unit for filling of cars. C Сторона обслуживания Вид справа/слева 1005 528 678 780 1100 1260 1376 1439 1805 1200 520 440 400 130 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 30 . • .Dimensional drawing of electronic LPG-dispenser type FAS-220 WM with filling device Front view Side view right/left C FAS 93 6931 electronic LPG dispenser type FAS ZS-120 (Economy line) FAS 93 6938 Electronic LPG dispenser type FAS ZS-230 (Economy line) displays + hoses at the front FAS 93 6936 Electronic LPG dispenser type FAS ZS-230 (Economy line) displays + hoses oppositely Operation pressure, bar up to 25 Flow capacity, l/min min. 5 max. 50 Weight, kg 90 Dimensions, mm: Height (entire dispenser) 1500 Height (mechanical part) 1000 Width 500 Depth 400 Power supply 230 V AC, 50 Hz Operation pressure, bar up to 25 Flow capacity, l/min min. 5 max. 50 Weight, kg 148 Dimensions, mm: Height (entire dispenser) 1500 Height (mechanical part) 1000 Width 850 Depth 400 Power supply 230 V AC, 50 Hz Counter-Display (kg)/ LCD-Display 1 (inside)/1 Hydraulic PN 25 Coriolis flow meter 5-50 l/min Equipment: vapor eliminator with fine mesh filter, differential pressure valve, back check pressure valve, safety relief valves, expansion vessel, high pressure hose LPG 19 (length 5 m) with excess flow valve and breakaway coupling Connection: liquid phase / gas return line Ball valve 1” female NPT/ Ball valve ¾” female NPT Information data at LCD-Display: “price per liter”, “filling volume liter”, “total sum” Information data at internal counter-display: volume, kg, density and temperature data of LPG Additional equipment (against extra cost): solenoid valve (single- or double-acting), heating for electronic part, insulating flange set for underground pipe lines Counter-Display (kg)/LCD-Display 2 (inside)/2 Hydraulic PN 25 Coriolis flow meter 5-50 l/min Equipment: vapor eliminator with fine mesh filter, differential pressure valve, back check pressure valve, safety relief valves, expansion vessel, high pressure hose LPG 19 (length 5 m) with excess flow valve and breakaway coupling Connection: liquid phase / gas return line Ball valve 1” female NPT/ Ball valve ¾” female NPT Information data at LCD-Display: “price per liter”, “filling volume liter”, “total sum” Information data at internal counter-display: volume, kg, density and temperature data of LPG Additional equipment (against extra cost): solenoid valve (singleor double-acting), heating for electronic part, insulating flange set for underground pipe lines LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .31 C ENERGY • SAFETY • COMPETENCE LPG 2019-2020 32 . • .FAS 93 583 Service kit in a tool bag for service technicians Conversion kit for modification of a LPG-dispenser type FAS of early versions Service kit in a tool bag with calibrated flow turbine and set of adaptors for connection to internal filling valve. For control measuring of LPG Dispenser Type FAS-120/220/230 after. Consists of: • Tool bag • Measuring turbine, max. flow capacity 50 l/min, with 1¾” ACME connections • 1×FAS 22344 rotary switch attachment • 1×Adapter FAS 13532, T3 / W 21,8×1 /14” male • 1×Adapter FAS 13518, 1¾” ACME coupling / Bajonett • 1×Adapter FAS 13509, 1¾” ACME coupling / T3 • 1×Adapter FAS 10065, 1¾” ACME male / W 21,8×1 /14” male • Protective glove The conversion kit makes it possible to modify quickly an early version of LPG-dispenser with piston meter. Consisting of: • 2 pcs. of Coriolis mass meter, cable, LCD-display and 2 pcs. differential pressure valves • Installation material • Manual Order No. Description 93 602 Conversion kit for modification of dispenser FAS-230 with one 4-piston meter, year of manufacture from 2007 93 6020 Conversion kit for modification of dispenser FAS-230 with one 2 or 4-piston meter, year of manufacture before 2004 93 6021 Conversion kit for modification of dispenser FAS-120 with one 2-piston meter 93 6026 Conversion kit for modification of dispensers FAS-120/220 with one piston meter in a dispenser with a mass meter 93 6030 Conversion kit for modification of dispenser FAS-230 with two-piston meter in a dispenser with a mass meter C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .33 REMARK: execution and installation versions will be processed accordingly to county-specific regulations and standards as well as to specific customer requirements and can be combined in modular construction system as necessary. Complete LPG filling unit type FAS with above-ground tanks LPG filling station of filling of cars with LPG • above ground storage tanks, mounted on a steel base frame, with LPG-Dispenser, pump unit for the removal of liquid phase from the tank, incl. all the necessary safety- and shut-off fittings, strainer, bypass valve and all necessary pipe lines • the construction on a common frame reduces the installation and remanufacturing costs, speeds mounting and commissioning, retaining system stability. Main components: • 1-3 above ground storage tanks for LPG (4,85/6,7/9,0 m3 ) • 1-3 pump units type FAS-NZ with flow rate of 50 up to 130l/min • 1-4 LPG-dispenser type FAS, with one or two filling nozzles, capacity – up to 50 l/min • complete measuring, shut-off and safety fittings • optional: an additional pump unit for filling and emptying of storage tanks, capacity 220 l/min C 10385 D FAS- NZ36-8 F E 1460 DN50 210 220 2300 32/25 120 55 360 65/50 100 100 100 B Ø22mm 2195 DN20 DN50 DN25 3500 A C A C 2250 1000 3600 2290 C A DN500 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 34 . • .Dimensional drawing of complete LPG filling station with two over-ground storage tanks and LPG-dispenser type FAS-220 C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .35 C Consisting of: • FD-150 pump unit with mechanical seal, capacity up to 100 l/min, Ex-motor 4,6 kW, 400/690 V, 50 Hz • supply line with ball valve DN 32 and fine filter DN 32 • discharge line with ball valve DN 25 with mounting flange • bypass line with bypass valve and ball valve with mounting flange • all necessary additional equipment for safety operation • connections for road tanker All equipment is painted. Mounted on a common galvanized frame. The frame is prepared for mounting of all types of FAS dispensers. Consisting of: • side channel pump unit with mechanical seal, capacity of 100 l/min, Ex-motor 5 kW, 400/690 V, 50 Hz, • supply line with a ball valve DN 32 and with a fine filter DN 32 • discharge line with a ball valve DN 25 with mounting flange • bypass line with bypass valve and ball valve with mounting flange • all necessary additional equipment for safety operation • connections for road tanker All equipment is painted. Mounted on a common galvanized frame. The frame is prepared for mounting of all types of FAS dispensers. FAS 93 3093 complete FAS “ready to use” pump units for LPG car refueling station, prepared for installation of LPG dispenser and 1, 2 or 3 pcs of LPG tanks FAS 93 3092 complete FAS “ready to use” pump units for LPG car refueling station, prepared for installation of LPG dispenser and 1, 2 or 3 pcs of LPG tanks “Ready to use unit” with FD-150, prepared for connections with two LPG tanks “Ready to use unit” shown incl. dispenser FAS-120 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 36 . • .Complete LPG-filling station type FAS with underground storage tanks of 4 850 up to 20 000 l LPG-Filling Station for filling of cars with LPG: • Underground storage tanks • Common steel base frame, with LPG-Dispenser, pump unit for the removal of liquid phase from the tank, incl. all the necessary safetyand shut-off fittings, strainer, by-pass valve and all necessary pipe lines • The construction on a common frame reduces the installation and remanufacturing costs, speeds mounting and commissioning, retaining system stability. Main components: • 1-3 underground storage tanks for LPG (4,85/6,7/9,0/20,0 m3 ) • Complete self-priming pump facility with pump unit type FAS-AP, capacity 50/100 l/min • By-pass line • Pipe lines for filling of cars, filling and emptying of storage tanks, also by emergency emptying • Dry running protection – flow detector dip sensor • Insolating flanges for underground pipe lines • 1-4 LPG-dispenser type FAS, with one or two filling nozzles, capacity – up to 50 l/min • Complete measuring, shut-off and safety fittings REMARK: execution and installation versions will be processed accordingly to country-specific regulations and standards as well as to specific customer requirements and can be combined in modular construction system if necessary. C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .37 C 1400 2890 1600 4875 525 500 2400 657 250 300 1600 1200 57 256 76,1 650 0,00 1 2 3 4 Основные компоненты / Hauptkomponenten: 1. Резервуар СУГ FAS- 9,0 / Flüssiggaslagerbehälter…………………Чертеж/Zeichnung: РСГП.011.065.004- 3СБ 2. Насосный агрегат FD150 / Pumpenaggregat FD-150…………………………FAS 915015 3. Насосный агрегат Z2000 / Pumpenaggregat Z2000……………………………FAS 969920 4. Шкаф с заправочными рукавами / Schrank mit LPG-Füllschlauch…….FAS 93680 1000 2600 4200 1000 1900 1000 2500 1630 200 200 200 1000 2600 2890 Чертеж-№: Flüssiggas-Anlagen GmbH Peiner Straße 217 D-38229 Salzgitter Tel.: 05341 / 8697 – 0 Fax.: 05341 / 8697 – 11 E-mail.: info@fas.de Масштаб: Материал: Материал Поверхность: Вес: Допуски согласно Инд. Изменения DIN-ISO 2768 m K Согласно нормам DIN ISO 16016 (C) Пров. Имя Разраб: Дата Т.контр. Проверил Дата пров. Дата изм. Изменил Лист: Технические изменения предусмотрены Блочный технологический комплекс тип FAS Treibgasbetankungsanlage ohne Abgabeeinrichtung 2 3 4 5 6 7 8 4 A B C D E F D E C B A 1:15 Проекция: 22.11.2017 22.11.2017 GB MA 939775-2_1_0-3D 1 / 1 a b c d G H 9 10 11 F G 5 6 7 1 12 13 14 15 16 I J K 8 9 10 11 12 H I J L M N K L M N O 17 18 19 20 21 22 23 13 14 15 16 17 18 19 -DIN: ENERGY • SAFETY • COMPETENCE LPG 2019-2020 38 . • .REMARK: the execution of this compact station is possible with LPG-dispenser type FAS-220 WM Complete compact LPG-filling station type FAS with one underground storage tank Neither long construction no mounting works are required. Only a spoil for storage tank and a trench for power supply as well as data cables are needed. Pump unit is equipped with pump FD-150, flow capacity 90 l/min at differential pressure of up to 10,5 bar and electrical motor with motor capacity 4,1 kW in Ex-execution. • Capacity of filling station is up to 20 cars per hour • Completely pre-assembled and tested • Quick installation and comissioning C LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .39 Hydraulic schema of compact filling unit with underground storage tank and pump unit FD-150. LPG-dispenser – FAS-120. C ENERGY • SAFETY • COMPETENCE LPG 2019-2020 40 . • .By order must be specified: 1. Type name: Junior, Senior, large tank version 2. Tank inside diameter 3. Tank type: cylindrical or spherical 4. Mounting position: a. End mounted in tank bottom b. Side-mounted in tank shell c. Top-mounted d. Angle-mounted in tank bottom or in tank shell Floating liquid level gauge • with transfer of measured values in % of tank volume Measurement equipment • Liquid level gauges D • Control fittings • Meters • Accessories 5. For dimensional determination of gauge: for 4a) Stem length (S) for 4b)Stem length (S) for 4c) distance from center line of tank to top of mounting flange (S= stem length) for 4d) degree of angle between horizontal center line of tank and center line of liquid level gauge or vertical distance in mm from horizontal center line of tank to center of gauge; distance from center of motion of liquid level gauge to top of mounting flange (S = stem length) D LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .41 D Liquid level gauge PN 25, Type Junior • with rubber seal • protection cup • mounting screws M6×25 from stainless steel Order No. Type Junior Mounting position Tank ø, mm Shaft length, mm 18 001 6284 horizontal up 800 18 002 up 1250 ≈350 18 003 up 1600 18 006 Special execution for ammonia 18 011 6281 vertical 800 630 18 012 1000 510 18 013 1250 630 18 014 1250 755 18 015 1250 785 18 016 1250 805 18 017 up 1600 up 1200 18 019 Special execution for ammonia Order No. Type Senior Mounting position Tank ø, mm Shaft length, mm 18 021 6283 horizontal up 1600 ≈200 18 031 6280 vertical up 1500 up 825 18 032 up 2000 up 1200 Model Mounting 6339 M11 6342 M11 Side, End 45° 6339 M12 Liquid level gauge PN 25, Type Senior • with rubber seal • protection cup • mounting screws M6×25 from stainless steel M6300 series Magnetel gauges • special design for mobile applications such as truck, trailer, container Model Mounting 6342 M12 6339 M16 Side, End 45° 6342 M16 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 42 . • .Order No. Tank ø, mm Shaft length, mm Execution A 18 071 1600 610 18 072 1900 610 18 073 2000 610 18 074 2100 610 18 075 2200 610 18 076 2300 610 18 077 2400 610 18 078 2500 610 18 079 2700 610 18 080 2800 610 18 081 2900 610 Liquid level gauge large tank version for horizontal cylindrical tanks • horizontal installation • 8” dial • spiral wound gasket 1.4571/graphite to 550°C • screws M12×25 from stainless steel Executions: • A – for propane/butane, Type W709, flange PN 40, from 1.4541 • B – for propane/butane und ammonia, flange PN 25, from stainless steel • C – for propane/butane, Type W709, with spring shock absorber for road tankers, shaft length – 475 mm, side mounting, flange PN 40, from 1.4541 Order No. Tank ø, mm Shaft length, mm 18 082 3000 610 18 083 3200 610 18 084 3400 610 18 085 3500 610 18 086 3600 610 18 087 3800 610 18 088 4000 610 18 094 Additional price – alternativ tank Ø or shaft length Execution В 18 167 up 2500 610 18 168 up 3000 610 18 169 up 3600 610 Order No. Tank ø, mm Shaft length, mm 18 170 up 4000 610 Execution С 18 100 2000 without shaft (side mounting) 18 101 2100 18 102 2200 18 103 2150 18 104 2050 18 105 1900 18 106 2250 18 107 1800 18 108 1750 D LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .43 Liquid level gauge – large tank version for horizontal cylindrical tanks • vertical installation • 8” dial • spiral wound gasket 1.4571/graphite to 550°C • screws M12×25 from stainless steel Executions: • A – for propane/butane, Type S709 (max. shaft length – 2500 mm, other lengths – on your request), flange PN 40, from 1.4541 • B – for propane/butane und ammonia, flange PN 25, from stainless steel Order No. Tank ø, mm Shaft length, mm Execution A 18 140 1600 980 18 141 2000 1100 18 142 2300 1330 18 143 2500 1350 18 144 2500 1380 18 145 2500 1400 18 146 2500 1430 18 147 2500 1450 18 148 2500 1550 18 149 2500 1650 18 150 2600 1540 18 151 2600 1590 18 152 2900 1550 18 153 2900 1580 Liquid level gauge – large tank version for horizontal cylindrical tanks • type Rochester • 4” dial • spiral wound gasket 1.4571/graphite to 550°C • screws M12×25 from stainless steel Level gauges – large tank version with dial 4” for ammonia (NH) on your request Order No. Mounting position Tank ø, mm Shaft length, mm 18 330 Horizontal up 2000 610 18 331 up 2500 610 18 332 up 3000 610 18 333 Vertikal up 2000 up 1250 18 334 up 2500 up 1550 18 335 up 3000 up 1800 18094 Additional price – alternativ tank Ø or shaft length Order No. Tank ø, mm Shaft length, mm 18 154 2900 1600 18 155 2900 1650 18 156 3000 1530 18 157 3000 1635 18 158 3200 1750 18 159 3400 1850 18 160 3600 1800 18 161 4000 2085 18 094 Additional price – alternativ tank Ø or shaft length Execution В 18 172 up 2500 up 1550 18 173 up 3000 up 1800 18 174 up 3600 up 2300 18 175 up 4000 up 2300 D ENERGY • SAFETY • COMPETENCE LPG 2019-2020 44 . • .Devices for „dry running protection“ of pumps • no mechanical parts, full electronical version • for use in Ex-Zone 1 Order No. Execution Weight, kg 18 381 Flow detector analyzing device for connection to sensor, EExib II C, operating voltage 230 V/50 Hz AC, relay output: 1, for installation in electrical switch box 0,3 18 380 Flow detector analyzing device for connection to sensor, EExib II C, operating voltage 24 DC, relay output: 1, for installation in electrical switch box 0,3 18 384 Flow detector analyzing device with connection ½” NPT AG, EExib II C, Operating voltage 24 V DC, vrsion: Eurocard-size 100×160 mm 0,3 18 382 Flow detector dip sensor for use in hazardous areas, case form stainless steel A4, art of protection IP68, with 2 m connection cable, ambient temperature -20 °C up to +85 °C, max. pressure – 60 bar 0,2 18 389 Welding half coupling ½” NPT, PN 40, for dip sensor, from steel ASTM 105 0,1 Order No. Execution 26 0855 Level sensor VEGAFLEX 81 with built in displayoperation module (PLICSCOM), EX ia IIC T1..T6 X, thread G¾, material 316L 26 182 Switch amplifier type VEGAMET 381 for filling level sensors, Inlet: 1×4-20 mA, Outlet: 1×0/4-20 mA – current outlet, 2×Relay outlets, 1×device defect relay, operating voltage: 20-253 V AC, 50/60 Hz, error of indication-accuracy±20µA (0,1% from 20mA), number of relay outlets 2×operation relays, 1×device defect relay, LC display for digital and analog presentation of measured value, ambient temperature -20…60°C, protection art IP 40 26 087 VEGACONNECT 3 interface adaptor between PC and communicable VEGA devices TDR-Sensor for continuous liquid measurement of filling level and of separator • filling level sensor VEGAFLEX 81 for mounting in tank • switch amplifier type VEGAMET 381 for continuous measurement with • integrated limit switches, for installation in electrical switch box • filling level measurement of LPG in tank in the real time • control of min. and max. values of tank filling (for example 5/85%) with supply control signal for switching off of pump motor or of solenoid valve control at reaching of min. or max. filling level D LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .45 Order No. Type Dip tube, mm Weight, kg 18 024 489 250 1,5 18 025 489 310 1,5 18 026 489 463 1,5 Gas withdrawal valve with limit indicator PN 25 for LPG storage tank • case from brass • tank connection ¾” NPT-AG • gas withdrawal connection POL-IG • complete with pressure gauge, gauge and dip tube Flow indicator PN 25 • connection 2“ NPT-AG • for pipe diameter 50 up to 100 mm Order No. Length, mm Weight, kg 18 440 55 0,9 18 441 75 0,9 18 442 125 0,9 18 444 4” dial (spare part) Adaptor PN 40, for dip sensor • for installation between two flanges • material – steel H II Executions: • A – connection for sensor ½“ NPT-IG • B – connection for sensor ½” NPT-IG and additional connection ¼” NPT-IG for one safety relief valve Order No. Nominal width, DN Weight, kg Execution A Execution B 18 390 18 680 15 0,3 18 391 18 681 20 0,5 18 392 18 682 25 0,7 18 393 18 683 32 0,9 18 394 18 684 40 1,1 18 395 18 685 50 1,5 18 396 18 686 65 2,0 18 397 18 687 80 2,3 18 398 18 688 100 3,0 18 399 18 689 125 3,6 18 400 18 690 150 4,2 Sight flow indicator PN 25 • NPT- female thread • case from ductile cast iron ASTM 536 • back check valve from stainless steel • with two opposing glasses Order No. RegO Connection, ” Weight, kg 18 501 A7794 2 4,7 18 502 A7796 3 10,0 D ENERGY • SAFETY • COMPETENCE LPG 2019-2020 46 . • .Vent valve PN 40 • ¼” NPT-male thread Executions: • A – with type approval • B – with knurled screw • C – with tee handle Order No. Type Execution Warning plate Dip tube Material Picture 18 430 FAS 7155 A, B – – Brass 1 18 431 RegO 3165 C B – – 1 18 432 RegO 3165 CP + – 2 18 433 RegO 3165 CF – 300 mm 5 18 434 RegO 3165 CPF + 300 mm 4 18 438 FAS AL 1917 – – Steel 1 18 435 RegO TSS 3169 C – – Stainless steel 3 18 436 RegO TA 3169 F – 300 mm Steel 5 Pressure switch • explosion protected • EEx ed IIC T6 • connection G¼” AG • protection art IP 55 • ambient temperature -20 up to +40°C • changer protected against explosions • switching capacity – 0,5 A 230 V AC • control button is mounted inside; PTB approval Order No. Type Range, bar Difference, bar Max. testing pressure, bar Weight, kg 18 461 Ex/FF 142V-3 -0,4…8,0 0,3…3,0 25 1,2 18 460 Ex/FF 142V-10 5,0…40,0 2,0…10,0 50 1,2 1 2 3 4 5 D LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .47 D Pressure switch • Ex-i proof, protection art IP 54 • connection G½” AG • case from aluminium • max. admitted pressure – 25 bar • ambient temperature -25 up to +70°C • 1 changer • switching capacity – 5/230 V AC • Ex-proof when used in conjunction with isolating switch amplifier Oder No. 25301 (230 V) or 26303 (24 V) Pressure switch • Ex-i proof, protection art IP 54 • connection G½” AG • case from Aluminium • max. admitted pressure – 25 bar • ambient temperature -25 up to +70°C • 1 changer • switching capacity – 5/230 V AC • Ex-proof when used in conjunction with isolating switch amplifier No. 25301 (230 V) or 26303 (24 V) Order No. Type Execution Weight, kg 18 453 FD 16-326 External electrical locking system required in switch box 0,6 18 454 FD 16-327 With mechanical locking device 0,6 26 301/302 KHA6-SH-EX1 Isolation switch amplifier in safety engineering, intrinsically safe control circuit, supply voltage 230 V / 50 Hz 0,1 Maximal Pressure control switch • acc. To TRB 801/25, without Ex-proof, protection art IP 65 • connection G½” AG • case from Aluminium • max. admitted pressure – 25 bar • ambient temperature -25 up to +60°C • setting range 3-16 bar • 1 changer • Ex-proof when used in conjunction with isolating switch amplifier No. 25305 (230 V) Order No. Type Range, bar Difference, bar Weight, kg 184573-EU/18457-CIS DWR 625 0,5…6,0 0,25 0,3 184560-EU/18456-CIS DWR 25 4,0…25,0 1,00 0,3 184621-EU/18462-CIS DCM 6 0,5…6,0 0,15 0,3 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 48 . • .Sight flow indicator PN 25 • socket connection NPT-female thread • housing from steel casting GS-C 25 • with two opposite glasses Order No. Connection, ” Length, mm Weight, kg 18 503 ½ NPT 100 2,8 18 504 ¾ NPT 100 2,8 18 505 1 NPT 130 5,6 18 506 1¼ NPT 130 5,6 18 507 1½ NPT 150 6,0 18 508 2 NPT 180 9,5 Sight flow indicator PN 25 • flange connection acc. to DIN 2635 • housing from steel casting GS-C 25 with two opposite glasses from borosilicate glass acc. to DIN 7080 Order No. Connection (DN) Length, mm Weight. kg 18 588 15 150 3,5 18 589 20 150 4,5 18 590 25 160 5,5 18 591 32 180 8,0 18 592 40 200 9,0 18 593 50 230 11,0 18 517 65 290 16,0 18 518 80 310 21,0 18 519 100 350 27,0 18 509 125 400 38,0 18 510 150 480 50,0 92 662 200 400 111, D LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .49 D Rotary level gauge PN 25 • material – steel • for horizontal tanks; connection – 1“ NPT-AG • complete with dial and rotary level gauge for stationary and mobile tanks Dip tube for rotogauge • material – steel • Ø 8 mm • one side with thread • order number – 28 119 Order No. Type (RegO) Stem length, mm Stem execution Weight, kg 18 531 A9091 R 490 Standard stem 1,7 18 533 A9092 R 675 2,0 18 535 A9093 RS 915 2,3 18 536 A9093 TS 915 Reinforced stem 3,0 18 537 A9094 TS 1150 3,5 18 530 A9095 TS 1422 3,8 Spare parts for rotary level gauges Other spare parts are available on request Order No. Type Description Material 18 545 A3163-6 Screw plug with seal Steel 18 546 FAS 18 547 FAS Dial Alu 18 548 RegO Turbine flow meter PN 40 for LPG • 6 digit LCD-display with floating point • installation independent on location • various measuring options: total sum, sub-total (resettable) • current flow rate in l/min • lithium battery (approx. 4.000 operation hours); automatic switching on and off • not calibratable Order No. Connection Accuracy of measurement, % Measuring range, l/min Temperature range, °C Dimensions,мм Weight, kg 18 326 ½“ NPT ±2 4…40 10…60 110×50×55 0,9 18 325 2“ NPT 80…800 160×85×100 2,5 18 385 1“ NPT 2…200 115×50×70 1,2 18 388 ISO G¾” 8…80 110×50×70 1,1 Order No. Description 38 395 Differential valve for LC meter, 2” 98 930 Electronic calculator type ME 3000 98 1631 TEX batch controller with MODBUS interface 38 466 Epson Slip printer TM-U295, 24 VDC, for TE550 38 4120 Trap with strainer (MID400-Version) Version without printer Version incl. printer Version with TEX-Register Order No. Description 38 412 Trap with strainer (LC-Version) 38 444 Back check valve 98 6570 Coriolis mass flow meter DN 40/1½” 38 459 3-way solenoid valve 38 334 Impulse line for LC measuring units ENERGY • SAFETY • COMPETENCE LPG 2019-2020 50 . • .Complete measuring unit Type LC • flow direction from left to the right • BUNA seals • include fastening base without ground plate • execution for road tanker: – type MA-4 up to MA-15 – housing from alu • execution for stationary units: – type MSA-15 up to MSA-120 – housing from steel Equipment: Back check pressure valve in inlet (standard for MA-4 – MA-7), vapor eliminator with fine mesh filter, LC-Meter, mechanical counter Type VR with ticket printer, differential pressure valve. Combination options, spares and conversion parts on special request: electronic counter with ticket printer, flow direction from right to the left, with DIN-flanges, with pulser etc. Order No. Type Connection Capacity, l/min Operation pressure, bar Housing Execution Weight, kg Execution for road tanker 18 792 FAS-LC MA 5GX 10 1½” 20…227 25 Alu without temperature compensation 37,0 18 932 FAS-LC MA 5GY 10 1½” 45…227 25 with temperature compensation 40,0 18 7935 FAS-LC MA 7GX 10 2” 75…380 25 without temperature compensation 44,0 18 7936 FAS-LC MA 7GX 10 2” 75…380 25 without temperature compensation and without printer 43,0 18 904 FAS-LC MA 7 GY 10 2” 75…380 25 with temperature compensation 49,0 98 1641 FAS-LC MA 7 TEX 2” 75…380 25 with temperature compensation and Ex-pulser 46,0 18 794 FAS-LC MA 15 GX 10 3” 150…760 25 without temperature compensation 49,0 98 1642 FAS-LC MA 15 TEX 3” 150…757 25 with temperature compensation 46,0 18 750 FAS-LC MSA 15 GX 10 Extra charge for factory acceptance test with flow measurement and adjustment D Main components of measuring units Parameter Marking Unit Value Accurasy class – – 1,0 Maximum flow rate Qmax l/min, kg/min 450;220 Minimum flow rate Qmin l/min, kg/min 60; 40 Minimum measured quantity MMQ l; kg 50; 25 Order No. Description 98 1 80 Temperature sensor PT100 for using with MID 400 / ME 3000 excl. calibration 98 1801 Temperature sensor PT100 for using with MID 400 / ME 3000 incl. calibration 98 1800 Flange with 2 holes for measuring pockets 93 1920 PRESET Set for measuring system MID 400 93 1925 PRESET Set for measuring system MID 800 Metrological data LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .51 D FAS 98 1610 measuring unit for LPG road tankers MID-400 • flexible layout of connections (90° or 180° run) • expansion of preset option an any time • space saving installation • electrical switch box is not applicable • coriolis meter in a special design • electronical register in Ex de execution • data transfer via MODBUS-Interface • filling optionally in kilograms and/ or liters • density registration and report • FAS No. – 98 1611 CIS / 98 1602 EU Technical parameters of ME 3000 Registers: MME 3000 register was developed for use in mobile transport units for measuring of flammable liquids and gases: LPG, fuel oil, diesel and petrol products: • case – Ex d (ia) II B T6 • voltage – 24 V DC • memory of deliveries – 300; of changes – 250; of troubles – 200 Additional components for measuring units for LPG road tankers MID FAS-Nr Country-design Version 98 1623 Germany MID 400 98 1624 France MID 400 98 1625 Turkey MID 400 98 1626 Russia MID 400 98 1627 Ukraine MID 400 98 1628 Poland MID 400 98 1629 Czech Republic MID 400 98 1630 Kazakhstan MID 400 98 1614 nv MID800 98 1641 nv MA7-TEX 98 1642 nv MA15-TEX Parameter Marking Unit Value Accuracy class – – 1,0 Max flow rate Qmax l/min; kg/min 450;220 Min flow rate Qmin l/min; kg/min 60;40 Minimum measured quantity MMQ L; KG 50;25 Design for other countries by request available Order No. Description 98 6341 Temperature sensor PT100 for TE 550/TEX excl. calibration 98 6342 Temperature sensor PT100 for TE 550/TEX incl. calibration 98 1800 Flange for measuring pockets 93 1920 PRESET Set for measuring system MID 400 93 1925 PRESET Set for measuring system MID 800 Additional components for MID-TEX measuring units for LPG road tankers ENERGY • SAFETY • COMPETENCE LPG 2019-2020 52 . • .D MID-TEX measuring unit for LPG road tankers and LPG applications • flexible configuration • compact design • big coloured display • Coriolis mass flow meter • data transfer via MODBUS possible • LPG filling in mass (kg) and/or volume (l) • density monitoring • free to configure delivery ticket • “app” data transfer • remote control operation, external communication via serial cable, Ethernet, Bluetooth and WiFi • Ex d-design of TEX register FAS 98 1631 TEX Register could be used in measuring systems for the following liquids: : • petrochemical business: crude oil, liquid hydrocarbons, industrial oil, LPG ect • liquid food • alcohol, ethanol ect • chemical product in liquid forms • distilled water, deionized water ect • other liquids not listed Please note: TEX-Register could be combined with • all coriolis meters with MODBUS communication • all liquid controls PD meters equipped with pulser LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .53 Order No. Type Connection DN Max. measuring range, l/min (by LPG- applications) Mediation 98 8624 PROMASS 80E 15 180 HART, frequency output; analog input/output 98 8625 PROMASS 83E Modbus+RS485, frequency output; analog input/output 98 650 LPG-MASS 15 130 Modbus+RS485, frequency or puls output 98 8612 PROMASS 80E 25 500 HART, frequency output; analog input/output 98 8613 PROMASS 83E Modbus+RS485, frequency output; analog input/output 98 8614 PROMASS 80E 40 1268 HART, frequency output; analog input/output 98 8615 PROMASS 83E Modbus+RS485, frequency output; analog input/output 98 8616 PROMASS 80E 50 1950 HART, frequency output; analog input/output 98 8617 PROMASS 83E Modbus+RS485, frequency output; analog input/output 98 8618 PROMASS 80E 80 5075 HART, frequency output; analog input/output 98 8619 PROMASS 83E Modbus+RS485, frequency output; analog input/output 98 8689 PROMASS F300 50 1150 Modbus+RS485, frequency output 98 6570 LPG-MASS 40 720 Modbus+RS485, frequency or puls output 98 6572 LPG-MASS 50 1150 Modbus+RS485 98 656 LPG-MASS 25 360 Modbus+RS485, frequency or puls output Promass 40E Promass 83E Separate execution Coriolis mass flow meter for LPG • measures in real time, independent on physical characteristics of fluids • mass flow meter especially designed for analyses of viscosity, density, temperature and mass • sparkling measuring accuracy, recording of several process sizes: mass flow density and temperature of fluids and gases • cost-efficient, space-saving and maintenance free construction: no moving parts or seals • incompatible with all established communication-protocols: HART, PROFIBUS DP / PA, MODBUS, etc. • high anti-vibration stability, for example for operation on road tankers For other mediums – on special request D ENERGY • SAFETY • COMPETENCE LPG 2019-2020 54 . • .FAS 93 9352 complete support-measuring unit For draining of road tankers and business commercial registration of mass and/or volum devices (under consideration of real density and temperature of LPG), PN 25 • capacity up to 220 l/min • steel sheet cabinet – 1200×1200×600 mm • in- and outlet connections M60×4 (left) with ball valve • 2-digits LCD display • return pipe line RVS 22 mm • medium temperature -50 up to 125°C • pump unit – FAS-Z200 (220 l/min), mass flow meter – Promass 80E • measuring data – density, temperature, flow • totalizing counter for volume or mass FAS 93 9359 measuring unit in a cabinet construction • steel sheet cabinet – 2000×1600×500 mm • medium temperature -50 up to 125°C • in- and outlet connections flange DN 80 with ball valve • 4-digits LCD display • return pipe line RVS 22 mm • vapor eliminator with filter • differential pressure valve • complete shut-off and safety fittings • mass flow meter – Promass 83E • Modbus RS 485-interface • power supply 230 V • measuring data – density, temperature, flow • totalizing counter for volume or mass D Order No. Measuring rate, l/min Maximum working pressure, PN Inlet/ Outlet Voltage, V Weight, kg 98 6858 10-110 25 DISCH / Ermeto 22 mm 24/230 26 35 8301 20-1000 25 1¾” ACME AG 24/230 50 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .55 D Test unit for verifying your metering equipment • max. flow – 1000 l/min • connection: In / Out – 1¾“ ACME • power supply – 230 V or 24 V • coriolis mass flow meter • electronic counter • totalizer ”kg” and ”liter” • density measurement Consisting of following main components: • Strainer • Sight flow indicator • Vapor eliminator • Mass flow meter • Solenoid valves; ball valves; liquid level sensors FAS 93 1053 complete measuring line • capacity up to 2500 l/min • 2-digits LCS display • in- and outlet connections flange DN 100 • power supply – 230 V • measuring data – density, temperature, flow • totalizing counter for volume or mass 6 7 1 2 4 5 3 9 8 Inlet DN 100 Outlet DN 25 By pass line DN 20 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 56 . • .D Dimensional drawing of measuring line FAS 93 1053 Outlet gas phase Inlet liquid phase Lock Connection discharge line FAS-Vaporizer unit in vertical cabinet construction Bypass line LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .57 FAS vaporizers will be assembled generally as a facility and will be delivered as a complete ready unit. Vaporizers and their components (trap, regulator etc.) will be mounted on a base frame, in a lockable vertical cabinet or container. This simplifies the selection of installation place both internally and externally. The regulation of the connecting pipe lines may vary depending on typee, constellation and customer requests. Vaporizers • Vaporizer units • Mixturing E units E Liquid phase inlet Aluminium alloy (heat-carrier) Isolation coating Snake tube Vapor outlet Heater Abscheider Ausganggasphase Eingang Flüssigphase Umgehungsleitung Abblaseleitung Niederdruckregler Mitteldruckregler Verdampfer FAS 2000 Outlet phase Low pressure regulator Middle pressure regulator Inlet liquid phase Bypass line Discharge line Vaporizer FAS 2000 Trap ENERGY • SAFETY • COMPETENCE LPG 2019-2020 58 . • .Vaporizers FAS 2000 are so called „Dry typee vaporizers“ with indirect heating. An aluminium core with high heat conductivity is used as the heat transfer medium. This ensures short warm-up and reaction time. The control of solenoid valves and of the heating will be realized means of temperature sensor on aluminium block, hereby safety operation of the unit will be ensured. Typical diagram of vaporizer unit FAS 2000 Operating diagram of dry typee vaporizer FAS 2000 E LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .59 E Electrical dry typee vaporizer FAS 2000 • electrical dry type vaporizer • capacity – 15 kg/h • gas temperature outlet – max. 70°C • connection value – 4,4 kW (230 V, 14 A) • max. operation pressure – 25 bar • pipe screw connection • inlet/outlet – 12 mm • wire cross section – min. 2,5 mm2 • height – 350 mm • weight – 25 kg Vaporizer Type FAS 2000 in a special industrial version Will be used in nuclear industry, biogas production, technologi – cal production lines of a high degree of reliability, industrial test – ing facilities. Main features: • automated temperature control of the vapor phase in the specified parameters • transfer of operating data • “app” communication Order No. Vaporizer type Capacity, kg/h 20 3334 FAS 2000-15 15 20 3339 FAS 2000-25 25 20 3320 FAS 2000-40 40 20 554 FAS 2000-32 32 20 555 FAS 2000-60 60 20 556 FAS 2000-100 100 20 640 FAS 2000-170 170 Order No. Vaporizer type Capacity, kg/h 20 574 FAS-2000 i-32 32 20 575 FAS-2000 i-60 60 20 576 FAS-2000 i-100 100 20577 FAS-2000 i-170 170 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 60 . • .Model FAS-No. Capacity, kg/h Inlet/Outlet, Ø mm Cabinet dimension, B×L×H, mm Weight, kg FAS 2000-40 20 3381 40 DN 25/ DN 25 400×800×1200 140 FAS 2000-32 20 977 32 400×1200×1200 215 FAS 2000-60 20 648 60 400×1200×1200 265 FAS 2000-70 20 3382 70 400×1200×1200 233 FAS 2000-100 20 986 100 DN 25 / DN 50 400×1600×1200 352 FAS 2000-170 20 322 170 400×1600×1200 361 Complete vaporizer units Complete vaporizer units in cabinet construction ready for connection and consisting of: • strainer in front of vaporizer (liquid line) • liquid gas trap with possibility to install liquid level sensor • regulator group (modification with duplication is possible) • shut off fittings • pressure gauges • reserve gas line Complete unit mounted in a steel cabinet and is ready for connection directly after the installation E LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .61 E LPG vaporizer unit FAS 2000 • electrical dry type vaporizer • gas temperature outlet – max. 70°C • for Ex-Zone II • connection value – 380 V • 2-staged regulator unit • max. operation pressure – 25 bar Order No. Vaporizer, pcs. Capacity, kg/h Consumption, kW Connection, DN Outlet pressure, mbar Dimensions, mm Weight, kg Inlet (Liquid phase, Bypass line, Discharge line) Outlet Gas phase 20 924 2 200 2×18 25/25/25 50 50…300 2000×500×1600 360 20 321 2 330 2×24 25/25/25 50 50…300 2000×500×1600 380 20 259 3 450 3×24 15/15/25 50 50…300 2400×1800×1200 390 20 324 4 620 4×24 25 50 1500 2400×600×1800 450 20 328 6 900 6×24 25 50 1500 4800×600×1800 650 20 327 8 1250 8×24 25 50 1500 3000×2500×2600 900 Execution: • Outlet pressure 0,8 bar. Other setting pressures on request. Various adds-on such as step tread for operation of tank fittings, by-pass line with manual switching suitable for unit configuration are available on your request. Vaporizer size Tank size Ground frame Cabinet dimensions Inlet Outlet Connection voltage Connection value el. 15 4850 4230×850×100 1200×800×400 RVS15 left RVS18 left 230 V 4,4 kW 6400 5820×850×100 32 4850 4230×850×100 RVS22 left 400 V 6,0 kW 6400 5820×850×100 60 4850 4230×850×100 1200×1200×400 12,0 kW 6400 5820×850×100 100 4850 4230×850×100 18,0 kW 6400 5820×850×100 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 62 . • .Vaporizer unit in compact design with tank and dry-type vaporizer Type FAS 2000, Ex-Zone 2, connection voltage single-phase alternating current 230 V/50 Hz, 3-phase current 400 V/50 Hz, complete mounted in steel sheet cabinet, piped, tank and cabinet are mounted on a galvanized ground frame, piped, grounded and painted. Compact unit consisting of: • steel sheet cabinet, painter, with rain protection roof, vents, console h=100 mm • ball valve in in- and outlet as well as between trap and middle pressure regulator • strainer with fine mesh filter and safety relief valve in front of drytype vaporizer • pressure gauge 0-25 bar with pressure gauge shut-off valve in front of and behind the middle pressure regulator • dry-type vaporizer Type 2000 (see Order No. 20333, 20554-20556), for Ex-Zone 2, with 2 pcs. of solenoid valves at vaporizer’s inlet, 1 safety relief valve at vaporizer’s outlet, control box on vaporizer, wired ready for connection • trap with emptying of remainders • middle pressure regulator PN 25 with emergency shut-off valve (SAV) and connection with pressure tap (SBV) and pressure gauge • LPG storage tank acc. to DIN 4680 (domestic tank), for over ground installation, for storage of LPG, with standard fittings • ground frame in special execution • excess flow valve • by pass line from safety relief valves in vaporizer’s cabinet E Detailed view of heat exchanger. Special profiling to optimize the heat transfer. Functioning principle of plate heat exchangers. LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .63 E Vaporizer FAS 3000 are generally designed for middle and large industrial consumers. They will be also used in mixing units for production of liquid gas-air-mixture (synthetic natural gas). The effectivity of vaporizers FAS 3000 will be achieved through applications of welded plate heat exchangers especially designed for these purposes with a high efficiency factor as well as their potential to work with small temperature differences. The thermal transfer will be affected over curly plates from stainless steel, mounted in a package. Hot and cold sectors are alternating. Such construction ensures an affective system of heat exchange surface. Discharge line Middle pressure regulator Liquid trap By-pass line Inlet hot water Outlet hot water Inlet liqid phase Low pressure regulator Outlet gas phase Vaporizer FAS 3000 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 64 . • .LPG vaporizer unit FAS 3000 • capacity – 200 kg/h • outlet pressure – 50 mbar • design pressure – 25/10 bar (gas/water) • heat carrier temperature – 90/70°C • power supply 230 V • inlet connection DN 25 (liquid phase, by-pass line, discharge line, hot water) • outlet connection DN 25/DN 50 (water, gas) • dimensions – 1200×1200×400 mm • weight – 255 kg Scope of delivery • Vaporizer FAS 3000 • Thermostat for gas temperature • 2 liquid level sensors • 2 solenoid valves in inlet of liquid phase • Safety relief valve in liquid phase • Thermometer • Pressure switch in water space • Liquid trap with ball valve for emptying • Separate control box for mounting outside of Ex-zone • Regulator unit: (middle pressure regulator, inlet pressure – up to 16 bar, • Outlet pressure – 1,5 bar, low pressure regulator, outlet pressure – 50 mbar, emergency shut-off valve (SAV) and connection with pressure tap (SBV), pressure gauge Hydraulic schema of vaporizer unit FAS 3000-200 Vaporizer type Capacity, kg/h FAS 3000 200 300 E LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .65 E LPG vaporizer unit FAS 3000 • outlet pressure – 50…5000 mbar • design pressure – 25/10 bar (gas/water) • heat carrier temperature – 90/70°C • thermostat for gas temperature • 2 liquid level sensors • 2 solenoid valves in inlet of liquid phase • safety relief valves in liquid phase • thermometer • pressure switch in water space • liquid trap with ball valve for emptying • separate control box for mounting outside of Ex-zone • regulator unit FAS No. Capacity, kg/h Pressure, outlet, mBar 20 247 400-800 without regulator group 20 246 1000-1200 without regulator group 20 245 1500-1900 without regulator group 20 229 up to 4000 without regulator group 20 249 up to 7000 without regulator group 20 250 up to 12000 without regulator group 20 248 400-800 20-2100* 20 2481 400-800 5-5000* 93 065 1000-1200 5-5000* 93 073 1500-1900 5-5000* 93 153 up to 4000 5-5000* 93 074 up to 7000 5-5000* 93 075 up to 14000 5-5000* Scheme of jet mixer Hydraulic schema of mixer FAS 4000 • 32 ND Mixing unit FAS 4000 are available in two executions: • ND – as low pressure unit • HD – as high pressure unit Low pressure mixing units are designed in cabinet construction for systems with an outlet pressure of not higher as 500 mbar. High pressure mixing units are depending on local operation conditions at side. They will be designed and manufactured accordingly to corresponding requirements and specifications of customers. Air Air Propane Propane Propane-air-mixture Propane-air-mixture ENERGY • SAFETY • COMPETENCE LPG 2019-2020 66 . • .LPG-Air-Mixing unit FAS 4000 (Vaporizer + Mixing unit) for large demand. The facility is developed for great gas supply systems with natural gas to cover the pick loads as well as for places of location with an elevated risk of condensation in the gas line. E LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .67 E The combined Mixing units FAS 4000 can be designed in special configurations depending on conditions of a special object. Order No. Mixing units Type Capacity, m3 (propane-air-mixture) kg/h Inlet/Outlet LPG Inlet/Outlet pressure, mbar 93710 FAS 4000-32 ND 30/30 DN15/DN50 2000–5000/ up to 500 93711 FAS 4000-60 ND 50/60 DN15/DN50 93712 FAS 4000-100 ND 80/100 DN20/DN65 93713 FAS 4000-160 ND 130/160 DN25/DN65 93714 FAS 4000-300 ND 240/300 DN25/DN65 93953 FAS 4000-640-4 ND 640/790 DN32/DN200 – FAS 4000-1200 ND 1200/1480 DN65/DN200 Accessories for road tankers F FAS-No. Type Capacity, m3/h (l/min) Differential pressure, bar NPSH stage Connection for hydraulic motor 46 0953 STW NZ24-8 24 (400) 9 – PARKER F11-14 46 0962 STW NZ24-7 24 (400) 8 + PARKER F11-14 46 0952 STW NZ48-8 48 (800) 9 – PARKER F11-19 46 0964 STW NZ60-7 60 (1000) 7 – PARKER F11-19 FAS-No. Type Capacity, m3/h (l/min) Differential pressure, bar NPSH stage Hydraulic motor type Liquid demand, l/min, connection 46 0955 STW NZ24-8 24 (400) 9 – SUNFAB 010 29, G¾“ 46 0961 STW NZ24-8 24 (400) 9 + SUNFAB 012 38, G¾“ 46 0954 STW NZ48-8 48 (800) 9 – SUNFAB 012 38, G¾“ 46 0969 STW NZ60-7 60 (1000) 7 – Recommended pump protection elements: • dry run protection (like FAS 18 382) • oil pressure switch (like FAS 18 456 or 18 4563) • by pass valve (like FAS 19333, 19 337, 19 350) ENERGY • SAFETY • COMPETENCE LPG 2019-2020 68 . • .F Advantages of LPG FAS-NZ pumps • low noise emission • low vibration • high reliability Pump FAS-NZ without motor Pump units FAS-NZ with hydraulic motor in truck execution Pump unit with hydraulic motor PN 25 • for positive suction head • pump case of ductile iron ASTM A536 • with single-acting mechanical seal • complete unit consisting of pump • hydraulic adaptor, coupling and hydraulic motor • ready for connection mounted, primed and painted Order No. Pump Type Motor, kW Capacity, l/min Speed, RPM Oil recirculated quantity, l/min Oil pressure, bar Pump with NPT-threaded flanges, right-handed, execution A (Corken/Danfoss) 21 5720 Z 2000/OM 80 5,5 220 640 58,0 100 21 299 Z 3200/OM 100 10,0 450 550 29,0 232 21 2993 Z 3200/OM 80 8,0 400 750 52,0 110 21 2995 Z 3500/OM 100 10,0 450 550 60,0 140 Pump units left-handed on your request. Power rating at 5 bar differential pressure. Inlet flange 3” ANSI 300 lbs Pump with welding ends, right-handed, execution A (Blackmere/Danfoss) 21 572 LGL 2”E/OM 80 5,0 220 650 58,0 100 21 573 LGL 3“F/OM 100 10,0 380 550 29,0 232 21 574 LGL 3“F/OM 100 10,0 380 550 60,0 140 21 576 LGL 2”E/OM 80 5,0 220 650 58,0 100 21 577 LGL 3“F/OM 100 10,0 380 550 29,0 232 21 578 LGL 3“F/OM 100 10,0 380 550 60,0 140 Pump units left-handed on your request. Power rating at 5 bar differential pressure. Complete measuring unit Type LC • flow direction from left to the right • BUNA seals • include fastening base without ground plate • housing for road tanker: type MA-4 up to MA-15 – from alu • housing for stationary units: type MSA-15 up to MSA-120 – from steel Equipment: Back check pressure valve in inlet (standard for MA-4 – MA-7), vapor eliminator with fine mesh filter, LC-Meter, mechanical counter Type VR with ticket printer, differential pressure valve. Combination options, spares and conversion parts on special request: electronic counter with ticket printer, flow direction from right to the left, with DIN-flanges, with pulser etc. Order No. Type Connection Capacity, l/min Operation pressure, bar Housing Temperature compensation Weight, kg Execution for road tanker 18 792 FAS-LC MA 5GX 10 1½” 20…227 25 Alu – 37,0 18 932 FAS-LC MA 5GY 10 1½” 45…227 25 + 40,0 18 7935 FAS-LC MA 7GX 10 2” 75…380 25 – 44,0 18 7936 FAS-LC MA 7GX 10 2” 75…380 25 – (without printer) 43,0 18 904 FAS-LC MA 7 GY 10 2” 75…380 25 + 49,0 98 1641 FAS-LC MA 7 TEX 2” 75…380 25 + (and Ex-pulser) 46,0 18 794 FAS-LC MA 15 GX 10 3” 150…760 25 – 49,0 98 1642 FAS-LC MA 15 TEX 3” 150…757 25 + 46,0 18 750 FAS-LC MSA 15 GX 10 Extra charge for factory acceptance test with flow measurement and adjustment LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .69 FAS-Corken pump unit Z 3500 without printer with printer with TEX-Register F Parameter Marking Unit Value Accurasy class – – 1,0 Maximum flow rate Qmax l/min, kg/min 450;220 Minimum flow rate Qmin l/min 60; 40 Minimum measured quantity MMQ l; kg 50; 25 Metrological data FAS 98 1610 measuring unit for LPG road tankers MID-400 • flexible layout of connections (90° or 180° run) • expansion of preset option an any time • space saving installation • electrical switch box is not applicable • coriolis meter in a special design • electronical register in Ex de execution • data transfer via MODBUS-Interface • filling optionally in kilograms and/ or liters • density registration and report • FAS No. – 98 1611 CIS / 98 1602 EU Technical parameters of ME 3000 Registers: MME 3000 register was developed for use in mobile transport units for measuring of flammable liquids and gases: LPG, fuel oil, diesel and petrol products: • case – Ex d (ia) II B T6 • voltage – 24 V DC • memory of deliveries – 300; of changes – 250; of troubles – 200 Order No. Description 98 1 80 Temperature sensor PT100 for using with MID 400 / ME 3000 excl. calibration 98 1801 Temperature sensor PT100 for using with MID 400 / ME 3000 incl. calibration 98 1800 Flange for measuring pockets 93 1920 PRESET Set for measuring system MID 400 93 1925 PRESET Set for measuring system MID 800 Additional components for measuring units for LPG road tankers MID ENERGY • SAFETY • COMPETENCE LPG 2019-2020 70 . • .F LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .71 F FAS-Nr Country-design Version 98 1623 Germany MID 400 98 1624 France MID 400 98 1625 Turkey MID 400 98 1626 Russia MID 400 98 1627 Ukraine MID 400 98 1628 Poland MID 400 98 1629 Czech Republic MID 400 98 1630 Kazakhstan MID 400 98 1614 nv MID800 98 1641 nv MA7-TEX 98 1642 nv MA15-TEX Parameter Marking Unit Value Accuracy class – – 1,0 Max flow rate Qmax l/min; kg/min 450;220 Min flow rate Qmin l/min; kg/min 60;40 Minimum measured quantity MMQ L; KG 50;25 Design for other countries by request available Order No. Description 98 6341 Temperature sensor PT100 for TE550/TEX excl. calibration 98 6342 Temperature sensor PT100 for TE550/TEX incl. calibration 98 1800 Flange with 2 holes for measuring pockets 93 1920 PRESET Set for measuring system MID 400 93 1925 FAS PRESET Set for measuring system MID 800 Additional components for MID-TEX measuring units for LPG road tankers MID-TEX measuring unit for LPG road tankers and LPG applications • flexible configuration • compact design • big coloured display • Coriolis mass flow meter • data transfer via MODBUS possible • LPG filling in mass (kg) and/or volume (l) • density monitoring • free to configure delivery ticket • “app” data transfer • remote control operation, external communication via serial cable, Ethernet, Bluetooth and WiFi • Ex d-design of TEX register FAS 98 1631 TEX Register could be used in measuring systems for the following liquids: : • petrochemical business: crude oil, liquid hydrocarbons, industrial oil, LPG ect • liquid food • alcohol, ethanol ect • chemical product in liquid forms • distilled water, deionized water ect • other liquids not listed Please note: TEX-Register could be combined with • all coriolis meters with MODBUS communication • all liquid controls PD meters equipped with pulser ENERGY • SAFETY • COMPETENCE LPG 2019-2020 72 . • .Hose reels Type Hannay Reels with hand crank • LPG high-pressure hoses LPG 25 / LPG 32 • hose connection – G¼” male • inlet – 1½” NPT female • swivel joint 90° • completely mounted on base frame, primed and painted Type: • A – inlet and drive right-hand • B – inlet and drive left-hand Type: • A – inlet and drive right-hand • B – inlet and drive left-hand Supply options: • Including the LPG-Hose • Including the measuring • System LPG-Control MID 400 Order No. Type of LPG high pressure hoses Weight, kg Type A Type B 24 331 24 332 LPG 25 (up to 44 m) LPG 32 (up to 38 m) 50,0 24 333 24 334 LPG 25 (up to 60 m) LPG 32 (up to 50 m) 57,0 Order No. LPG-hoses Type Weight, kg 24 3415 DN 32 max. 40 m 41,60 Hose reels Type Hannay Reels with pneumatic drive • LPG high-pressure hoses LPG 25 / LPG 32 • hose connection – G¼” male • inlet – 1½” NPT female • swivel joint 90° • completely mounted on base frame, primed and painted FAS Hose Reel with pneumatic drive, Type VIP 40, PN 25 • Road tanker version in ALU – light-weight design, • For LPG high pressure pipe line DN 32 • Hose length max. 40 m • Inlet left-hand DN 40 • Outlet right-hand 1 1/4” NPT IG (hose connection) • Regulation: push lever valve • Bracket for road tanker connection 1 3/4 ACME • Completely mounted and tested for functioning Order No. Type of LPG high pressure hoses Weight, kg Type A Type B 24 341 24 342 LPG 25/32 (up to 44/38 m) 60,0 24 343 24 344 LPG 25/32 (up to 60/50 m) 68,0 F LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .73 F Tandem hose reels Type Hannay Reels • left reel for LPG high-pressure hose LPG 25 for a length up to 40 m, with swivel joint 90°, inlet 1½” female NPT and hose connection 1” female NPT • right reel for LPG high-pressure hose LPG 13 for a length up to 40 m, with swivel joint 90°, inlet 1“ female NPT and hose connection ½” female NPT • completely mounted on a base frame, primed and painted Type: • A – with hand drive • B – with pneumatic drive • C – with hydraulic drive Order No. Type Weight, kg 24 356 А 92,0 24 329 В 106,0 24 351 С 110,0 Complete high-pressure hose line suitable for hose reel • complete with hose connections on both sides • inlet flat seal with union nut • outlet – male NPT thread Type: • A – Length 40 m • B – Length 50 m Order No. LPG-Hose length Connection, ” Weight, kg Type А Type В Inlet Outlet Type А Type В 24 005 24 014 25 G 1¼ 1 NPT 42,0 52,0 24 006 24 015 32 1¼ NPT Hose reels Type Hannay Reels with hydraulic drive • hydraulic drive • LPG high pressure hose LPG 25 and LPG 32 • inlet – 1½” NPT female • swivel joint 90° • completely mounted on base frame, primed and painted Type: • A – inlet and drive right-hand, hose connection G 1¼” male • B – inlet and drive left-hand, hose connection G 1¼” male • C – inlet and drive left-hand, hose connection 1¼” NPT male • D – inlet and drive right-hand, hose connection 1¼” NPT male Order No. Type of LPG high pressure hoses Weight, kg Type A Type B Type C Type D 24 361 24 362 24 365 24 366 LPG 25 (up to 44 m) LPG 32 (up to 38 m) 62,0 24 363 24 364 24 368 24 367 LPG 25 (up to 60 m) LPG 32 (up to 50 m) 68,0 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 74 . • .3-way ball valve PN 63 • truck version • from stainless steel • welding ends • housing and shaft from 1.4401 • temperature – -30 up to +180°C Order No. Size, DN, “ Weight, kg Length, mm 19 2311 DN 15, ½” 0,60 75 19 2321 DN 20, ¾” 0,90 80 19 2330 DN 25, 1” 1,40 90 19 2350 DN 40, 1½” 2,90 125 19 2360 DN 50, 2” 4,70 150 19 2370 DN 65, 2½” 10,30 185 19 2380 DN 80, 3” 15,30 205 19 2390 DN 100, 4” 24,60 240 Cable drum type FAS • cable and earthing clamp • spring rewind • lockable in any position • cable material – copper cable cross section 2,5 mm2 Type: • A – open execution • B – closed execution Order No. Type Cable length, m Weight, kg 24 321 А 50 17,6 24 322 А 25 7,0 24 019 В 30 7,0 F LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .75 F Quick-acting shut-off valve PN 25 • angular • material – steel • open position with locking device • outlet with vent valve Quick-acting valve PN 25 • material – steel • with safety filling device • closing position with lock • suitable for LPG and ammonia Quick-acting shut-off valve PN 25 • with safety filling device Order No. Type RegO Execution Inlet/outlet Weight, kg 13 021* A7708 L angle form 1” NPT / 1” NPT 1,6 13 022* A7707 L straight form 1,7 Order No. Type RegO Execution Inlet/outlet Weight, kg 13 0351 A7793 A angle form ¾” NPT / 1¾” ACME 2,9 13 035 A7797 A angle form 1” NPT / 1¾” ACME 2,8 Order No. Type Inlet/outlet Lock Weight, kg 13 018 RegO/FAS 1” NPT IG / 1¾” ACME + 2,9 13 031 RegO/FAS – 2,9 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 76 . • .Wheel block as rolling protection for road tankers up to 40 tons gross weight • stainless steel • mechanical switch EEx dII C T6, 250 V AC/6 A respectively 24 V DC/4 A Ex-proof • cable connecting end length = 10 m • flexible plastic protection hose Order No. Execution 24 191 In case of interruption of contact, e.g. in case of rolling of the tank truck, the stop of the filling process is effected by the quick-acting shut-off equipment, respectively by the emergency stop system Excess flow valve PN 25 for road tankers • of stainless steel 1.4541 • 2” female NPT connection on both sides • for installation in front of hose reel Order No. Type Capacity (liquid phase), l/min Weight, kg 24 013 FAS 697-2 1210 2,5 Pneumatic actuator for RegO internal valves Order No. Type RegO Connection, ” 24 137 A3209 PA 1¼ 24 138 A3212 PA 2 24 139 A3213 PA 3 Hand pump for RegO internal valves with hydraulic control Order No. Execution Weight, kg 24 751 Type Whessoe 7012, connection – ¼“BSP, with oil tank, max. oil pressure 80 bar 15,0 Line housing for pneumatic internal quick-acting valves type Whessoe • for installation in pipelines • steel body with reinforced bolts • flange connection according to ASME/ASA, Class 300 Order No. Connection, ” Max. pressure, bar Weight, kg 24 731 2 30 20,0 24 732 3 31,0 24 733 4 50,0 24734 6 73,0 24 735 8 103,0 24 736 10 127,0 F LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .77 F Internal valve with NPT connection • body of ductile iron ASTM A395 or equivalent • with built-in excess flow valve • hand lever • actuated mechanically by cable, by pneumatic or by hydraulic force Internal valve flanged • housing from ductile graphite iron ASTM A395 or similar • with integrated excess flow valve, hand lever • mechanical switching with cable, pneumatic or hydraulic actuator possible Order No. Type Connection NPT,” Outlet Weight, kg Pic. 24 131 RegO A3209 A050 1¼ 1 0,9 1 24 132 RegO A3212 A175 2 1 4,1 2 24 135 RegO A3213 A300 3 1 7,3 3 24 101 Fisher C407-10 1¼ 1 0,9 1 24 1021 Fisher C427-16 2 1 4,1 2 Order No. Type RegO Closing volume, GPM / l Connection (flange 300 lb) Weight, kg 28 107 A3217 AR410 410/1550 3” 20,0 28 1079 A3217 AR510 510/1930 3” 17,8 28 308* A3217 DAR410 410/1550 3” 29,4 28 0881 A3219 FA400L 400/1515 4” 31,0 28 088 A3219 FA600L 600/2270 4” 30,0 RegO internal vale with ANSI-flange on request Order No. Type Connection NPT,” Outlet Weight, kg Pic. 24 103 Fisher C421-16 2 2 5,0 2 24 104 Fisher C402-16 2 3 6,8 2 24 1051 Fisher C427-24 3 1 7,3 3 24 106 Fisher C421-24 3 2 9,6 3 24 107 Fisher C402-24 3 3 17,2 3 1 2 3 * Version with double flange connection. Other flow rates on request ENERGY • SAFETY • COMPETENCE LPG 2019-2020 78 . • .F Internal valve PN 25 • with double flange connection • type RegO Flomatic • housing from ductile graphite iron ASTM A395 or similar • the valve is operated automatically, the opening and closing is managed by pressure difference from switch on and switch off of the pump • with visual indicator for “open” and “closed” position of the valve Order No. Type RegO Connection (flange 300 lb) Weight, kg 24 141 A7883FK 3” 24,0 24 142 A7884FK 4” 33,0 Order No. For internal valve Type A, B 24 791 6239 – 2”/DN 50 24 792 6239 – 3”/DN 80 24 793 6239 – 4”/DN 100 24 794 6239 – 6”/DN 150 Type C 24 741 6139 – 2” Order No. Max. pressure, bar Connection ANSI/ASA RF, ” Weight, kg Type B Type C – 24 721 21,0 2 9,0 – 24 722 3 12,0 – 24 723 17,5 4 21,0 – 24 724 6 32,0 – 24 725 8 47,0 – 24 726 10 63,0 Internal withdrawal-quick acting valve for road tanker and stationary tanks • type Whessoe, internal • additional body for pipe lines • in case of failure of auxiliary energy the valves close automatically by means of a spring • with hydraulic or pneumatic control system (min. 5 bar) • body of steel ASTM A352 Grade LCB, chromed steel cylinder and pistons, spring of stainless steel, seals resistant male ainst LPG • connection auxiliary energy 3 /8” NPT Spare parts Type: • A – type 6239, for pneumatic control, flange connection to DIN 2635, with approval according to EEC directive 94/55/CE, not available, only spare parts • B – type 6239, for pneumatic control, flange connection according to ANSI/ASA RF, not available, only spare parts • C – type 6139, from 8” type 6240, for hydraulic control, flange connection according to ANSI/ASA RF Type 6240 Type 6139 Order No. For internal valve Type C 24 742 6139 – 3” 24 743 6139 – 4” 24 744 6139 – 6” 24 745 6139 – 8” 24 746 6139 – 10” LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .79 Globe valve • NPT-thread • soft seal Order No. Type Size, DN, ” Length, mm Weight, kg 19 001 N301-04 ½ 94 1,40 19 002 A7505 АР ¾ 94 1,10 19 003 A7507 АР 1 110 1,60 19 004 А7509ВР 1¼ 125 3,10 19 005 А7511АР 2 150 3,70 19 006 А7513АР 2 150 7,70 19 007 А7517АР 3 230 18,00 Angle valve • NPT-thread • soft seal Order No. Type Size, DN, ” Length, mm Weight, kg 19 009 N401-04 ½ 45 1,25 19 010 A7506 AP ¾ 45 1,20 19 011 A7508AP 1 51 1,20 19 012 A7510 BP 1¼ 57 2,70 19 013 A7512AP 1½ 62 3,60 19 014 A7514 AP 2 69 5,00 19 015 A7518AP 3 102 15,00 Shut-off valves • Bypass valves • 3-way valves • Solenoid valves • Ball valves • Quick-acting G valves G ENERGY • SAFETY • COMPETENCE LPG 2019-2020 80 . • .Shut-off valve/ regulating valve PN 20 • NPT-thread Order No. Type Size, DN, ” Weight, kg Pic. 19 033 1224 WA ¼ 0,1 1 19 034 2553 ¼ 0,7 2 19 035 2553 A 3 /8 0,7 2 1 2 Shut-off valve • NPT-thread • collar seal Type • A – straight type • B – angle type Order No. Type Size, DN, ” Length, mm Weight, kg Pic. Type A 19 017 7704 P ½ 95 1,0 1 19 018 7705 P ¾ 95 1,0 1 Type B 19 020 7704 LP ½ 43 0,9 2 19 021 7706 P ¾ 43 0,9 2 Order No. Type Size, DN, ” Length, mm Weight, kg Pic. 19 026 7901 T ¼ 63 0,6 1 19 027 7554 SAV ½ 94 1,0 2 19 028 7554 SV ¾ 94 1,0 2 Quick acting valve with lever • NPT-thread Ball valve with spring release • NPT-thread • mechanical hand lever Order No. Type Size, DN, ” Length, mm Weight, kg 19 151 Argus ½ 90 2,0 Type А 1 2 Type В G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .81 G Angle valve • connection ¾” NPT male Order No. Type Outlet Material Pic. Weight, kg 19 439 9101 C1 POL Brass 1 0,4 19 440 7550 P ¾” NPT Brass 1 0,6 19 441 FAS 484 ¾” NPT, with brass plug Brass 1 0,7 19 442 A7550 P ¾” NPT Steel 1 0,6 19 443 7550 PX ¾” NPT, with excess flow valve Brass 2 0,6 19 444 A7550 PX ¾” NPT, with excess flow valve Steel 2 0,6 19 445 901 C5 POL, with excess flow valve Brass 2 0,4 19 446 9101 DNP POL, with dip tube 300 mm Brass – 0,5 19 447 FAS 483 POL, with dip tube 300 mm and pressure gauge Brass 3 0,7 19 448 Brass plug for angle valve ¾“ NPT, brass, with seal Other dip tubes are available on request 1 2 3 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 82 . • .Shut-off valve • straight type • flanges acc. to DIN 2635 • length acc. to DIN 3202 • body of cast steel GS-C 25 • seat ring, disc and stem of stainless steel • leakproof class 1 to DIN 3230 part 3 Type: • A – gland seal of pure graphite • B – bellows seal, mainte – nance free Order No. Size, DN Length, mm Weight, kg Type A Type B 19 041 19 101 15 130 4,8 19 042 19 102 20 150 5,4 19 043 19 103 25 160 7,1 19 044 19 104 32 180 8,0 19 045 19 105 40 200 11,5 19 046 19 106 50 230 13,5 19 047 19 107 65 290 23,5 19 048 19 108 80 310 28,0 19 049 19 109 100 350 39,5 Order No. Size, DN Weight, kg Length, mm 93251 15 1,5 38 93252 20 2,0 40 93253 25 2,7 45 93254 32 5,2 58 93255 40 6,8 64 93256 50 11,1 82 93257 65 15,6 103 93258 80 22,3 122 93259 100 37,3 150 Ball valve straight type with hand lever • execution „Fire-Safe“ acc. to BS 6755 part 2, • compact FAS-KHV • body and ball of stainless steel (CrNi AISI 304), seals – PTFE • leakproof class 1 acc. to DIN 3230 part 3 G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .83 G Order No. Size, DN Connection (NPT), ” Weight, kg 19 449 8 ¼ 0,2 19 450 10 3/8 0,3 19 451 15 ½ 0,4 19 452 20 ¾ 0,6 19 453 25 1 0,9 19 454 32 1¼ 1,5 19 455 40 1½ 2,2 19 456 50 2 2,9 Ball valve type F120 PN 63 • full bore • two-piece body – steel 1.4408 • seals of PTFE • ball of stainless steel CF8M • operating lever • length acc. to DIN 3202 T4M3 Ball valve full bore with operating lever • execution “Fire-Safe” acc. to BS 6735 part 2 • body – ASTM A 105 • ball – of stainless steel (CrNiAISI 304) • seals – of PTFE • leakproff class 1 acc. to DIN 3230 Type: • A-type FAS-KHB, compact execution, block body • B-type FAS-KHF, standard, two piece body Order No. Size, DN Weight, kg Type А Type B Type А Type B 92 151 92 271 15 1,3 3,3 92 152 92 272 20 1,9 4,5 92 153 92 273 25 2,6 6,0 92 154 92 274 32 5,3 8,0 92 155 92 275 40 6,9 13,0 92 156 92 276 50 11,0 17,0 92 157 92 277 65 15,6 23,0 92 158 92 278 80 22,4 28,0 92 159 92 279 100 37,4 43,0 92 171 92 280 125 60,0 69,0 92 172 92 281 150 – 80,0 92 173 92 282 200 – 120,0 FAS-KHB FAS-KHF ENERGY • SAFETY • COMPETENCE LPG 2019-2020 84 . • .Ball valve PN 40 type Mecafrance • three-piece body of forged steel C 22.8 • seals of PTFE, selector shaft and ball of stainless steel • operating lever Stainless steel ball valves PN 63 • truck version • from stainless steel • welding ends • housing and shaft from 1.4401 • working temperature – -30 up to +180°C Type: • A – full bore • B – reduced bore, standard execution • C –seal kit Special executions: for road tankers, FIRE SAFE, and for temperature up to -20°C are available on request. Order No. Size, DN, ” Weight, kg Order No. Size, DN, ” Weight, kg Welding ends Pipe thread NPT-thread Type C full bore reduced bore Type A Type B Type B Type B 19 121 19 231 19 241 19 251 15 – ½ 0,5 19 261 10 – ¼ 15 – ½ 0,1 19 122 19 232 19 242 19 252 20 – ¾ 0,8 19 262 15 – ½ 20 – ¾ 0,1 19 123 19 233 19 243 19 253 25 – 1 1,3 19 263 20 – ¾ 25 – 1 0,1 19 124 19 234 19 244 19 254 32 – 1¼ 1,8 19 264 25 – 1 32 – 1¼ 0,1 19 125 19 235 19 245 19 255 40 – 1½ 2,8 19 265 32 – 1¼ 40 – 1½ 0,1 19 126 19 236 19 246 19 256 50 – 2½ 3,8 19 266 40 – 1½ 50 – 2 0,1 19 127 19 237 – – 65 – 2 7,5 19 267 50 – 2 65 – 2½ 0,1 19 128 19 238 – – 80 – 3 12,0 19 268 65 – 2½ 80 – 3 0,1 19 129 19 239 – – 100 – 4 20,5 19 269 80 – 3 100 – 4 0,1 Order No. Size, DN, “ Weight, kg Length, mm 19 2311 DN 15, ½” 0,60 75 19 2321 DN 20, ¾” 0,90 80 19 2330 DN 25, 1” 1,40 90 19 2350 DN 40, 1½” 2,90 125 19 2360 DN 50, 2” 4,70 150 19 2370 DN 65, 2½” 10,30 185 19 2380 DN 80, 3” 15,30 205 19 2390 DN 100, 4” 24,60 240 G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .85 G Ball valve PN 40 with full bore with electrical actuator • “Fire-Safe” version acc. to BS6755 part 2 • type with flanges – Type FAS-KHF • type compact – Type FAS-KHB • body – of steel ASTM A105 • ball – of stainless steel (CrNi AISI 304) • seals – of PTFE • leakproof class 1 acc. to DIN 3230 • electrical actuator – AUMA NORM SGEXC Order No. Size, DN Weight, kg 93820 15 26,5 93821 20 27 93822 25 28 93823 32 31 93824 40 32 Order No. Size, DN Weight, kg 93825 50 36 93826 65 41 93827 80 48 93828 100 51 93829 125 94 Order No. Size, DN Weight, kg 93830 150 121 93831 200 240 93832* 250 500 FAS-KHB FAS-KHF Electrical actuator AUMA series SGEXC for ball valve • bending range – 80…110° • Ex-protection – II2G EEx de IICT4 • temperature range – -40…+40°C • power supply – 400 V 50 Hz, protection class IP 67 Order No. Ball valve size Actuator type 93844 DN 15, DN 20, DN 25, DN 32, DN 40, DN 50, DN 65 SGEхC 05.1 93845 DN 80, DN 100, DN 125 SGEхC 07.1 93847 DN 150 SGEхC 12.1 * with FAS-KHF ENERGY • SAFETY • COMPETENCE LPG 2019-2020 86 . • .3-way ball valve type FAS-KHF W3, PN 40 • full bore • body – of steel ASTM A105, ball – of stainless steel CrNi AISI 304, seals – of PTFE • L-bore • flanges acc. to DIN 2635 • three-piece body • hand lever Order No. Size, DN Weight, kg 92 292 DN15 4 92 291 DN20 6 92 293 DN25 7 92 294 DN32 12 92 295 DN40 14 92 296 DN50 20 Order No. Size, DN Weight, kg 92 297 DN65 34 92 298 DN80 50 92 299 DN100 71 92 300 DN125 119 92 301 DN150 185 Quick-acting ball valve PN 40 with full bore • “Fire Safe” version acc. to BS6755 part 2 and antistatic device • flanges acc. to DIN 2635 • seals – of PTFE • leackproof class 1 acc. to DIN 3230 • with pneumatic actuator in maintenance free compact execution, angle of rotation 90°, with automatic spring return, 5-8 bar, min. pilot pressure of 5 bar (at a max. differential pressure of 25 bar) Type: • A – type ARGUS, body of forged steel TSTE 355N, ball and shaft of stainless steel, shaft seal of Viton • B – type ALFA, body of forged steel ASTM A 105 (C 21), ball and shaft of stainless steel, shaft seal of PTFE/Viton • C – type Bont, body of forged steel ASTM A 105 (C 21), three-piece body, ball and shaft of stainless steel, shaft seal of PTFE/Viton G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .87 G Order No. Size, DN Length, mm Weight, kg Type A Type B Type A Type B 19 700 19 730 15 115 8,0 8,5 19 701 19 731 20 120 9,0 9,5 19 702 19 732 25 125 9,5 10,5 19 703 19 733 32 130 14,2 15,3 19 704 19 734 40 140 15,1 18,8 19 705 19 735 50 150 21,4 26,4 19 706 19 736 65 170 33,5 37,7 19 707 19 737 80 180 47,0 53,0 19 708 19 738 100 190 69,3 80,0 19 709 19 739 125 325 80,0 95,0 19 880 19 890 150 350 137,0 122,0 Order No. Size, DN Length, mm Weight, kg Type A Type B Type A Type B Type C 19 750 19 860 15 230 7,6 205 7,5 19 751 19 861 20 250 8,3 225 8,1 19 752 19 862 25 260 9,5 235 9,3 19 753 19 863 32 250 13,0 250 12,4 19 754 19 864 40 260 14,9 270 14,6 19 755 19 865 50 270 20,2 211 25,5 19 756 19 866 65 285 32,4 250 34,5 19 757 19 867 80 315 46,7 308 48,0 19 758 – 100 355 69,2 – – 19 759 – 125 463 95,0 – – Welded end connection on one side, DIN-flange on other side Accessories DIN-flange connection on both sides, length acc. to DIN 3202 F4/F5 short model Order No. Type Weight, kg 19 710 Limit switch in housing, Ex-proof, for open/closed position indication, with optical position indicator 1,8 19 711 19 763 ATEX 3 /2-way solenoid valve, Ex-proof, Namur interface, for compressed air, max. 10 bar, thread connection G¼”, operating voltage 230 V, 50 Hz 1,5 19 712 3 /2-way solenoid valve, Ex-proof, for compressed air, max. 10 bar, thread connection G¼”, operating voltage 24 V, coflow 1,5 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 88 . • .Solenoid valve PN 40 • Ex-proof • with automatic lifting, normal closed • leakproof class 1 to DIN 3230 • operating pressure – 0…25 bar • flanges acc. to DIN 2635 Type: • A – body of cast steel • B – body of stainless steel, non-ferrous free • C – body of cast steel, non-ferrous free Solenoid valves with optical position indicator are available on request. Order No. Size, DN Length, mm Pic. Weight, kg Type A Type B Type C 230 В (AC) 24 В (DC) 230 В (AC) 24 В (DC) 230 В (AC) 24 В (DC) 19 419 19 369 19 429 19 379 – – 15 130 1 5,5 19 420 19 370 19 430 19 380 – – 20 150 1 5,8 19 421 19 371 19 431 19 381 – – 25 160 1 6,5 19 422 19 372 19 432 19 382 – – 32 180 1 11,0 19 423 19 373 19 433 19 383 – – 40 200 1 12,0 19 424 19 374 19 434 19 384 – – 50 230 1 14,0 19 425 19 375 – – 19 435 19 385 65 290 2 36,5 19 426 19 376 – – 19 436 19 386 80 310 2 46,5 19 427 19 377 – – 19 437 19 387 100 350 2 70,0 Accessories 19 388 Extra charge for 2 solenoid switches for contactless electronic indication of position ON/OFF for solenoid valves with flanged DN 15-50, Ex-proof to EEx d IIC T6 19 389 Extra charge for 2 solenoid switches for contactless electronic indication of position ON/OFF for solenoid valves with flanged DN 65-100, Ex-proof to EEx d IIC T6 1 2 G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .89 G Solenoid valve PN 40 • Ex-proof • indirectly actuated, normal closed • power supply 230 V, 50 Hz • operating pressure – 0,5…40,0 bar • body of brass Solenoid valve PN 25 • Ex-proof • with automatic lifting, normal closed • power supply 230 V, 50 Hz • operating pressure – 0,5…25,0 bar • body of brass Order No. Connection female , ” Length, mm Weight, kg 19 401 G ½ 67 0,8 19 402 G ¾ 80 1,2 19 403 G 1 95 1,6 19 404 G 1¾ 132 2,5 19 405 G 1½ 132 3,5 19 406 G 2 160 4,5 19 408 Special voltage 24 V – DC Order No. Connection female , ” Length, mm Weight, kg 19 411 G ½ 67 1,8 19 412 G ¾ 95 4,0 19 413 G 1 95 3,8 19 414 G 1¾ 132 5,3 19 415 G 1½ 132 5,5 19 416 G 2 160 6,6 19 408 Special voltage 24 V – DC 1 2 see next page By-pass valve PN 25 • Angle form • With spring loading • NPT female thread Order No. Type (Corken) Connection NPT, ” Setting ranges, bar Capacity max. l/min Weight, kg Pic. 19 330 B 166 ¾ 3,5…10,5 115 3,5 1 19 331 B 166 1 3,5…10,5 150 3,5 1 19 332 B 166 1 1,7…4,1 150 3,4 1 19 333 B 166 1 6,9…15,5 150 3,5 1 19 337 B 177 1½ 5,0…11,0 380 3,0 19 338 B 166 ¾ 1,7…4,1 115 3,4 1 19 339 B 166 ¾ 6,9…15,5 115 3,6 1 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 90 . • .Order No. Type (Corken) Connection NPT, ” Setting ranges, bar Capacity max. l/min Weight, kg Pic. 19 346 T 166 1½ 6,9…15,5 380 3,5 1 19 348 T 166 1¼ 6,9…15,5 300 3,8 1 19 349 T 166 1½ 3,5…10,5 380 4,0 1 19 350 B 177 2 3,5…8,6 1140 18,8 2 By-pass valve PN 25 Order No. Type (Corken) Connection NPT, ” Setting ranges, bar Capacity max. l/min Weight, kg Pic. 19 354 Т 166 1¼ 3,5…10,5 300 3,8 1 19 355 B 177 1½ 4,1…6,9 570 6,0 2 19 359 B 177 1¼ 5,0…11,0 470 3,8 2 Safety by-pass valve PN 25 • housing gas tight, spring loaded • flanges acc. to DIN 2635/EN 1092-1 • material – cast steel, internal parts – Niro Execution: A – with boot, independent of back pressure B – with O-Ring sealing, dependent on back pressure By-pass valve PN 25 • housing gas tight, spring loaded • dependend on back pressure • with NPT-thread • housing of ASTMA 536 / ductile iron • angle form Order-No. Size, DN Length, mm Height, mm Weight, kg Exec. A Exec. B 19 882 19 302 20 150 275 8,5 19 883 19 303 25 160 275 10,0 19 884 19 304 32 180 275 12,0 19 885 19 305 40 200 275 14,0 19 886 19 306 50 230 360 25,0 19 887 19 307 65 290 360 33,0 19 888 19 308 80 310 495 50,0 19 319 Conversion to spring with other adjustment range acc. to table Order-No. Blackmer type Connection, NPT Adjustment range, bar Capacity, l/min Weight, kg 19 321 BV ¾ ¾” 4,5-7,0 190 2,2 19 322 BV 1 1” 4,5-7,0 190 2,3 19 323 BV 1¼ 1¼” 4,5-8,6 380 3,5 19 324 BV 1¼ 1¼” 7,0-10,5 380 3,5 19 325 BV 1½ 1½” 4,5-8,6 380 3,3 19 326 BV 1½ 1½” 7,0-10,5 380 3,3 19 327 BV 2 2” 4,5-8,6 600 7,6 19 334 Conversion to spring with other adjustment range acc. to table When ordering please specify setting range. Adjustment ranges using different springs in bar: 1,6 – 2,5 2,5 – 4,0 4,0 – 6,3 6,3 – 10,0 10,0 – 16,0 16,0 – 25,0 G LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .91 G Liquid withdrawal valve PN 25 with excess flow valve Type: • A – Standard model • B – with built-in back pressure check valve Order No. Type Inlet, ” Outlet, ” Filling connection Weight, kg 19 341 A8017 DP 1¼ NPT male 1 NPT female – 1,8 19 342 A8017 DH 1¼ NPT male 1 NPT female with back pressure check valve 1,8 19 343 A8018 DP 1¼ NPT male 1 NPT female 1¾ АСМЕ male 1,9 19 344 A8016 DP 1¼ NPT male – 1¾ АСМЕ male 1,4 Multivalve PN 25 for storage tanks • body of brass Order No. Type (RegO) Connection, ” Weight, kg Components: 19 561 8475RV 2½ NPT-IG 5,7 FIller valve 1¾“ ACME, vapor equalizing valve 1¼” ACME, vapour withdrawal valve POL-female, vent valve with dip tube, connection for pressure gauge, flange connection for liquid level gauge, pressure relief valve, connection for dip tube ¾” NPT 19562 8593 AR 16.0 1½ NPT-AG 1,8 Filler valve 1¾” ACME, vapour equalizing valve 1¼” ACME, vapour withdrawal valve POL-female, vent valve with dip tube, connection for pressure gauge, connection for dip tube ¾” NPT Duoport pressure relief valve manifold PN 25 • connection – 2” NPT male • body – of ductile iron ASTM A395 • for 2 external relief valves 1¼” NPT male Type RegO 3135 of brass • without plastic cap Order No. Type RegO Connection, ” Relief valve (quantity) Set pressure, bar Weight, kg 19 571 А8540 2 NPT male – – 4,5 19 572 8542G 2 NPT male 2 2…27 6,8 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 92 . • .G Multiport pressure relief valve manifold PN 25 • ANSI/ASA flanges • body of ductile iron ASTM A395 • for external relief valves 2½” NPT male type RegO A3149 of steel • with plastic cap Type: • A – tank connection 3” ANSI/ASA-flange 300 lbs • B – tank connection 4” ANSI/ASA-flange 300 lbs Order No. Type RegO Relief valve (quantity) Set pressure, bar Weight, kg Type A 19 511 A8563 no safety relief valvee – 32,0 19 569 8530 2 17,2 30,0 19 512 A8563 3 17,2 53,0 19 513 A8564 4 17,2 60,0 19 570 A8532 2 2…21 40,0 19 514 A8563 3 2…21 53,0 Order No. Type RegO Relief valve (quantity) Set pressure, bar Weight, kg 19 515 A8564 4 2…21 60,0 Type В 19 516 A8573 no safety relief valvee – 38,0 19 517 A8573 3 17,2 59,0 19 518 A8574 4 17,2 66,0 19 519 A8573 3 2…21 59,0 19 520 A8574 4 2…21 66,0 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .93 Pressure regulators • Safety shut off valves H Regulator PN 25, middle pressure • with ¼” NPT lateral connection for pressure gauge • admission pressure – up to 16 bar Order No. Type (RegO) Back pressure, bar Connection NPT, ” Capacity up to Weight, kg 16 001 1584VL 0,4…3,5 ½ 80 kg/h 0,9 16 002 AA1584VL ½ 45 m3 /h (NH3 ) 0,7 16 003 1586VL ¾ 160 kg/h 1,4 16 004 AA1586VL ¾ 70 m3 /h (NH3 ) 1,4 16 005 1588VL 1 160 kg/h 1,3 16 007 1584VH 0,4…8,5 ½ 80 kg/h 0,9 16 008 1588VH 1 160 kg/h 1,3 Regulator PN 25 middle pressure • with ¼” NPT lateral connection for pressure gauge (suitable for liquid or vapor service) • admission pressure – up to 16 bar • capacity – up to 80 kg/h Regulator PN 16 middle pressure • with 1 /8“ NPT IG lateral connection for pressure gauge • admission pressure – up to 16 bar Order No. Fisher Type Connection NPT, ” Back pressure, bar Weight, kg 16 011 627-7710 1 0,3…2,5 2,2 16 012 630-104/78 2 2,0…4,0 15,8 Order No. RegO Type Connection NPT, ” (inlet/outlet) Back pressure, bar Capacity, kg/h Weight, kg 28 876 LV 3403 TR ¼ / ½ 0,7 32 1,30 29 058 LV 3403 VR ¼ / ½ 1,5 45 0,57 H ENERGY • SAFETY • COMPETENCE LPG 2019-2020 94 . • .Regulator PN 25, low pressure • compact two-stage regulator • with integral relief valve • connection for pressure tap ¾” NPT or ¼” NPT • admission pressure – up to 16 bar Order No. Type Connection NPT, ” Back pressure, mbar Capacity, kg/h Weight, kg Inlet Outlet 16 019 Fisher R 532BCG ¼ ½ 25…50 15 0,9 16 020 Fisher R 532CFG ¼ ¾ 0,9 16 021 RegO LV404H420 ¼ ½ 11 1,6 16 022 RegO LV404B46H20 ¼ ¾ 1,6 28 000 RegO LV404B46 ¼ ¾ 22,8…33 1,6 Order No. Type Fisher Connection NPT, ” Back pressure, bar Capacity, kg/h Weight, kg 16 015 627-7710 1 0,4…1,4 230 2,2 16 116 630-104/78 2 0,6…1,4 300 15,8 Regulator PN 25, middle pressure • with lateral connection for vent line H LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .95 H Regulator PN 25, middle pressure • admission pressure – up to 16 bar • back pressure – 1,5…2,0 bar • capacity – up to 24 kg/h Order No. Connection Weight, kg Inlet Outlet 16 023 POL G 3 /8 male 0,70 16 024 POL Ring 12 mm 0,60 16 025 POL Ring 15 mm 0,63 Regulator PN 2,5, low pressure • admission pressure up to 2,5 bar • back pressure – 50 mbar Further regulators are available on request Order No. Type RegO Connection NPT, ” Capacity, kg/h Inlet Weight, kg Outlet 16 013 LV 5503 H620 ¾ ¾ 25 1,30 16 014 LV 5503 B4H20 ½ ¾ 25 1,30 16 017 LV 4403 H4620 ½ ¾ 20 1,30 16 018 LV 4403 H420 ½ ½ 12 1,30 28 300 LV 4403 H414 ½ ½ 14 1,40 Regulator PN 2,5, low pressure • with integral relief valve • connection for pressure tap ¾“ NPT • admission pressure – up to 2,5 bar Order No. Type (Fisher) Connection, ” Capacity, kg/h Weight, kg Capacity – up to 40 kg/h 16 031 R422 CDG ¾ NPT 25…100 2,36 16 032 R522 H-DFJ ¾ NPT 450…700 2,50 Capacity – up to 20 kg/h, connection for pressure tap ¼” NPT 16 033 R522 CFG ½ NPT (Inlet) ¾ NPT (Outlet) 20…70 1,20 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 96 . • .Regulator PN 2,5, low pressure • with integral relief valve • connection for presure tap ¾“ NTP • admission pressure – up to 1,7 bar • back pressure – 35…70 mbar • capacity – up to 45 kg/h Regulator PN 2,5, low pressure • with integral relief valve • connection for presure tap ¾“ NPT • admission pressure – up to 1,0 bar • back pressure – 35-70 mbar • capacity – up to 150 kg/h Order No. Type (Fisher) Connection NPT, ” Weight, kg 16 041 S102 L-BFC ¾ 2,27 16 042 S102 L-CFC 1 2,27 16 043 S102 L-FFC 1¼ 2,27 16 044 S102 L-KFC 1½ 2,27 Order No. Type (Fisher) Connection NPT, ” Weight, kg 16 047 S302 G-FMJ ¼ 3,80 16 048 S302 G-SMJ 2 4,17 Regulator PN 2,5, low pressure • with integral relief valve • connection for presure tap 1“ NPT • admission pressure – up to 0,9…1,7 bar • back pressure – 30-70 mbar Order No. Type (Fisher) Connection NPT, ” Capacity, kg/h Weight, kg 16 051 S202 G-BNC 1½ 180 10,9 16 052 S202 G-СNC 2 280 10,9 H LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .97 H Regulator PN 25, • admission pressure – up to 25 bar • capacity – up to 12 kg/h Tank-regulator combination • 1. And 2. Stage, consisting of: middle pressure regulator (1.Stage) with emergency shut-off valve (SAV) • Low pressure regulator (2. Stage) with relief valve with connection for pres – sure tap (SBV) with emergency supply connection and check plug Order No. Connection Back pressure, mbar Weight, kg Inlet Outlet 16 060 POL G ¾ female 50 2,9 16 223 POL R ¾ female 30 3.2 Regulator low pressure (2. Stage) • emergency shut-off valve (SAV) • connection for pressure tap (SBV) • admission pressure – up to 25 bar Order No. PN Capacity, kg/h Connection, ” Back pressure, mbar Weight, kg Inlet Outlet 16 065 2,5 12 G ½ female G ½ female 50 1,7 16 066 2,5 24 G ¾ female G ¾ female 50 2,0 16 067 4,0 60 G ¾ female G ¾ female 50 2,4 16 224 2,5 12 G ½ female G ½ female 30 2,5 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 98 . • .Regulator PN 40 middle pressure (1. Stage) • emergency shut-off valve (SAV) • connection for pressure tap (SBV) • admission pressure – up to 25 bar • with device male ainst freezing • emergency supply connection • admission pressure – up to 25 bar • capacity – up to 24 kg/h Order No. Back pressure, bar Connection Weight, kg Inlet Outlet 16 027 2,0 POL G ½ female 3,1 16 028 0,7 POL G ½ female 2,6 Regulator PN 40 middle pressure (1. Stage) • connection for pressure tap (SBV) • admission pressure – up to 25 bar • emergency supply connection • pressure gauge • admission pressure – up to 25 bar • capacity – up to 60 kg/h Order No. Back pressure, bar Connection Weight, kg Inlet Outlet 16 029 0,7…2,0 POL G ¾ female 3,3 16 069 0,7…2,0 G ½ female G ¾ female 3,3 Regulator PN 40 middle pressure (1. Stage) • Flanges acc. to DIN 2635 • Body of steel GS-C25 • Admission pressure – up to 16 bar • Back pressure – 0,7…7,0 bar • Set pressure – 1,5 bar (standard version) Order No. Size, Weight, kg 16 101 DN25 11,0 H LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .99 H Regulator PN 25 middle pressure (1. Stage) • emergency shut-off valve (SAV) • connection for pressure tap (SBV) • admission pressure – up to 25 bar • pressure gauge Emergency shut-off valve (SAV) PN 25, adjustable • also with diaphragm-fracture protection • material – cast iron GGG 40 Order No. Stage connection, DN Stage Setting range, bar Factory setting, bar Dimensions, mm Weight, kg Length Height 16 111 DN 25 PN 16 0,05…0,25 0,10 160 240 11,0 16 112 DN 50 0,10 230 245 16,0 16 113 DN 80 0,10 310 285 26,0 16 115 DN 25 0,20…0,80 0,50 160 240 11,0 16 116 DN 50 0,50 230 245 16,0 16 117 DN 80 0,50 10 285 26,0 16 119 DN 25 PN 40 0,60…6,60 3,00 160 240 11,0 16 120 DN 50 3,00 230 245 16,0 16 121 DN 80 3,00 310 285 26,0 Order No. Inlets pressure, bar Back pressure, bar Capacity, kg/h Connection, ” Weight, kg Inlet Outlet 16 081 1,5…16 0,8 100 G1 female G1 female 4,0 16 082 2,5…16 1,5 150 G1 female G1 female 4,0 16 083 3,8…16 2,8 150 G1 female G1 female 4,0 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 100 . • .H Regulator PN 4, low pressure (2. Stage) • flange connection acc. to DIN 2633 • body of cast iron GGG 40 and GD-AL Si 12 • inlet pressure – 0,35…4,00 bar • operating temperature – 15 to +60°C • emergency shut-off valve • capacity – size DN 25 up to 70 kg/h; size DN 50 up to 520 kg/h Type: • A – with emergency shut-off valve for upper limit switch • B – with emergency shut-off valve for upper and lower limit switches and relief valve, relief valve connection for pressure tap, vent pressure permanently set 30 mbar above outlet pressure Order No. Size, DN Back pressure, mbar Factory setting, mbar Connection, ” Length, mm Weight, kg Type A Type B 16 135 16 139 25 35…140 50 G ¾ 160 6,0 16 136 16 140 25 70…280 150 G ¾ 160 6,0 16 137 16 141 25 140…420 300 G ¾ 160 6,0 16 156 16 161 50 30…70 50 G 1 200 14,0 16 157 16 162 50 70…140 100 G 1 200 14,0 16 159 16 164 50 140…300 200 G 1 200 14,0 16 158 16 163 50 210…450 250 G 1 200 14,0 – 16 144 50 30…450 300 G 1″ 200 14,0 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .101 Safety relief valves I Safety relief valve • spring-loaded relief valve • thread connection • plastic protection cap • body of brass Order No. Type (RegO) Connection Total height, mm Hexagon size, mm Flow capacity, m3 / min Adjusted at (bar) Weight, kg 28 301 RS3131 ¾” M.NPSM 85 46 48,9 17,2 1,0 28 303 RS3132 1” M.NPSM 129 60 77,5 17,2 1,0 28 305 RS3135 ¼” M.NPSM 141 68 118,0 17,2 1,0 28 382 RS3145 M45×2 139 68 187,2 15,6 1,0 28 869 RS3136 M36×2 135 60 134,3 15,6 1,0 28 875 RS3136 M36×2 135 60 134,3 17,0 1,0 90 904 RS3145 M45×2 139 68 187,2 17,0 1,0 Check device for safety relief valves • for exchange of relief valves without emptying of tank • seal • body of brass Order No. Type (RegO) Valve type Internal thread External thread Total height, mm Hexagon size, mm Weight, kg 28 306 CD35 RS3135 1¼” F.NPSM 2” M.NPT 59 62 0,5 28 387 CD31 RS3131 ¾” F.NPSM 1¼” M.NPT 59 46 0,5 28 388 CD32 RS3132 1” F.NPSM 1¼” M.NPT 59 46 0,5 28 389 CD45 RS3145 M45×2 2” M.NPT 59 62 0,5 28 854 CD36 RS3136 M36×2 1¼” M.NPT 58 52 0,5 I ENERGY • SAFETY • COMPETENCE LPG 2019-2020 102 . • .Order No. Type RegO Connection NPT, ” Pressure range (bar) Material Pic. Weight, kg 15 281 RegO 3127 ¼ 3…44 Brass 1 0,1 15 291 RegO SS8001 ¼ 10…31 Stainless steel 0,1 15 292 RegO SS8002 ½ 10…31 15 282 RegO 3129 ½ 4…31 Brass 0,1 15 293 RegO SS8021 ¼ 10…31 Stainless steel 0,1 15 294 RegO SS8021 ½ 10…31 0,1 15 284 RegO 3131 ¾ 2…27 Brass 2 0,5 15 287 RegO W3132 1 3…34 1,2 15 288 RegO 8684 1 12…21 3 0,6 15 289 RegO 8685 1¼ 7…20 1,0 15 311 RegO 3132 1¼ 2…27 2 1,3 15 285 RegO 3135 1¼ 7…19 1,5 15 312 RegO 3133 1½ 6…19 2,1 15 314 RegO 7573 2 6…31 3 4,4 15 315 Fisher H280/H281… 2 10…25 4,2 15 316 RegO А8434 Fisher H720/H721 2 10…25 Steel 4 2,1 15 286 RegO A3149 2½ 2…21 2 7,2 15 317 RegO А8436 Fisher H730/H731 3 10…25 5 5,2 Safety relief valves for pipelines, mobile and stationary tanks, multivalves and duoports • without protection cap Please indicate the required setting pressure when placing your order. Valves 15281, 15291 and 15292 – without threaded connection for vent piping. Order number is depending on setting pressure. 1 2 3 4 5 I LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .103 I Protective cap for relief valve Order No. Ventil Type For relief valve type Material Weight, kg 15 403 RegO 3131-40 RegO 3131 Rubber 0,01 15 405 RegO 7545-40 RegO 3127, 3129 0,05 15 406 RegO 3132-40 RegO 3132 Steel 0,15 15 407 RegO 7534-40 RegO 7534 Rubber 0,37 15 408 RegO 7584-40 RegO 8684 0,09 15 409 RegO 7585-40 RegO 8685 0,14 15 411 Fisher P297 Fisher H720/721 0,10 15 412 Fisher P298 Fisher H730/731 0,15 15 413 RegO A8434-11B RegO A8434 0,31 15 414 RegO A8436-11B RegO A8436 0,10 15 415 RegO 3133-40 RegO 3133 0,05 15 416 RegO 3149-40 RegO A3149 0,10 15 417 RegO 3135-40 RegO 3135 0,10 15 401 – SV-A 12/A 22/A 23/A 24/A 26/12ES/14ES/16 ES, SV 805 Plastics 0,01 15 404 – SV-A 3 0,01 15 410 – SV 486, SV 741 0,09 Adaptor for attachment of vent piping Order No. Type RegO For safety relief valve Material Connection, ” Pic. Weight, kg 15 331 3129-10 RegO 3129 Brass ½ NPT female 1 0,06 15 334 7534-20 RegO 7534 3 NPT female 2 1,00 15 336 3132-10 RegO 3132 1¼ NPT female 1 0,20 15 328 3131-10 RegO 3131 1 NPT female 0,20 15 329 3133-10 RegO 3133 2 NPT female 0,50 15 330 3135-10 RegO 3135 2 NPT female 0,40 15 332 – SV-A 12, A 22, A 23 SV-A 24, A 26, SV 805 ½ NPT female 3 0,06 15 333 – SV 486 Rp 1½ female 4 0,20 15 335 – SV-A 3 Rp 1½ female 3 0,30 15 337* – SV-A 12ES, A 14ES, SV-A 16ES, SV 805 Stainless steel ½ NPT female 0,06 15 338* – SV-A 12ES, A 14ES Steel, galvanized ½ NPT female 0,06 1 2 3 4 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 104 . • .Excess flow valves • Back pressure check J valves Excess flow valve PN 25 • NPT-thread see next page Order No. Type Connection, ” Closing flow Weight, kg Pic. Inlet NPT Outlet NPT Liquid, approx. l/min Vapor, approx. Nm3 /h at 1,7 bar at 7,0 bar 12 001 1519 A2 1 1 95 140 250 1,54 1 12 002* A1519 A2 1 1 95 140 250 2,50 1 12 003 1519 A3 1 ½ 1½ 225 325 570 1,54 1 12 004 1519 B4 2 2 510 784 1420 2,50 1 12 031 1519 A4 2 2 378 512 925 2,50 1 12 005* A1519 B4 2 2 510 784 1420 2,50 1 12 006* A1519 A6 3 3 850 1270 2350 5,27 1 12 007* FAS 3 3 1190 1780 3290 5,50 1 12 008 1519 C2 1½ male /1 G 1 female 95 140 250 1,10 2 12 009 – 3 male 3 male /2 female 985 1400 2385 4,50 3 12 010* A2137 A 2 male /1¼ female 2 male /1¼ female 265 396 707 1,60 3 12 011 2139 A 3 male /2 female 3 male /2 female 620 750 1300 4,50 3 12 032 12472 ¾ ¾ 15 20 35 0,15 4 1 2 3 4 5 6 9 7 8 J LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .105 J Order No. Type Connection, ” Closing flow Weight, kg Pic. Inlet NPT Outlet NPT Liquid, approx. l/min Vapor, approx. Nm3 /h at 1,7 bar at 7,0 bar 12 012 3272 E ¾ ¾ 30 40 75 0,18 4 12 041 3272 F ¾ ¾ 48 77 135 0,15 4 12 013 3272 G ¾ ¾ 76 105 195 0,18 4 12 014* A3272 G ¾ ¾ 76 105 195 0,18 4 12 042 3282 A 1¼ 1¼ 110 145 270 0,36 4 12 015 3282 C 1¼ 1¼ 190 255 461 0,36 4 12 016* A3282 C 1¼ 1¼ 190 255 461 0,40 4 12 017 7574 1½ 1½ 340 430 795 0,68 4 12 018 3292 B 2 2 378 512 925 1,04 4 12 019* A3292 C 2 2 462 625 1064 1,27 4 12 046* A3500 L4 2 – 290 435 650 0,90 6 12 047* A3500 N4 2 – 480 650 1170 0,90 6 12 022* A3500 P4 2 – 568 863 1470 0,90 6 12 023* A3500 R 3 – 568 908 1570 1,86 6 12 048* A3500 T6 3 – 770 1024 1850 1,86 6 12 024* A3500 V6 3 – 950 1446 2510 1,86 6 12 025* A4500 Y8 4 – 1890 2518 4360 3,31 6 12 028* A8523 ¾ ¾ 57 146 250 0,23 5 12 043* A8525 ¼ 1¼ 134 290 525 0,60 5 12 044* A7537 L4 2AG 2 male /1¼ female 284 432 735 0,60 5 12 029* A7537 P4 2AG 2 male /1¼ female 568 863 1470 1,54 5 12 030* A7539 V6 3AG 3 male /2 female 946 1446 2150 4,68 5 For pressure gauge 12 038 2884 D ¾ ¼ – – – 0,13 7 Check-Lock 12 033 7572 FС ¾ ¾ 75 – – 0,23 8 12 034 7580 FС 1¼ ¾ 132 – – 0,50 8 Check-Lock adaptor 12 037 7572 С-14A ¾ ¾ – – – 0,10 9 The indicated vapor closing flows refer tot he normal condition of 15°C and 762 torr. ENERGY • SAFETY • COMPETENCE LPG 2019-2020 106 . • .Excess flow valve PN 40 type FAS-F, for installation between two flanges • body and spring of stainless steel Type: • A – Standard execution • B – With stronger spring Order No. Size, ” Suitable for flanges Closing flow propane, approx. l/min Dimensions Weight, kg Type А A B C D 12 069 1¼ DN 32 90 30 10 60 75 0,6 12 070 1 DN 25 45 25 10 43 68 0,3 12 071 2 DN 50 167 48 13 85 92 0,9 12 072 2½ DN 65 224 60 13 94 105 1,3 12 073 3 DN 80 378 76 13 96 127 1,8 12 074 1½ DN 40 125 36 13 70 80 0,8 12 075 4 DN 100 791 97 16 118 157 3,3 12 076 5 DN 125 1257 121 16 151 186 5,0 12 077 6 DN 150 1764 142 19,6 183 216 8,4 12 078 8 DN 200 2388 190 20 211 270 12,9 12 079 10 DN 250 4035 245 22,5 285 323 23,7 Order No. Size, ” Suitable for flanges Closing flow propane, approx. l/min Dimensions Weight, kg Type В A B C D 12 081 2 DN 50 208 48 13 85 92 0,9 12 082 2½ DN 65 435 60 13 94 105 1,3 12 083 3 DN 80 606 76 13 96 127 1,8 12 085 4 DN 100 1287 97 16 118 157 3,3 12 086 5 DN 125 1567 121 16 151 186 5,0 12 087 6 DN 150 2911 142 19,6 183 216 8,4 12 088 8 DN 200 3217 190 20 211 270 12,9 12 089 10 DN 250 6185 245 22,5 285 323 23,7 The minimum flow rate should be twice as high as the maximum pumping capacity J LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .107 J Order No. Type Connection NPT Capacity l/min. at 0,7 bar Material Weight, kg Pic. 12 501 3146 ¾ 60 Brass 0,18 1 12 502* A3146 ¾ 60 Steel 0,23 1 12 503 3176 1¼ 150 Brass 0,36 1 12 504* A3176 1¼ 150 Steel 1,00 1 12 505 6586 C 2 1020 Brass 0,90 2 12 506* A3186 2 662 Steel 1,27 1 12 507* A3196 3 1600 2,81 1 12 508* A6586 C 2 1020 1,02 2 12 509* A3400 L4 2 1200 1,00 3 12 510* A3400 L6 3 2300 1,90 3 28 819 A3187 S 2 416 1,20 4 28 896 A3198 S 2 1098 4,60 5 Order No. Size, DN Length, mm Height, mm Weight, kg 12 511 15 130 66 3,6 12 512 20 150 75 4,5 12 513 25 160 80 5,5 12 514 32 180 88 8,0 12 515 40 200 105 11,5 12 516 50 230 115 14,0 12 517 65 290 135 23,0 12 518 80 310 145 30,0 12 519 100 350 175 47,0 12 520 125 400 215 70,0 12 521 150 480 240 96,0 Back pressure check valve PN 40 • flange connection acc. to DIN 2635 • body of cast steel GS-C25 • disc of stainless steel Back pressure check valve PN 25 • with NPT-thread • metallic sealed • sitting position variably 1 2 3 5 4 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 108 . • .J Back pressure check valve PN 40 • for installation between two flanges • soft seal Order No. Size, DN Length, мм Weight, kg Type A Type B Type C 12 531 12 541 12 561 15 16 0,12 12 532 12 542 12 562 20 19 0,18 12 533 12 543 12 563 25 22 0,29 12 534 12 544 12 564 32 28 0,50 12 535 12 545 12 565 40 32 0,66 12 536 12 546 12 566 50 40 1,23 12 537 12 547 12 567 65 46 1,55 12 538 12 548 12 568 80 50 2,35 12 539 12 549 12 569 100 60 3,63 Type: • A – housing material 1.4317, soft seal made of viton, for propane / butane • B – housing material 1.4317, soft seal made of viton, for propane / butane, with type approval • C – housing material 1.4552, with PTFE-special seal for DME, refrigerant and NH3 , with type approval LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .109 Filler valve PN 25 • brass • with double back pressure check valve • brass cap • one-piece housing Order No. Type Dimensions, ” Weight, kg Pic. Inlet Outlet 13 000 70321 1¾ ACME ¾ NPT 0,4 1 13 006 481 1¾ ACME 1¼ NPT 0,5 1 Order No. Type Dimensions, ” Weight, kg Pic. Inlet Outlet 13 001 7547 BС 1¾ ACME ¾ NPT 0,4 1 13 002 7579 С 1¾ ACME 1¼ NPT 0,6 2 13 003 6579 C 1¾ ACME 1¼ NPT 0,6 2 13 004 6587 EC 2¼ ACME 2 NPT 2,3 3 13 005 3197 C 3¼ ACME 3 NPT 6,5 3 Filler valve PN 25 • brass • with double back pressure check valve • brass cap • one-piece housing Filler valve PN 25 • brass • with single back pressure check valve • brass cap • one-piece housing Filling valves • Quick-acting filling valves • Unloading adaptor • Safety breakaway K couplings • Fittings Order No. Type Dimensions “ Weight, kg Pic. Inlet Outlet 13 008 6584 C 2¼ ACME 2 NPT 1,4 4 13 009 3194 C 3¼ ACME 3 NPT 4,3 4 1 2 3 4 K ENERGY • SAFETY • COMPETENCE LPG 2019-2020 110 . • .1 2 3 Vapor equalizing valve PN 25 • brass • excess flow valve • brass cap Vapor equalizing valve PN 25 • brass • excess flow valve Order No. Type Dimensions ” Weight, kg Pic. Inlet Outlet 13 011 7573 AC 1¼ ACME ¾ NPT 0,3 1 13 012 3183 AC 1¾ ACME 1¼ NPT 0,9 2 13 013 FAS 2¼ ACME 2 NPT 2,5 – 13 077 ¹ 7573 D 1¼ ACME ¾ NPT 0,2 – 13 069 ¹ 3183 AC 1¾ ACME 1¼ NPT 0,8 3 Order No. Type Dimensions ” Weight, kg Inlet Outlet 13 015 FAS 2¼ ACME 2 NPT 1,4 Quick-Acting shut-off valve PN 25 • housing of ductile iron – ASTM A395 Quick-Acting valve PN 25 • material steel • with safety filling device • closing position with lock • suitable for LPG and ammonia Order No. Type Execution Inlet ” Outlet ” Weight, kg 13 021* A7708 L Angular 1 NPT 1 NPT 1,6 13 022* A7707 L Straight 1 NPT 1 NPT 1,7 Order No. Type RegO Execution Inlet Outlet Weight, kg 13 0351 A7793A angle form ¾” NPT 1¾” ACME 2,9 13 035 A7797A angle form 1” NPT 2,8 Safety filler coupling PN 25 • brass • back pressure check valve Order No. Inlet NPT, “ Outlet ACME, “ Length, мм Weight, kg 13 025 1 NPT 1¾ ACME 120 1,5 13 026 ¾ NPT 1¾ ACME 59 0,3 K LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .111 K Order No. Type Inlet Outlet Weight, kg 13 018 RegO/FAS 1 NPT female 1¾ ACME 2,9 13 031 RegO/FAS 2,9 13 037 LG/FAS ¾ NPT female 2,0 13 038 LG/FAS M 30×1,5 left male 2,0 13 023 LG/FAS ¾ NPT female 2,0 13 024 LG/FAS M 30×1,5 links male 2,0 13 086 Nettuno T4 G1 female Clamp 1,4 13 039 Nettuno T3 Clamp 1,4 13 516 DV-V10 (NL) ¾ NPT female Bajonett 1,6 13 529 LG/FAS DISH 2,0 13 200 LG/FAS EUROPA Connection 2,0 13 498 Nettuno R 1 G1 female Clamp 1,4 Nozzle PN 25 • with safety filler coupling • back pressure check valve Other quick-acting shut-off valves for other countries, adaptors or connections on request. Nozzle RegO/FAS Nozzle LG/FAS Nozzle LG/FAS Nozzle Nettuno with outlet DISH ENERGY • SAFETY • COMPETENCE LPG 2019-2020 112 . • .Coupling PN 25 for filler valve Order No. Type Dimensions Material Weight, kg Type A Type В А В 13 050* 13 280* А3175 ¾ NPT 1¾ ACME Steel 0,35 13 051 – 3175 В ¼ NPT 1¾ ACME Brass 0,40 13 052 – 3175 ¾ NPT 1¾ ACME Brass 0,35 13 053 – 3175 A 1 NPT 1¾ ACME Brass 0,32 13 054* 13 281* A3175A 1 NPT 1¾ ACME Steel 0,36 13 055 – 3185 1¼ NPT 2¼ Brass 0,77 13 056* 13 282* A3185 1¼ NPT 2¼ Steel 0,73 13 057 – 3195 2 NPT 3¼ ACME Brass 1,95 13 058* 13 283* A3195 2 NPT 3¼ ACME Steel 1,95 13 059* 13 284* FAS 3 NPT 3¼ ACME Steel 2,90 13 060* 13 285* FAS 3 NPT 4¼ ACME Steel 3,45 Type: • A – standard type • B – hose coupling *Single ACME union nuts are available on request Coupling PN 25 • with back pressure check valve • brass Order No. Type Dimensions Pic. Weight, kg Inlet Outlet 13 061 7141 F 1¼ ACME female ¼ NPT female 1 0,20 13 062 7141 M 3/8 NPT female 1¼ ACME male 2 0,20 13 068 7193L-10A 1¼ ACME female ¼ ACME male 3 0,85 1 2 3 Coupling PN 25 for vapor equalizing valves •brass Order No. Type Dimensions ” Weight А В 13 064 3171 A ½ NPT 1¼ ACME 0,17 13 065 3181 ¾ NPT 1¾ ACME 0,29 13 066 3181 A 1 NPT 1¾ ACME 0,34 13 067 3191 1¼ NPT 2¼ ACME 0,85 K LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .113 K Coupling PN 25 • both sides with ACME-male thread Order No. Type Dimensions Material Weight, kg 13 071 FAS 1¼ ACME Brass 0,14 13 072 5765 M 1¾ ACME Brass 0,36 13 073 5767 M 2¼ ACME Brass 0,59 13 074 5769 M 3¼ ACME Brass 1,35 13 075 FAS 4¼ ACME Steel 3,86 Reducer-coupling PN 25 • both sides with ACME-connection Order No. Type Dimensions ” Material Weight, kg A – male B – female 13 078 FAS 1¾ ACME 2¼ ACME Brass 0,73 13 079 A5776 1¾ ACME 3¼ ACME Steel 2,27 13 080 FAS 3¼ ACME 4 ¼ ACME Steel 3,45 Cap plug PN 25 • with chain Order No. Type Dimensions Material Weight, kg 13 091 FAS-1 1¼ ACME Brass 0,10 13 092 FAS-2 1¾ ACME Brass 0,15 13 093 FAS-3 1¾ ACME Steel 0,36 13 094 3184-90 2¼ ACME Brass 0,86 13 095 A3184-90 2¼ ACME Steel 0,82 13 096 3194-90 3¼ ACME Brass 1,92 13 097 A3194-90 3¼ ACME Steel 1,95 13 098 FAS-4 4¼ ACME Steel 2,95 13 099 3144-91 1¼ ACME Plastics 0,10 13 100 3174-93 1¾ ACME Plastics 0,10 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 114 . • .Filler hose adaptor PN 25 • for installation between inner tube valve and filler valve • vent valve Type: • A – standard type of brass • B – with ball valve of steel, connection parts of brass Order No. Type Inlet, ” Outlet, ” Length, мм Pic. Weight, kg Type A 13 111 7577V 1¾ ACME female 1¾ ACME male 85 1 0,60 13 107 FAS 1¾ ACME female 1¾ ACME male 97 1 0,60 Type B 13 110 FAS 1¾ ACME female 1¾ ACME male 170 2 1,50 Order No. Type Inlet, ” Outlet, ” Form Pic. Weight, kg 13 112 FAS 1¾ ACME female 1¾ ACME male Angular 1 1,00 13 113 3119A 1¾ ACME female 1¾ ACME male Straight 2 1,20 13 114 M450A 1¾ ACME female 1¾ ACME male Angular 1 1,05 13 115 FAS 1¾ ACME female ¾ NPT female Eckform 1 0,90 Unloading adaptor PN 25 for descharging of LPG tanks 1 2 d D s Order No. Connection Dimensions, мм D d s 13 121 1 ¼ ACME 23 13 3 13 122 1 ¾ ACME 34 23 3 13 123 2 ¼ ACME 46 36 3 13 124 3 ¼ ACME 72 54 3 13 125 4 ¼ ACME 94 73 3 Seal PN 40 for filling fittings Spanner wrench for ACME-coupling Order No. Type Size of jaw, ” Weight, kg 13 126 Р120В 2¼, 3¼, 4¼ 0,52 13 127 3195-50 2¼, 3¼ 0,45 Other types of spanner wrenches for other sizes on request K LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .115 K Safety breakaway coupling PN 40 for loading arms • flanges acc. to DIN 2635 • entirely of stainless steel • no welds • both valves sealed when separated • disconnecting over pull cable and shear pin mechanism Type: • A – Viton O-rings for propane / butane (LPG) • B – O-rings (PTFE encapsulated) for ammonia (NH3 ) Models with seals suitable for other products are available on request Order No. Type Size, DN Type А Type В Length, mm Weight, kg 13 171 13 173 ERC 2” 50 200 18,0 13 172 13 174 ERC 3 ” 80 360 30,0 Pull cable activating mechanism with fastening elements Order No. Execution 13 181 Cable length in accordance to project specifications Spare parts kit with shear pins and O-rings Order No. Execution Type А Type B 13 191 13193 for DN 50 13 192 13194 for DN 80 Safety breakaway coupling for hoses PN 25 breakaway protection for high-pressure LPG hoses • thread connections • both halves sealed when separated Order No. Type Connection A+B, ” Length, mm Material Weight, kg 13 131 ARK19 ¾ NPT female 90 Red brass 0,8 13 132 A2141A6L ¾ NPT female 98 Steel 0,6 13 133 A2141A8L 1 NPT female 115 Steel 1,4 13 134 A2141A10 1 NPT female 142 Alu 2,2 13 135 A2141A16 2” NPT female 363 Alu 11,3 13 208 FAS ¾ NPT female 155 Steel 1,2 Breakaway coupling for hose LPG 19 13 105 Walther ¾ NPT female 163 Stainless steel 1,3 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 116 . • .Safety breakaway coupling for cars dispensers PN 25 • housing from brass • to protect the pipe line in case of accidental, accident-related demolition of dispenser, • valve self-closing, in separated position closed on both sides, release by shell with breaking point, • not reusable after draw Safety breakaway coupling for trucks – LPG dispensers PN 25 • housing from brass; completely with 2 pcs. • clamping jaws made of alu • for correct installation on ground frame of dispenser • further features as described before Commitment purposes acc. to DIN EN 14678-1 Point 4.4.1.2 Documentation: GIP, Type SBK with DVGW-test Documentation: Declaration of Conformity acc. to ATEX-guidelines Order-No. Type Length, mm Inlet /Outlet, NPT Capacity, l/min Breaking moment, N•m Weight, kg 13 7200 SBK 127 ¾” IG / ¾” IG 40 565 0,81 Order-No. Type Length, mm Inlet / Outlet, NPT Capacity, l/min Breaking moment, N•m Weight, kg 13 723 RIS-ShearLPG1 160 1” AG / 1” IG up to 130 420 1,13 Order-No. Size, DN Connection-Flange Length, mm Weight, kg Mann Tek-DGC / male part (tank connection) 13 9145 25 25 (DIN 2635) 75 1,4 13 9146 50 50 (DIN 2635) 81 3,5 13 9147 80 80 (DIN 2635) 112 5,5 13 9125 25 1” (ANSI / 300 lbs) 75 1,5 13 912 50 2” (ANSI / 300 lbs) 81 3,2 13 913 80 3” (ANSI / 300 lbs) 112 5,5 13 9153 25 1” (NPT IG) 77 0,7 13 915 50 2” (NPT IG) 102 1,0 13 916 80 3” (NPT IG) 144 3,0 Mann Tek-DGC / female part (hose connection) 13 9140 25 25 (DIN 2635) 169 3,4 13 9117 50 50 (DIN 2635) 218 6,0 13 9118 80 80 (DIN 2635) 267 13,2 13 9119 25 1” (ANSI / 300 lbs) 168 3,4 13 9111 50 2” (ANSI / 300 lbs) 218 5,7 13 9113 80 3” (ANSI / 300 lbs) 263 13,3 13 8010 25 1” (NPT IG) 133 1,9 13 911 50 2” (NPT IG) 155 2,9 13 9121 80 3” (NPT IG) 194 8,1 Quick-acting dry breakaway coupling PN 25 for loading / unloading of rail / road tankers • body of stainless steel 1.4408 • with NBR flat compression seals; with cam lever Type: A – male part; B – female part In coupled position (thread execution) Male part Female part K LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .117 K Safety breakaway coupling for hoses PN 25 • type approval • flanges acc. to DIN 2635 • stainless steel • no pressure-containing welds • Viton O-Rings • disconnects using 3 break pins • max. angle of traction – 90° Order No. Type, ” Size, DN Length, mm Material Standard breakload, kN Weight, kg 13 150 APC 1½ 25 163 Niro – 4,0 13 151 ¹ APC 1½ 32 163 Niro 6,99 5,0 13 152 APC 1½ 40 163 Niro – 6,0 13 153 ¹ APC 2½ 50 200 Niro 14,98 12,0 13 154 ¹ APC 2½ 65 200 Niro 14,98 13,0 13 156 ¹ APC 3 80 360 Niro 30,62 24,0 13 157 АРС 4 100 340 Niro – 38,0 13 158 APC 4 125 340 Niro – 45,0 13 159 APC 6 150 380 Niro – 100,0 13 160 APC 8 200 640 Niro – 195,0 13 140 Steel safety cable with fastening elements Breakspade kit with viton O-rings 13 161 for DN 25, DN 32 and DN 40 (1½ ”) 13 162 for DN 50 and DN 65 (2½ ”) 13 164 for DN 80 (3”) 13 163 for DN 80 (4”), DN 100 and DN 125 (4”) 13 165 for DN 150 (6”) 13 166 for DN 200 (8”) 13 197 Torque wrench with 2 nuts, setting range 4…12 N•m Type approval is only valid during standard pulloff strength operation, other pull-off strengths are available on request. ENERGY • SAFETY • COMPETENCE LPG 2019-2020 118 . • .Strainers • Traps • Fine filters • Methanol L dewatering equipment Strainer PN 40 • body of steel • Y-type • flange connection acc. to DIN 2635 • inner screen of stainless steel Type: • A – standard type • B – with fine-mesh screen, mesh size 0,25 mm Other sizes and strainers in nominal pressure PN 16, or with ANSI flanges are available on request. Order No. (type А) Size, DN Length, mm Mesh size, mm Weight, kg 14 001 15 130 0,60 2,0 14 002 20 150 3,0 14 003 25 160 4,0 14 004 32 180 6,0 14 005 40 200 8,0 14 006 50 230 11,0 14 007 65 290 1,20 15,0 14 008 80 310 24,2 14 009 100 350 28,0 14 010 125 400 44,0 14 000 150 480 62,0 Order No. (type B) Size, DN Length, мм Mesh size, mm Weight, kg 14 011 15 130 0,25 2,0 14 012 20 150 3,0 14 013 25 160 4,0 14 014 32 180 6,0 14 015 40 200 8,0 14 016 50 230 11,0 14 017 65 290 15,0 14 018 80 310 24,2 14 019 100 350 28,0 14 020 125 400 44,0 14 040 150 480 62,0 L LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .119 L Order No. Connection NPT, ” Length, mm Weight, kg 14 0610 ½ 80 0,3 14 0620 ¾ 95 0,4 14 0630 1 100 0,8 14 0640 1 ¼ 120 1,2 14 0650 1 ½ 140 1,5 14 0660 2 180 2,4 Strainer PN 40 • Y-type • thread connection • inner screen 0,25 mm of stainless steel • body of steel GP 240 GH (1.0619) Strainer PN 40 • type FAS-SFF • body of cast steel GS-C 25 / GP 240GH • Y-type with flanges acc. to DIN 2635 / EN 1092-1 • interior strainer made of stainless steel • mesh size – 0,6 mm Strainer PN 40 • type FAS-SFF • body of cast steel GS-C 25 / GP 240GH • Y-type with flanges acc.to DIN 2635 / EN 1092-1 • interior strainer made of stainless steel • execution with fine mesh filter, mesh – 0,25 mm Order No. Size, DN Length, mm Weight, kg 14 411 15 130 2,4 14 412 20 150 4,0 14 413 25 160 5,2 14 414 32 180 7,2 14 415 40 200 8,5 14 416 50 230 12,2 14 417 65 290 19,0 14 418 80 310 27,2 14 419 100 350 44,0 14 420 125 400 65,0 14 421 150 480 80,0 Order No. Size, DN Length, mm Weight, kg 14 451 15 130 2,4 14 452 20 150 4,0 14 453 25 160 5,2 14 454 32 180 7,2 14 455 40 200 8,5 14 456 50 230 12,2 Spare filter and seals are available on request Order No. Size, DN Length, mm Weight, kg 14 457 65 290 19,0 14 458 80 310 27,2 14 459 100 350 44,0 14 460 125 400 65,0 14 461 150 480 80,0 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 120 . • .Strainer PN 40 • for installation between flanges • in short version acc. To DIN 3202 • cylindrical housing with two discharging screws • body of steel (GP265GH (1.0425) • mesh size – 1,0 mm Order No. Size, DN Length, mm Diameter, mm Weight, kg 14 091 40 40 92 1,1 14 092 50 42 107 1,3 14 093 65 46 127 1,5 14 094 80 50 142 2,3 14 095 100 60 168 2,8 Filling device for methanol PN 25 (order No.14085), weight – 7,2 kg Consisting of: • Adapter, brass, 1¾” ACME with pin, for attachment to filler valve • Shut-off valve, brass, ¾” NPT • Vent valve, brass, ¼” NPT • Methanol-pressure vessel, nominal capacity approx. 2 l • Plug • High-pressure LPG hose DN 10, length approx. 2 m • Swivel POL adaptor for connection to service valve for gas withdrawal L LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .121 L Trap for installation downstream from vaporizer unit • connection 1” NTP female for liquid level sensors • primed and painted All traps are fitted with: • a fine-mesh screen, mesh size 1,0 mm • gas deflector • drain valve Order No. Connection Contents, l Length, mm Weight, kg 14 121 ½” NPT 2,9 160 6,0 14 122 ¾” NPT 2,9 160 6,9 14 123 1” NPT 2,9 160 7,8 14 124 DN 25 2,9 220 8,7 14 125 DN 32 2,9 220 9,5 14 126 DN 40 2,9 225 10,1 14 127 DN 50 2,9 230 12,4 14 128 DN 65 12,5 330 26,8 14 129 DN 80 12,5 340 28,6 14 130 DN 100 12,5 350 31,7 26 130 Extra charge for level sensor (PN 25, connection 1“ NPT male, approved for use in hazardous locations, Zone 0, with PTB-type approval, length of sensor: 66,5 mm) 26 301 Extra charge for isolating switch amplifier (with intrinsically safe input and relay output, 1-channel) 14 120 Extra charge for sealing of level sensor including pressure test Drain device for draining of water from stationary pressure tanks • volume approx. – 4 liters • inlet flange acc. to DIN 2635 • primed and painted Type: • A – Angle valve of brass, ¾” NPT with plug, relief valve of brass, type approval, ¾”NPT, set pressure 25 bar • B – Ball valve of steel, ½” NPT with plug, relief valve of stainless steel, type approval, ½” NPT, set pressure 25 bar Order No. Size, DN Dimensions, mm Weight, kg Type A Type B A B 14 151 14 156 15 310 300 5,2 14 152 14 157 20 310 300 5,5 14 153 14 158 25 310 300 5,7 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 122 . • .L Fine-mesh filter PN 25 for stationary systems • primed and painted • straight type • connecting flanges acc. to DIN 2635 • fine-mesh screen – of stainless steel, mesh size of 0,125 mm • connection – ½” female NPT, with plug Order No. Size, DN Dimensions, mm Weight, kg A B D L 14 131 25 250 205 133 285 11,0 14 132 32 250 255 133 335 13,0 14 133 40 285 250 152 335 16,0 14 134 50 285 310 152 395 19,0 14 135 65 350 350 194 465 29,0 14 136 80 350 440 194 560 33,0 14 137 100 460 585 273 720 42,0 14 138 125 460 585 273 720 42,0 14 139 150 648 714 406 899 192,0 14 169 200 648 714 406 899 192,0 Fittings for refilling facilities • Swivel joints M • Loading arm stations LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .123 Liquid and vapor transfer hose system in full hose system PN25 • standard connections for road tankers • respectively for rail tankers • tested at a hydrostatic pressure of 37,5 bar Type: • A – Length 4 m • B – Length 5 m Order No. Execution Type A Type B Filler hose for road tankers with safety relief valve 25 bar and venting device 25 021 25 221 High-pressure hose LPG 80, connections: one side ball valve DN 65 PN 40 with coupling 3¼”ACME with union nut and plug of brass, other side flange DN 80 PN 40 to DIN 2635 25 022 25 222 High-pressure hose LPG 50, connections: one side ball valve DN 50 PN 40 with coupling 3¼”ACME with union nut and plug of brass, other side flange DN 50 PN 40 to DIN 2635 Vapor transfer hose for road tankers 25 023 25 223 High-pressure hose LPG 80, connections: one side ball valve DN 65 PN 40 with coupling 2¼”ACME with union nut and plug of brass, other side flange DN 50 PN 40 to DIN 2635 25 024 25 224 High-pressure hose LPG 32, connections: one side ball valve DN 32 PN 40 with coupling 2¼”ACME with union nut and plug of brass, other side flange DN 32 PN 40 to DIN 2635 Filler hose for rail tankers with safety relief valve 25 bar and venting device 25 031 25 231 High-pressure hose LPG 80, connections: one side ball valve DN 65 PN 40 with lapped DIN flange DN 80 PN 40 and installed blind flange, other side flange DN 80 PN 40 to DIN 2635 Vapor transfer hose for rail tankers without safety relief valves 25 bar and venting device 25 032 25 232 High-pressure hose LPG 50, connections: one side ball valve DN 50 PN 40 with lapped DIN flange DN 50 PN 40 and installed blind flange, other side flange DN 50 PN 40 to DIN 2635 M FAS 25 027 LPG-filling hose DN 50 in full hose system FAS 93 6808 complete hose cabinet for road tankers Liquid line: right • M60×4 with cap • pressure gauges with shut-off valve • ball valve ½” NPT • ball valve DN 50 Vapor line: left • M60×4 with cap • pressure gauges with shut-off valve • ball valve ½” NPT • ball valve DN 25 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 124 . • .Complete hose system for applications in CIS and Baltic states Order No. Execution 25027 LPG-filling hose DN 50 in full hose system with safety relief valve and tension release, length = 4 m, connections: ball valve DN 50 PN 40 with union nut M60×4 and plug on one side, other side flange DN 50 PN 40 to 2635, completely mounted 25028 LPG-filling hose DN 50 in full hose system with safety relief valve and tension release, length = 4 m, connections: ball valve DN 50 PN 40 with union nut M60×4 and plug on one side, other side union nut M60×4, completely mounted 25029 LPG-filling hose DN 50 in full hose system with safety relief valve and tension release, length = 5 m, connections: ball valve DN 50 PN 40 with union nut M60×4 on one side, other side flange DN 50 PN 40 to 2635, completely mounted 25030 LPG-filling hose DN 32 in full hose system with safety relief valve and tension release, length = 10 m, connections: ball valve DN 32 PN 40 with union nut M60×4 and plug on one side, other side flange DN 32 PN 40 to 2635, completely mounted 25037 LPG vapor transfer hose DN 32 in full hose system with safety relief valve and tension release, length = 4 m, connections: ball valve DN 32 PN 40 with union nut M60×4 and plug on one side, other side flange DN 32 PN 40 to 2635, completely mounted 25039 LPG vapor transfer hose DN 32 in full hose system with safety relief valve and tension release, length = 7 m, connections: ball valve 1¼” with union nut M60×4 and plug on one side, other side flange DN 32 PN 40 to 2635, completely mounted 25042 LPG-filling hose DN 50 in full hose system with safety relief valve and tension release, length = 7 m, connections: ball valve DN 50 PN 40 with union nut M60×4 and plug on one side, other side flange DN 50 PN 40 to 2635, completely mounted 93016 Complete LPG high pressure hose line DN 50, PN 25, 2”, electrical conductively, temperature range: -40 up to +70°C, hose length = 4 m, connections: flange DN 50 PN 40 with ball valve DN 50, PN 40 on one side, other side flange DN 50 PN 40 to 2635, safety relief valve, excess flow valve, flange outside for welding 93018 Complete LPG high pressure hose line DN 50, PN 25, 2”, electrical conductively, temperature range: -40 up to +70°C, hose length = 4 m, connections: flange DN 50 PN 40 with ball valve DN 50, PN 40 on one side, other side flange DN 50 PN 40 to 2635, safety relief valve, excess flow valve, flange outside for welding FAS 93 680 FAS 93 6808 M LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .125 M Loading arm station PN 25 type FAS-G5 for the unloading of road tankers or rail tankers • two product arms (liquid and vapor phase) • connection for road tankers or rail tankers • 10% X-ray of welding seams • completely mounted and primed Loading Arm Station • Loading arm DN 80 (liquid phase), connection road tanker: coupling 3¼” ACME with union nut and blind plug • Loading arm DN 50 (vapor phase), connection road tanker: coupling 2¼” ACME with union nut and blind plug • Flanged ball valve DN 50 and DN 80, Fire-safe acc. to BS 6755 Part 2 • ERC-safety breakaway coupling DN 50 and DN 80 with release system • Ball valve ½” NPT for tension release, vent hose line LPG 10 for propane / butane or flexible stainless steel hose line for ammonia NH3 • Support column with thrust bearing system and 2 parking position locks • Hydraulic/pneumatic balance system for easy operation and handling Type: • A – for Propan/Butan • B – for Ammonia NH3 Loading arm stations with other dimensions and ANSIconnections for other media on request. Order No. Execution Type А Type В 25 302 25 307 Road tanker 25 304 25 309 Rail tanker Additional Service 25 392 Painting of the complete loading arms station 25 399 X-ray 100% of welding seams ENERGY • SAFETY • COMPETENCE LPG 2019-2020 126 . • .Loading arm station PN 25, Type FAS-G4, for loading and unloading of road tankers • two loading arms (liquid and vapor phases) • 100% X-ray of welding seams • completely mounted and primed Equipment: • Two loading arms DN 50, connection liquid phase with coupling 3¼” ACME with union nut and blind plug, connection vapor phase coupling 2 ¼” ACME with union nut and blind plug • Flanged ball valve DN 50 PN 40, Fire-safe acc. to BS 6755 Part 2 • ERC-safety breakaway coupling DN 50 with release system • Ball valve ½” NPT with hose line LPG 10 for venting • Support column with thrust bearing system and 2 parking position locks Order No. Execution 25 466 TKW Flexible loading arm Type FAS for unloading of rail tankers (execution for Russia) • 3 pcs. per rail tanker Order No. Execution 93 268 Basic version: lapped flange DN 50, PN 40, socket 1½” NPT – 2 pcs., flexible hose of stainless steel DN 40, PN 25, length 6 m, ball valve DN 40, PN 63, filling connection for rail tankers Additional accessories 12 081 Excess flow valve 2”, Type FAS, 166 l, PN 40 13 135 Breakaway coupling for hoses, PN 25, 2” female NPT on both sides M LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .127 M Order No. DN Execution Connection Type A Type B 25 451 25 468 80 TKW 3¼” ACME 25 452 25 469 80 EKW DN80 25 401 25 464 50 TKW 2¼” ACME 25 402 25 465 50 EKW DN50 25 519 – 80 FAS-RFP DN50 25 520 – 50 FAS-RGP DN50 25 521 Swivel joint 90°, connections 1½“×1½“ female NPT, with corrosion resistant metallic seal, max. operation pressure 25 bar, min. temperature -40° C Additional service 25 391 Extra charge for painting of complete loading arm station 25 398 X-ray 100% of welding seams Loading arm station PN 25, Type FAS-G7, for loading and unloading of road tankers or rail tankers • with one product arm (liquid phase) • completely mounted and primed • 10% X-Ray of welding seams Equipment: • Loading arm DN 80/DN 50 for road tanker, connection ACME-coupling with union nut and blind plug or respectively connection lapped flange with blind flange for rail tankers. • Flanged ball valve DN 50 or DN 80, Fire-safe acc. to BS 6755 Part 2 • ERC-safety breakaway coupling DN 50 with release system • Ball valve ½” NPT for tension release, vent hose line LPG 10 for propane / butane or flexible stainless steel hose line for ammonia NH3 • Support column with thrust bearing system and 2 parking position locks • Hydraulic/pneumatic balance system for easy operation and handling Type: • A – for Propan/Butan • B – for Ammonia NH3 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 128 . • .Swivel joint PN 25 for hose and pipe connections • seals of PTFE Type: • A – angular construction 90°, steel, both sides female NPT • B – straight construction, steel, both sides female NPT • C – straight construction, steel, one side female NPT, other side male NPT male Order No. Connection NPT, ” Weight, kg Type Type A B C A B C 25 161 25 171 25 182 ¾ 3,2 2,2 0,9 25 162 25 172 25 183 1 3,2 2,2 0,9 25 163 25 173 25 186 1¼ 3,0 2,0 1,2 25 164 25 174 – 1½ 5,9 5,4 – 25 165 25 175 – 2 5,6 5,0 – Torch for safe burning of vapor and liquid LPG (Order No. 25 290) • 3 removable supports, with brackets for fixing • automatic ignition device and flash back arrestor • 20 meters cable with plug •solenoid valve 230 V 50 Hz in inlet • connection 1¾” male ACME • total height approx. 3500 mm, space required for erection approx. 9 m2 Swivel joint PN 40, 3-piece body • straight construction of steel • welding ends on both sides • seals of PTFE Due to this 3-piece construction an exchange of the swivel joint head is possible without difficulties. Order No. Size, DN Length, mm Weight, kg 25076 DN 50 170 8,8 25078 DN 80 175 12,0 Swivel joint PN 40, 2-piece body • straight construction • welding ends on both sides • seals of PTFE Type: • A – of stainless steel for ammonia NH3 • B – of steel for propane / butane Order No. Size, DN Length, мм Weight, kg Execution A Execution B 25 064 25 084 DN 32 90 3,5 25 066 25 086 DN 50 145 7,2 25 068 25 088 DN 80 155 11,8 M LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .129 M Road tanker connection (FAS-98124), PN 25, for liquid gas line of any LGP filling station • connection M60×4 left, male with welding end DN 50 • welded neck flange DN 50 • cap M60×4 left, female • weight – 2,9 kg • completely welded, primed, painted and mounted Filling connection type FAS-RKSW-III (FAS-25522) for fixation of LPG-filling line to GUS-LPG-rail tankers • for liquid and vapor phase • without locking facility • thread-less connection to rail tanker’s side, with O-ring, pipe line side connection 1½” male NPT • galvanized and tested for functioning Road tanker connection (FAS-98127), PN 25, for liquid gas line of any LPG filling station • connection M60×4 left, male with welding end DN 50, reducer DN 80 / DN 50 • welded neck flange DN 80 • cap M60×4 left, female • weight – 5,9 kg • completely welded, primed, painted and mounted Parts list 1. Socket 1” NPT 2. Coupling 3. Spindle 4. Guide arm 5. Handle 6. Guide shell 7. Grease nipple M 10.1 8. Bracket 9. Guide ring 10. Guide pin 11. Guide screw nut Dimension drawing. Electrical components • Gas alarms systems N Control button for controlling of electrical drives • insulating box • E Ex dem IIC T6 • protection class IP 65 Order No. Type Pic. 26041 Emergency stop button with mushroom button actuator 1 26042 ON-OFF push-button 2 26043 ON-OFF push-button with indicating lamp 3 26044 Emergency stop button with mushroom key-operated button actuator 4 Control button for installation outside of Ex-zone • insolating box • protection class IP 64 Order No. Type Pic. 26 046 Emergency stop button with mushroom button actuator 1 1 2 3 4 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 130 . • .N Horn with powerful electromagnetic system • 230 V / 50 Hz • for use in damp areas or outdoors Order No. Type Weight, kg 26061 Without explosion protection 0,9 26062 With explosion protection 1,0 Temperature measuring and monitoring system (e.g. for vapor outlet in compressors) • measuring amplifier with 2 adjustable limit outputs • temperature indication • intrinsically safe input circuit for PT 100 • connection PT100 – M18×1,5 female • DIN resistors in 2-, 3- or 4-wire circuit • potential-free outputs • operating voltage 24 V DC • installation in electrical switch box Order No. Type 26312 Resistance thermometer, PT 100 263140 Measuring amplifier PMT 50 Ex 26316 Welding thermometer well, connection M18×1,5 female Beacon for use in moist areas or outdoors AC 230 V, 50/60 Hz Order No. Type Weight, kg 26151 Without explosion protection 0,5 26152 With explosion protection 1,3 Electric torch 2,5 V for hazardous areas zone 1, protection class EEx ia e II C T6, batteries type I EC R 20 Order No. Lamp Qty. of Batteries Weight, kg 26 161 2,5 V/0,3 А 2 0,20 26 162 3,7 V/0,3А 3 0,25 LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .131 N Connecting Parts O ENERGY • SAFETY • COMPETENCE LPG 2019-2020 132 . • .Seal PN 40 • LPG-proof • DIN 2690 • asbestos-free d d d D D D Type A, D Type B Type С Type: • A – Universal high-pressure seal with inner rim of galvanized soft iron, 2 mm thick • B – Soft seal of Perbunan with steel insert, DIN-DVGW-approved, reusable, 5 mm thick • C – Graphite high-pressure seal with insert of stainless steel foil, corrugated, FIRE SAFE to BS 6755, max. 650°C, with inner rim of stainless steel, 2 mm thick • D – Special high-pressure seal, FIRE SAFE to BS 5146, max. 650°C, with inner rim of galvanized soft iron, 2 mm thick Order No. Size, DN Dimensions, mm Type A Type B Type C Type D D d 10 641 10 651 10 941 10 991 15 50 22 10 642 10 652 10 942 10 992 20 60 27 10 643 10 653 10 943 10 993 25 70 34 10 644 10 654 10 944 10 994 32 82 43 10 645 10 655 10 945 10 995 40 92 48 10 646 10 656 10 946 10 996 50 107 60 10 647 10 657 10 947 10 997 65 127 76 10 648 10 658 10 948 10 998 80 142 89 10 649 10 659 10 949 10 999 100 168 114 10 650 10 660 10 940 10 990 125 195 141 Compensator for pipelines PN 25 • DIN 2635 • with flange connection Order No. DN Weight, kg 10 751 25 2,00 10 752 32 3,20 10 753 40 3,40 10 754 50 4,75 10 755 65 6,00 10 756 80 7,50 10 757 100 10,15 O LPG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .133 O Straight pipe union PN 40 • with NPT male thread • galvanized Elbow and tee unions available on request Order No. NPT, “ Pipe O.D. Weight, kg 10 701 ¼ 8 0,04 10 702 ¼ 10 0,05 10 703 ¼ 12 0,06 10 704 3 /8 10 0,06 10 705 3 /8 12 0,07 10 706 ½ 12 0,08 Order No. NPT, “ Pipe O.D. Weight, kg 10 707 ½ 15 0,11 10 708 ½ 18 0,13 10 709 ½ 22 0,16 10 710 ¾ 18 0,15 10 711 ¾ 22 0,18 10 712 1 28 0,21 Insulating Flange Set PN 40 • pre-assembled and dielectrically tested to 5000 V Discharger explosion-proof, for bridging of insulating flanges in hazardous areas • complete with connecting cable = 200 mm High pressure LPG hose LPG PN 25, Type FAS • acc. to DIN EN 1762 • temperature range: -30 up to +70°C • electrically conductive Flanges must be demounted before installation in pipelines. High-pressure hose for ammonia and other sizes are available on request Order No. Screw connection Weight, kg 10 615 M12 1,1 10 616 M16 1,1 10 617 M20 1,2 10 618 M24 1,2 Order No. DN External diameter, mm 10 801 10 20 10 800 13 23 10 802 19 31 10 803 25 37 10 804 32 44 10 805 50 66 10 806 80 93 Order No. Size, DN Connection D×s Length, mm Weight, kg 10 770 15 21,3×2,0 88 1,9 10 771 20 26,9×2,3 97 2,2 10 772 25 33,7×2,6 97 3,5 10 773 32 42,4×2,6 100 5,0 10 774 40 48,3×2,6 108 6,0 10 775 50 60,3×2,9 114 7,0 10 776 65 76,1×2,9 122 10,0 10 777 80 88,9×3,2 133 12,3 10 778 100 114,3×3,6 148 17,5 ENERGY • SAFETY • COMPETENCE LPG 2019-2020 134 . • .O Order No. Connection /LPG Type 10 811 DN 20/19 1 10 812 DN 25/19 R 1 10 813 DN 25/25 1 10 814 DN 25/32 1 10 815 DN 32/25 R 1 10 816 DN 32/32 1 10 817 DN 40/32 R 1 10 818 DN 40/50 1 10 819 DN 50/32 R 1 10 820 DN 50/50 1 10 821 DN 50/50 2 10 822 DN 50/50 3 10 823 DN 65/50 R 1 10 824 DN 65/80 1 10 825 DN 80/50 R 1 10 826 DN 80/80 1 10 827 DN 80/80 2 10 828 DN 80/80 3 10 888 ½” NPT/13 4 Order No. Connection /LPG Type 10 831* ½” NPT/19 4 10 832* ¾” NPT/19 4 10 833 ¾” NPT/25 4 10 834 1”NPT/19 R 4 10 835* 1” NPT/25 4 10 836* 1” NPT/32 4 10 837* ГА” NPT/32 4 10 838 172” NPT/32 4 10 839* 2” NPT/50 4 10 840 2” NPT/80 R 4 10 841 2½” NPT/50 R 4 10 842 3” NPT/50 R 4 10 843* 3” NPT/80 4 10 851 ½” NPT/19 5 10 852 ¾” NPT/19 R 5 10 853* ¾” NPT/25 5 10 854 1” NPT/19 R 5 10 886 G ½”/1 3 7 10 855 1” NPT/25 R 5 Order No. Connection /LPG Type 10 844* 1” NPT/32 R 5 10 856 1¼” NPT/25 5 10 857 1¼” NPT/32 R 5 10 858 1½” NPT/32 R 5 10 859 2” NPT/50 5 10 860 2” NPT/80 5 10 861 2½” NPT/50 R 5 10 862 2½” NPT/80 5 10 863 3” NPT/50 R 5 10 864 3” NPT/80 R 5 10 869 ¾” NPT female like 5 10 873 G 1¼”/25 6 10 865 G 1¼”/32 6 10 850 M 65×2/50 like 6 10 849 M 100×2/80 like 6 10 866 M 30×1,5 links/19 7 10 867 W 21,8×714” links/10 7 10 892 M 60×4/ DN 32 like 6 10 920 M 60×4/ DN 50 like 6 Complete hose connection PN 25 • hose nipple of steel • with clamp of aluminium • complete mounting parts Type: 1. Flange PN 40, DIN 2635 2. Flange PN 40, DIN 2635 and half coupling PN 40, ½” NPT for relief valve 3. Lapped flange PN 40, DIN 2656 4. Nipple PN 40, with NPT-thread 5. Half coupling PN 40, with NPT-thread 6. Union nut (brass), flat seal 7. Union nut (brass), flat seal * One-piece turned part without welding, galvanized 1 2 3 4 5 6 7 Industrial compressors A 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .135 Corken compressors for industrial applications • type of compressors – piston • type of cooling – air • type of lubrication – oil free • type of compression – single stage, two staged • purging system (optional) • working pressure – up to 112 bar • capacity – up to 50000 m3 /h (depending on process) Applications: • transport of liquid gases • recuperations of gases • oil, natural gases production • CNG applications • loading and unloading of liquid gases • chemical and petrochemical processes Common mediums Ammonia Cyclopropane Hydrogen Cyclohexan Argon Deuterium Hydrogen Chloride Hydrocarbon gas Benzene Dimethylamine Isobutane Monomethylamine Biogas Dimethyl ether Isobutene Natural gas Butadiene 2,2-dimethylpropane Isobutylene Neon Bromotrifluoromethane Ethane Krypton Nitric oxide Carbon dioxide Ethyl chloride Methane Nitrous oxide Carbon monoxide Ethylene Methyl acetylene N-octaine Carbon tetrachloride Ethylene oxide Methyl bromide Ozone Carbonyl sulfide Helium Methyl chloride N-pentane Chlorine Hexafluoroethane Methyl fluoride Phosgene Chlorodifluoro-Methane N-heptane Methyl mercaptane Propane Cyanogen N-hexane Monoethylamine Propylene Refrigerants CFC-11 CFC-503 Sulfur dioxide Vinyl bromide CFC-12 NCFC-22 Sulfur hexafluoride Vinyl fluoride CFC-13 NCFC-141B Tetrafluoroethylene Vinyl chloride CFC-113 NCFC-134A Trichlorethane Xenon CFC-502 NCFC-152A Trimethylamine A ENERGY • SAFETY • COMPETENCE 2019-2020 136 . • .INDUSTRIAL Model line Single stage compressors Two stage compressors D91 D291 D491 D491-3 D691 D691-4 D891(a) FD151 D191 FD351 D391 D590 FD591 D791(a) Cylinder diameter, mm 1 stage 1 cylinder 76,2 101,6 76,2 114,3 101,6 114,3 63,5 76,2 69,9 114,3 152,4 152,4 152,4 2 stage 76,2 31,8 44,5 44,5 63,5 82,5 82,5 82,5 Piston stroke, mm 63,5 63,5 76,2 76,2 101,6 101,6 101,6 63,5 63,5 76,2 76,2 101,6 101,6 101,6 Capacity, m3 /h: Min. at 400 U/min-1 6,8 13,6 29,2 16,7 49,6 39,4 96,2 79 6,8 117 18,8 30,9 30,9 87,0 Max. at 825 U/min-1 14,1 25,4 60,3 34,3 102,3 81,6 192,4 164 14 14,4 38,7 63,7 63,7 179,6 Max. operation pressure, bar 24,1 24,1 24,1 42,4 24,1 42,4 32,1 82,8 42,4 82,8 43,1 24,1 42,4 42,4 Max. power consumption, kW 5,6 11 11 11 26,1 26,1 34 11 11 11 11 34 26,1 34 Max. piston rod liability, kgs 1633 1633 1814 1814 2495 3175 3175 1633 1633 1814 1814 3175 3175 3175 Max. outlet temperature, °C 177 177 177 177 177 177 177 177 177 177 177 177 177 177 Double gland T-style (optional) • • • • • • • • • Flanges ANSI/DIN (optional) • • • • • • • • • • • Water cooling (optional) • • • • • • A 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .137 A Horizontal industrial compressors • up to 4-stage version • max. pressure – 310 bar • max. cubic capacity voltage more than 600 m3 /h • piston stroke – 76,2 mm • max. piston rod strain – 3175,2 kgs • max. motor capacity – 58 kW • max. outlet temperature – 176,7°C • speed range – 400…1200 U/min-1 Two stage model HG602AB HG602AD HG602BD HG602BE HG602DE HG602DF HG602EF Cylinder diameter, inch 8×6 8×4 6×4 6×3,25 4×3,25 4×2,75 3,25×2,75 Capacity (1200 min-1), m3 /h 351,7 351,7 195,4 195,4 84,6 84,6 54,5 Weight, kg 430,0 423,2 386,9 380,1 373,3 373,3 364,2 Water cooling (optional) WG602AB WG602AD WG602BD WG602BE WG602DE – – Single stage model HG601AX HG601BX HG601CX HG601DX HG601EX HG601FX HG601AA Cylinder diameter, inch 8 6 5 4 3,25 2,75 8×8 Capacity (1200 min-1), m3 /h 351,7 195,4 134,4 84,6 54,5 56,0 703,5 Weight, kg 423,2 393,7 390,5 373,3 364,2 364,2 456,8 Water cooling (optional) WG601AX WG601BX – WG601DX WG601EX – WG601AA Cylinder bore, mm 203,2 203,2 152,4 152,4 127 127 101,6 Max. operation pressure, bar 21,7 21,7 25,2 25,2 51,7 51,7 70,0 ENERGY • SAFETY • COMPETENCE 2019-2020 138 . • .INDUSTRIAL Technical data Inlet pressure min. 0,5 bar Inlet pressure max. 21 bar Cubic capacuty 1-staged operation – 302,8 m3 /h 2-staged operation – 179,4 m3 /h Motor capacity 58 kW Weight 2650 kg Technical data Inlet pressure min. 0,5 bar Inlet pressure max. 19 bar Cubic capacuty 393 Nm3 /h Motor capacity 58 kW Weight 2289 kg Dry running piston compressor unit for ammonia (NH3 ) • technical process for a chemical facility • combined 1- and 2-staged execution • automated change over in 2-staged execution • application of control equipment with AUMAdrives • heat exchanger as an intercooler • complete pipe system • liquid trap • pulsation damper • instrumentation and monitoring of operation process • suitable for location outside and inside • suitable for installation in Ex-Zone II Dry running piston compressor unit for propylene • rail tanker unloading station • medium: Propylene • 1-stage design • complete pipe line system • liquid trap • instrumentation and monitoring of operation process • suitable for location outside and inside • suitable for installation in Ex-Zone II A Technical data Inlet pressure min. 0,5 bar Inlet pressure max. 25 bar Cubic capacuty 13 Nm3 /h Motor capacity 5,5 kW Weight 460 kg Technical data Inlet pressure min. 5 bar Inlet pressure max. 58 bar Cubic capacuty 1-staged – 9,6 Nm3 /h / 2-staged – 3,9 Nm3 /h Motor capacity 2×7,4 kW Weight 3476 kg Dry running piston compressor unit for Hexane • technical process for a chemical facility • medium: Hexane • 2-staged execution • heat exchanger as an intercooler • controlling of frequency converters • complete pipe system • instrumentation and monitoring of operation process • suitable for location outside and inside • suitable for installation in Ex-Zone II Dry running piston compressor unit for Nitrogen (N2 ) • technical process for fertilizer facility • 2 compressors, 2 process lines • surge drum acc. To ASME with isolation • 2-staged compressor FD351 • heat exchanger as an intercooler • complete pipe system acc. To ASME 31.3 • medium contacting parts from stainless steel • instrumentation and monitoring of operation process • fittings from ASME • instrumentation with UL/FM • suitable for location inside • suitable for installation in Ex-Zone II 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .139 A Industrial pumps B NUB 300 NUB 32- NUB 500 NUB 600 NUB 700 NUB 80-160 NUB 800 30 20 10 0 60 50 40 м Высота водяного столба Производительность, м3 /ч 2 3 4 8 6 10 8 20 30 40 60 0 100 3 200 00 350 Delivery head, m Delivery rate, m3 /h ENERGY • SAFETY • COMPETENCE 2019-2020 140 . • .INDUSTRIAL Universal single-stage circulation pump in a compact block version BLOC NUB/NUBF High power efficiency • low flow rate • slight speed-hight difference Technical advantages • thrust free open or balanced closed impellers • compensation of radial force through control equipment in ring housing Process reliability • partial gas transfer • wide characteristic curves • selection between flat or abrupt characteristic curves • top control mode Easy installation • large flange nominal sizes • no pipe extension required • any installation position • compact pump design Easy service and operation conditions • operating pressure up to 10 bar • temperature -40°C up to +140°C • viscosity up to 115 mm2 /s B LUB 65 LUB 80 LUB 100 LUB 40 4 Высота водяного столба, м 10 0 20 40 30 50 300 60 6 8 10 20 3 0 0 4 60 80 100 200 Производительность, м3 /ч Delivery head, m Delivery rate, m3 /h 40- 32- 50- 65- 80- Производительность, м3 /ч 6 8 1 2 0 0 4 0 0 6 80 100 200 3 0 00 35 50 Hz 50 30 40 20 10 100 90 80 70 60 Высота водяного столба, м 4 Delivery head, m Delivery rate, m3 /h Universal single-stage circulation pump in inline-version LUB High power efficiency Technical advantages • thrust free open or balanced closed impellers • compensation of radial force through control equipment in ring housing Process reliability • capability of transfer of gas in the liquid • wide characteristic curves • selection between flat or abrupt characteristic curves • top control mode Easy installation and service • pull-back version • extracting coupling Application • operating pressure up to 10 bar • temperature -40°C up to +140°C • viscosity up to 115 mm2 /s Universal single-stage centrifugal pump BLOC CB BC in stainless steel • closed impellers • single or double mechanical seal • easy service thanks to pull-back version • material stainless steel/stainless steel sheet • operating pressure up to 10 bar • temperature -25 up to +110°C • viscosity up to 115 mm2 /s 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .141 B 0 Высота водяного столба, м 10 20 30 40 5 15 25 35 2 Производительность, м3 /ч 3 0 4 5 6 8 10 20 3 40 60 80 100 200 300 400 FUB 300 FUB 500 FUB 700 FUB 800 FUB 600 Delivery head, m Delivery rate, m3 /h Unchokable pump in a compact block version FUB CBF Process reliability • solid transfer • cavitation adaptability • mild medium transfer • non-sensitive for pigtail- and clew formation Technical advantages • pulse transmission by recessed vortex type impeller • free ball pass up to 80 mm diameter • abrasion cover and other special designes Easy installation • any installation position • compact pump design Easy service • pull-back version • robust construction Application • operating pressure up to 10 bar • temperature -40°C up to +140°C • viscosity up to 60 mm2 /s • solids content ENERGY • SAFETY • COMPETENCE 2019-2020 142 . • .INDUSTRIAL B 8 2 1 4 6 20 10 40 2 4 6 1 8 0 20 40 60 100 60 80 200 300 Высота водяного столба, м 400 600 100 200 400 600 Производительность, м3 /ч Delivery head, m Delivery rate, m3 /h Multi-stage circulation pump LBU VBU NHP Z High power efficiency • integrated jet pump or mixture formation • low flow rate • optimized impeller inflow • small internal friction losses • optimized stage’s delivery head Technical advantages • thrust free open or balanced closed impellers • compensation of radial force through control equipment in ring housing • NPSH-pre-stages Process reliability • capability of transfer of gas in the liquid • wide characteristic curves • selection between flat or abrupt characteristic curves • top control mode Easy installation • modular system for individual solutions • free selection of nipple position • horizontal or vertical execution • block- or ground plate design Easy service Application • operating pressure up to 64 bar • temperature -60°C up to +220°C • viscosity up to 115 mm2 /s 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .143 B S 6 E S 5 SUB 700 S 7 SUB 600 SUB 500 SUB 300 Производительность, м3 /ч 2 5 3 4 6 1 8 0 3 20 0 40 60 80100 200 0 50 100 150 200 Высота водяного столба, м 1 Delivery head, m Delivery rate, m3 /h Self-sucking centrifugal pump E SUB S High power efficiency • integrated jet pump or mixture formation • low flow rate • optimized impeller inflow • small internal friction losses • optimized stage’s delivery head Technical advantages • thrust free open or balanced closed impellers • compensation of radial force through control equipment in ring housing Process reliability • self-sucking • capability of transfer of gas in the liquid • wide characteristic curves • selection between flat or abrupt characteristic curves Easy installation • modular system for individual solutions • horizontal execution • block- or ground plate design Easy service Application • operating pressure up to 16 bar • temperature -40°C up to +90°C • viscosity up to 115 mm2 /s ENERGY • SAFETY • COMPETENCE 2019-2020 144 . • .INDUSTRIAL B 0,5 1 2 5 3 4 6 78 19 2 0 0 40 60 80 1 100 80 30 25 20 15 10 0 5 Давление, бар Производительность, м3 /ч EBu LBU 6 … PBU LBU 4 … NHU 100 … Pressure, bar Delivery rate, m3 /h Multiphase centrifugal pump type PBU EB LBU High power efficiency • optimal enrichment and mixing of fluids with gases • high degree of dispersion • low flow rate • optimized impeller inflow • small internal friction losses • optimized stage’s delivery head Technical advantages • thrust free open impellers • compensation of radial force through control equipment in ring housing • direct gas addition acc. to VDMA 24430 Process reliability • ability of gas transfer up to 30% • stable producing of micro bubbles Easy installation • modular system for individual solutions • horizontal execution • block- or ground plate design Easy service Application • operating pressure up to 40 bar • temperature -40°C up to +140°C • viscosity up to 115 mm2 /s 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .145 B Производительность, м3 /ч 0 0 Высота водяного столба, м60 350 50 40 30 20 10 50 100 150 200 250 300 40-160 32-160 50-160 65-160 700 M 800 N Delivery head, m Delivery rate, m3 /h Universal space saving submersible pump B CTOL High power efficiency • no shaft seal • no external leakage • with vortex type impeller Easy installation • space saving design • modular system for individual solutions Applications • operating pressure up to 10 bar • temperature -25 up to +90°C • viscosity up to 115 mm2 /s • special pump models for other conditions ENERGY • SAFETY • COMPETENCE 2019-2020 146 . • .INDUSTRIAL B Einfach wirkende Gleitringdichtung Doppelt wirkende Gleitringdichtung Magnetkupplung Order No. Pump type Delivery rate m3/h (l/min) Delivery head (NPSH), m (bar) Max. pressure, bar Inlet/Outlet Motor capacity, kW Weight, kg 46 0301 NZ-3-6-2,5 3 (50) 66 (5,5) 16,0 65/40 (PN16/PN40) 2,5(T3) 70 46 0302 NZ-6-7-3,3 6 (100) 79 (6,5) 16,0 3,3 (T3) 100 46 0303 NZ-12-7-5,5 12 (200) 80,5 (6,7) 16,0 5,5 (T3) 100 46 0304 NZ-18-6-5,5 18 (300) 68 (5,6) 16,0 5,5 (T3) 100 46 0305 NZ-30-6-10 30 (500) 71,5 (5,9) 16,0 80/65 (PN16/PN40) 10,0 (T3) 162 46 0306 NZ-42-6-12,5 42 (700) 69 (5,7) 16,0 12,5 (T3) 171 46 0307 NZ-60-6-15 60 (1000) 64 (5,3) 40,0 125/100 (PN40) 15,0 (T3) 281 46 0308 NZ-90-6-24 90 (1500) 65 (5,4) 40,0 24,0 (T3) 370 46 0309 NZ-150-6-36 150 (2500) 72 (5,9) 40,0 36,0 (T3) 395 46 0310 NZ-180-7-68 180 (3000) 87,5 (7,2) 40,0 200/125 (PN40) 68,0 (T3) 1100 Order No. Type Connection, ” NPT Max. capacity, l/min Max. operation pressure, bar Max. differential pressure, bar Max. operation temperature, С° 21 2963 PT 20 2 340 13,8 8,6 149 21 2962 PT 25 2½ 610 13,8 8,6 149 21 2961 PT 30 3 1030 13,8 8,6 149 Pump unit for transfer of light fuel oil products (petrol, kerosene, diesel and fuel oil) • constant high efficiency • ability to increase the productivity and differential pressure • mechanical seal • available with double mechanical seal “Tandem” or magnetic coupling • compact version Pumps Corken type PT for petroleum products and industrial solvents (gasoline, fuel oil, diesel fuel, ethanol, solvents) 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .147 B Industrial measurements C Mass flow meters FAS 98 8687 Promass F 300, 8F3B50 • for liquid CO2 • connections – DN 50 2” • operation pressure – 8 bar • maximum flow rate – 50000 kg/h Mass flow meters FAS 98 8686 Promass F 300, 8F3B80 • for liquid CO2 • connections – DN 80 3” • operation pressure – 8 bar • maximum flow rate – 120000 kg/h Other flow rates on request Complete measuring unit Type LC for petroleum (* capacity is depending on viscosity) Order No. Type Connection Max. capacity, l/min Execution 98 1665 LC M7CX0100 2” 500* VR register/excl. printer 98 1666 LC M15CX0100 3” 1000* 98 1667 LC M25CX0100 3” 1150* 98 1668 LC M30CX0100 4” 1700* Order No. Type Connection Max. capacity, l/min Execution 98 1660 LC M7GX0100 2” 500* VR register/incl. mech. printer 98 1661 LC M15GX0100 3” 1000* 98 1662 LC M25CX0100 3” 1150* 98 1663 LC M30CX0100 4” 1700* Order No. Type Connection Max. capacity, l/min Execution 98 1670 LC M7-TEX 2” 500* TEX register/excl. printer (FAS No. 38466 Epson Slip printer TM-U295 is by request available) 98 1671 LC M15-TEX 3” 1000* 98 1672 LC M25-TEX 3” 1150* 98 1673 LC M30-TEX 4” 1700* ENERGY • SAFETY • COMPETENCE 2019-2020 148 . • .INDUSTRIAL C Road tanker equipment D • inlet /outlet – 3” NPT • flow rate (max) – 1514 l/min (by low viscosity medium) • maximum differential pressure – 8,6 bar FAS 21 3181 FAS-Corken pump aggregate for liquid CO2 , Type CDBN 1022, Capacity approx. – 530 l/min at 2 bar differential pressure; 450 l/min. at 8,6 bar differential pressure. Consists of: • pump CDBN 1022, connection – 3” NPT, with special mechanical seal, • gear-motor 7,5 kW (560 rpm, IP 54, 400/690 V) • with coupling and coupling protection • mounted on a common base plate FAS-Corken pump aggregate for liquid CO2 , Type CDBN 1022. Capacity approx. – 530 l/min at 2 bar differential pressure; 450 l/min. at 8,6 bar differential pressure. Execution: FAS 21 3183 – without ground plate; FAS 21 3182 – standart. FAS-Corken pump aggregate consists of: • pump CDBN 1022, connection – 3” NPT, with special mechanical seal, • gear-motor 15,0 kW (560 rpm, IP 54, 400/690 V) • with coupling and coupling protection • mounted on a common base plate FAS 32 0451 Corken pump for liquid CO2 , Type CDBN 1022 Pumps Corken PZ for petroleum products and industrial solvents, for installation on a road tanker • high pressure design with O-ring construction • mechanically sealed with a silicon carbide seal seat • six vanes and vane drivers • adjustable internal relief valve • replaceable cam, liner, and reversible slide plates • ideal for liquids with high vapor pressures Order No. Type Connection, ” NPT Max. capacity, l/min Max. operation pressure, bar Max. differential pressure, bar Max. operation temperature, С° 21 2966 PZ 7 2 400 13,8 8,6 149 21 2969 PZ 10 2½ 610 13,8 8,6 149 2019-2020 ENERGY • SAFETY • COMPETENCE INDUSTRIAL . • .149 D Order No. Motor, kW Capacity, l/min By dif. pressure, bar Pmax, bar 46 0963 15 600 6,6 (1,03 dm/cm3 ) 7,5 (1,116 dm/cm3 ) 40 46 0967 Bare pump 750 max – 40 FAS 21 284 Blackmer-pump for liquid CO2 Type CRL3 • inlet/outlet – 3” NPT, • maximum flow rate – 560 l/min (by low viscosity medium) • maximum differential pressure – 8,6 bar • double wave version FAS 21 285 Blackmer-pump for liquid CO2 Type CRL4 • inlet/outlet – 4” NPT, • maximum flow rate – 950 l/min (by low viscosity medium) • maximum differential pressure – 8,6 bar • right hand rotation FAS 21 288 FAS-Blackmer pump aggregate for liquid CO2 , Type CRL3 Capacity approx. – 400 l/min at 3 bar differential pressure, 320 l/min at 6.5 bar differential pressure. Pump aggregate consisting of: • pump CRL3, connection – 3” NPT, with special mechanical seal • with gear-motor 7,5 kW, 570 rpm, IP 54, 400/690 V • with coupling and coupling protection • mounted on a common base plate FAS 21 2882 FAS-Blackmer pump aggregate for liquid CO2 , Type CRL3 Capacity approx. – 400 l/min at 3 bar differential pressure, 320 l/min at 6.5 bar differential pressure. Execution – without ground plate. Pump aggregate consisting of: • pump CRL3, connection – 3” NPT, with special mechanical seal • with gear-motor 7,5 kW, 570 rpm, IP 54, 400/690 V • with coupling and coupling protection • without common base plate Centrifugal pump unit for CO2 liquid phase • type – NZ 36-7,4-15 STW • normal suction • horizontal • bloc design • with electromotor • material – stainless steel V4A ENERGY • SAFETY • COMPETENCE 2019-2020 150 . • .INDUSTRIAL D LNG filling station – Version 1: LNG LNG filling stations FAS are designed for filling of all types of trucks with liquefied natural gas. Typical filling station consists of the following components: • LNG tank • pump unit of low pressure • saturation vaporizer • LNG dispenser • electrical control box The module design allows in the shortest possible time to adapt the performance of the station to almost any consumer needs. LNG filling station – Version 2: a combination of LNG-L-CNG Combined filling stations FAS are designed for filling of all cars with liquefied natural gas and liquefied compressed natural gas. Typical filling station consists of following components: • LNG tank • pump unit of low pressure (LNG line) • saturation vaporizer (LNG line) • LNG dispenser (LNG line) • pump unit of high pressure (L-CNG line) • high pressure vaporizer (L-CNG line) • block-battery (LNG line) • LNG dispenser (LNG line) • electrical control box The module design allows in the shortest possible time to adapt the performance of the station to almost any consumer needs. Refueling stations LNG, L-CNG A Through many years of experience in the liquid gas market FAS has already been involved several times in the construction of gas refueling. With our wide range of various filling station executions, we can find the right solution for every application. The rapid development of natural gas applications (NG) has moved us to extend our know-how for LNG and L-CNG filling stations. LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .151 A LNG filling station – Version 3: modular LNG filling station in container execution LNG filling station in container execution is designed to carry out the following processes: • receipt and storage of LNG • increase of LNG pressure up to 5-8 bar • filling of LNG trucks The station is a factory product ready for connection and includes all the main components for safe reception, storage and refueling with automatic control of all production processes. Container design suppose a limitation of the volume of capacity to 20 cubic meters. If necessary, to increase the storage volume – it is possible to carry out the tank outside the container. ENERGY • SAFETY • COMPETENCE 2019-2020 152 . • .LNG A Regasification stations in their standard executions The LNG regasification station is designed to convert the liquid phase into vapor, followed by lowering the pressure incl. odorizing option for further supply to various groups of natural gas consumers. The most demanded standard sizes of LNG / LNG regasification stations are Regasification unit B Consumption LNG, kg/h Capacity, kW/h Capacity of vaporizer, Nm3 /h Area of vaporizer, m2 100 1 200 150 64 170 2 000 300 121 330 4 000 450 178 500 6 000 750 300 650 8 500 900 355 750 9 500 1 050 390 1 000 12 500 1 500 586 2 000 25 000 2×1500 2×586 Tank Vaporizer Vaporizer Heating Regulator Metering unit Odorizer Automation Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Unit 6 Unit 7 Unit 8 Installations of higher capacity are possible. The volume and number of containers depends on required capacity and delivery frequency. Scheme of regasification station in standard executions Regasification stations consist of the following main technological units V23 AV2 BLOCK-1 BLOCK-3 V25 V21 BLOCK-2 V26 V24 TT V22 V14 DV BLOCK-4 BLOCK-5 V32 PR2 V30 V34 F2 PT TT PT PI PI PR1 V29 V31 V33 F1 V28 V27 GH BLOCK-6 BLOCK-7 V48 TRV 11 ODORIZER V42 V45 V40 V43 V50 V51 V49 V47 V46 V41 V44 V39 PTZ FM SV4 SV2 SV1 SV3 TRV 10 E E TRV9 V19 TRV1 V12 E PUBC TRV6 TRV2 E E E TRV4 V2 TRV3 TRV8 V3 V21 FL AV1 V20 V1 TRV7 E V5 V15 V7 VG V20 E LG VC V9 V16 PT PG PI TRV5 E V10 LT V11 V6 ERG PT E V17 OS V8 LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .153 B Regasification stations in container design The LNG regasification station is designed to convert the liquid phase into vapor, followed by lowering the pressure incl. odorizing option for further supply to various groups of natural gas consumers. The most demanded standard sizes of LNG / LNG regasification stations are Dimensions of tank frame Capacity Capacity of vaporizer, Nm3 /h Area of vaporizer, m2 10 ft 1 500 150 66 20 ft 4 000 450 178 30 ft 7 000 800 289 40 ft 10 000 1 150 445 Tank Vaporizer Vaporizer Heating Regulator Metering unit Odorizer Automation Unit 1 Unit 2 Unit 3 Unit 4 Unit 5 Unit 6 Unit 7 Unit 8 As a tank or logistics fleet can be used the following tank containers: 20 ft, 30 ft, 40 ft. Regasification stations in container design consist of following units: Scheme of regasification station in container executions V23 AV2 BLOCK-1 BLOCK-3 V25 V21 BLOCK-2 V26 V24 TT V22 V14 DV BLOCK-4 BLOCK-5 V32 PR2 V30 V34 F2 PT TT PT PI PI PR1 V29 V31 V33 F1 V28 V27 GH BLOCK-6 BLOCK-7 V48 TRV 11 ODORIZER V42 V45 V40 V43 V50 V51 V49 V47 V46 V41 V44 V39 PTZ FM SV4 SV2 SV1 SV3 TRV 10 E E TRV9 V19 TRV1 V12 E PUBC TRV6 TRV2 E E E TRV4 V2 TRV3 TRV8 V3 V21 FL AV1 V20 V1 TRV7 E V5 V15 V7 VG V20 E LG VC V9 V16 PT PG PI TRV5 E V10 LT V11 V6 ERG PT E V17 OS V8 ENERGY • SAFETY • COMPETENCE 2019-2020 154 . • .LNG B LNG dispenser is designed for filling of LNG cars (also version for VOLVO trucks available). Medium – LNG at 8 bar, -130°C, maximum carrying capacity – 100 kg/min. • mass flow meter, OIML R81 & R117-1 certificate, LNG error 0,35%/BOG error 0,35% • Modbus communication counter – PC, EAS1 protocol • PLC communication Modbus for reading of error history • display with value (______/kg), mass (kg) and price (_________) • memory of 150 fillings & 250 failures • voltage – 230 V AC, 50 Hz, 300 W, class of protection – IP54 • housing from stainless steel, grounded and painted • automatic cooling, filling and by pass process, emergency switch off • measurement of filling pressure and temperature • filling hose 1”, with breakaway coupling and protection against burns • return hose ½”, with breakaway coupling and protection against burns • nozzles JC Carter or Macrotech • ground terminal block Dispensers C 2130 1775 868 1200 1352 550 120 770 210 150 10 150 400 G A Options: • EAS2 LON protocol • ATEX BOX EAS2 ExnA E30 LNG is required for installation in the ATEX Zone 2 • a set for filling of a single-hose system (VOLVO) • breakaway coupling LNG1” ANSI 300 PN 40 15 kN • breakaway coupling LNG ½” ANSI 300 PN 40 15 kN Dimensional scheme of LNG Dispencer type FAS LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .155 C LNG-Tanks D LNG tanks LNG tanks are available both in a vertical and in a horizontal execution. Tank design depends on the purpose and intended use: • as a part of a filling station • as a part of the regasification station The time of non-drainage storage is determined by the maximum working pressure and type of insulation. V, liter Dif. Net V, liter Working pressure, bar Hight, mm Diameter, mm Length, мм Weight, kg (5 bar) Weight, kg (12 bar) 5 800 5% 5 500 5-12 2 300 2 300 4 200 2 400 2 700 8 000 7 700 5 200 2 800 3 200 10 300 9 800 6 200 3 200 3 600 15 900 15 100 8 200 4 200 4 900 20 400 19 500 10 700 5 000 5 900 22 700 21 500 11 700 5 500 6 400 32 100 30 100 3 000 3 000 9 500 7 500 8 500 42 400 40 300 12 000 9 300 10 600 52 700 50 100 14 500 11 100 12 700 67 300 63 900 3 700 3 700 12 700 12 900 15 300 76 500 72 700 14 200 14 100 17 000 Hydraulic scheme of LNG tank ENERGY • SAFETY • COMPETENCE 2019-2020 156 . • .LNG D Tanks with volume up to 200 m3 available on request Road tanker equipment E Cryogenic centrifugal pump unit SGM 185 for LNG (FAS No. 96 624), maximum capacity – 550 l/min (by maximum differential pressure 6 bar), electric motor – 11 kW (50 Hz 400 V, ATEX Ex-D IIB T4) with junction box and gearbox transmission. Type of shaft-seal – rulon mechanical seal. Inducer to minimize required NPSH Cryogenic centrifugal pump applications: • road trailers unloading, storage/iso-containers loading/ unloading • process and back-up operations, petrochemical industry applications • special applications with differential head and flow-rates upon customer demand Cryogenic centrifugal pump unit DSM 230 for LNG (FAS No. 96 626), capacity – 1000 l/min (by max differential pressure 3 bar), motor 11 kW (50 Hz 400 V, ATEX Ex-D IIB T4), with junction box and Direct Coupling transmission. Type of shaft-seal – rulon mechanical seal. Inducer to minimize required NPSH. Technical features • low noise emission (< 80 dB) • maximum allowable working pressure (MAWP) – 23/33 bar* • max head (50 Hz) – 420 m • max suction pressure required – 6 bar • inlet – DN 65, outlet – DN 40 Components: • FAS 96 6245 – PT100 temperature probe for leakage detection • FAS 96 6246 – PT100 temperature probe – for cool-down of pump • FAS 96 6247 – PT100 temperature probe – for over temperature detection • FAS 96 6240 – conical filter DN 65, assembled on the pump • FAS 96 6241 – suction flange DN 65 PN 40, assembled on the pump • FAS 96 6242 – discharge counter flange DN 40 PN 40 with hole G1 /8“×PT 100, assembled on the pump • FAS 96 6243 – flexible pipe2½“ DN 65 PN 25, L=300 mm (suction line), assembled on the pump • FAS 96 6244 – flexible pipe 1½“ DN 40 PN 40, L=300 mm (discharge line), assembled on the pump Technical features • low noise emission (< 80 dB) • transmission – Direct Coupling • max suction pressure required – 6 bar • inlet – DN 100, outlet – DN 80 Components: • FAS 96 6261 – conical filter DN 100, assembled on the pump • FAS 96 6262 – flange ASME B16,5 type SO-RF 4“ -300 LB A304, assembled on the pump • FAS 96 6263 – flange ASME B16,5 type SO-RF 3“ -300 LB A30, assembled on the pump • FAS 96 6264 – flexible pipe 4“ DN 100 PN 25, L=300 mm, assembled on the pump • FAS 96 6265 – flexible pipe 3“DN 80 PN 25, L=275 mm, assembled on the pump • FAS 96 6266 – PT 100 temperature probe for leakage detection • FAS 96 6267 – PT temperature probe for cool-down of pump LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .157 E FAS 98 8684 LNG coriolis mass flow meter Type F500 8F5B50, 2”/DN 50 Maximum flow – 20000 kg/h (by 2 bar operation pressure), display: mass flow unit – ”kg/h”, volume flow unit – ”l/h”, density unit – ”kg/l”, temperature unit – ”°C”. • approval; transmitter; sensor – EAC; Z1/21,Ex de; Z0/1,Z21,IIC/IIIC • D Power Supply – 24 V (DC) • MA Output; Input 1 – Modbus RS 485 • A Output; Input 2 – w/o; input 3 – w/o; input 4 – w/o; • F Display: operation – 4-line illum., touch control FAS 98 8688 LNG coriolis mass flow meter Type F500 8F5B80, 3”/DN 80 Maximum flow – 50000 kg/h (by 2 bar operation pressure), display: mass flow unit – ”kg/h”, volume flow unit – ”l/h”, density unit – ”kg/l”, temperature unit – ”°C”. • approval; transmitter; sensor – EAC; Z1/21,Ex de; Z0/1,Z21,IIC/IIIC • D Power Supply – 24 V (DC) • MA Output; Input 1 – Modbus RS 485 • A Output; Input 2 – w/o; input 3 – w/o; input 4 – w/o; • F Display: operation – 4-line illum., touch control Coriolis flow meters for LNG mobile (road tanker) and stationery (loading of refueling and regasiification stations) applications ENERGY • SAFETY • COMPETENCE 2019-2020 158 . • .LNG E Cryogenic equipment F LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .159 F ENERGY • SAFETY • COMPETENCE 2019-2020 160 . • .LNG F LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .161 F Cryogenic Cylinder Equipment RegO • T9450 Series & T9460 Series • ES8450, BK9450 & BK9470 • RegO® LOK™ • RG Series • ECL Series • CBH & CBC Series • LCR Series Relief Valves • 9400 Series • PRV 19430 & PRV 29430 • NR/AR/DR/DA Series • UA 3149A Series • Brass Pipe Caps • B-19434B Series & C-19434B Series Globe Valves • BB Series • 222 226LL 226GF 226ULL 226BLC Series • 202X 206LL 206GF 206ULL 206BLL Series • SK Series • 210 Series • 231 Series • 232 Series • CFM, AFM & SFM Series • 2550 Series • 2500 Series Cryogenic & Industrial Gas Products Gate Valves • 322 & 326 Series • 302, 306, 310 & 310X Series • 110 Series Check Valves • 8500 Series • 846M & 840 Series • 886 Series • CG Series • NG Series Regulators • 1780 Series • BR-1780 Series • 1682M Series & C-1682M Series • M2523HP Series • 4403 Series • 4286-10 Series & 4289-10 Series • Alarm Gauges 4285-9B • 4286/4289/4291 Series Master High Pressure Valves • HP9560 Series • 7160 Series Adapters, Nipples, Pipe & Miscelaneous • Pressure Gauges • CMM 250 Series and CFF 250 Series • Brass Adapters ENERGY • SAFETY • COMPETENCE 2019-2020 162 . • .LNG F Equipment for use with gases in medical, food and other cryogenic applications Series 2400 – safety valves made of stainless steel, angle-type with threaded connections. Safety valves are set and sealed at the factory and are oil- and grease-free as standard. • connections – ¼-1½” • temperatures – -200...+200°C • setting pressure – 0,2...70,0 bar Series 2580 – overflow valves made of gunmetal, angle-type with threaded connections. For use with gases in medical, food and other cryogenic applications. Overflow valves of this type are oil- and grease-free as standard. • connections – ¼-½” • temperatures – -200...+200°C • setting pressure – 0,2...70,0 bar Series 2700 – diverter ball valves made of stainless steel with threaded connections. For use with gases in medical, food and other cryogenic applications. The ball-valves of this type are oil- and grease-free as standard. • connections – ¾-1¼” • temperatures – -200...+200°C • setting pressure – PN 63 Series 2480 – safety valves made of gunmetal, angle-type with threaded connections. Safety valves are set and sealed at the factory and are oil- and grease-free as standard. • connections – ¼-1” • temperatures – -200...+200°C • setting pressure – 0,2...70,0 bar Series 2780 – diverter ball valves made of gunmetal with threaded connections. For use with gases in medical, food and other cryogenic applications. The ball-valves of this type are oil- and grease-free as standard. • connections – ¾-1¼” • temperatures – -200...+200°C • setting pressure – PN 63 LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .163 F F The LNG all-in-one pipe consists our of three endless corrugates pipes: • LNG-supply • LNG/BOG-return • the third one also is a corrugated pipe which creates a secondary containment for the LNG and contains the • optimized PUR-foam insulation or • vacuum superinsulation LNG pipe – vacuum or PUR insulated All-in-one PUR – with PUR-foam insulation All-in-one VIP – the vacuum insulated pipe FAS No. Type DN 1 DN 2 PN Ø, “/mm Volume DN 1 l/m Volume DN 2 l/m Weight kg/m Bending radius , “/мм All-in-one PUR – with PUR-foam insulation 48 640 AiO PUR 39-64/148 1¼“ DN 32 1¼“ DN 32 25 6,0/153 1,35 2,13 8,5 47/1200 48 641 AiO PUR 48-83/171 1½“ DN 40 2“ DN 50 25 6,9/175 2,00 4,00 12,5 30/1500 All-in-one PUR – the Vacuum insulated 48 642 AiO PUR 39-64/115 1¼“ DN 32 1¼“ DN 32 25 4,6/117 1,35 2,13 7,5 39/1000 48 643 AiO PUR 48-83/152 1½“ DN 40 2“ DN 50 25 6,0/152 2,00 4,00 11,0 47/1200 FAS 61 6508 CryoMac® 3 50 GPM LNG Filling Nozzle • flow capacity – 50 GPM • JIC male SAE 37° flare fitting for 1” tube – stand • handle ISO 12617 road vehicles certified • EX II 2 G c IIA T3 Certified according to ISO 12617 approved product as specified by ISO 16924 Natural gas fueling stations – LNG stations for fueling vehicles ENERGY • SAFETY • COMPETENCE 2019-2020 164 . • .LNG F Equipment for cryogenic applications Type 01 641 Technical Data Nominal Size DN 10 15 15 20 25 32 40 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 70 85 85 100 115 115 130 130 155 205 245 280 400 Height, mm 270/370 370 420 Type 01 643 Technical Data Nominal Size DN 10 15 15 20 25 32 40 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 70 85 85 100 115 115 130 130 155 205 245 280 400 Height, mm 370 370 370 370 375 405 420 420 425 510 575 635 685 Globe valve HEROSE Type 01 641 for cryogenic applications Type – 01641 stainless steel, size – ½- 6” (DN 10- DN 150), pressure range – Cryogenic-Globe and Globe/Check Valves – PN 50 (DN 150=PN 40), “Fire safe” type test approval acc. to EN ISO 10497 • approved for air gases, vapors and cryogenic liquefied gases incl. LNG • working temperature: -196...+120°C • stainless steel body and live loaded gland packing • cleaned and degreased for oxygen service • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 Actuated globe valve HEROSE Type 01 643 for cryogenic applications Type – 01 643 stainless steel, size – ½-6” (DN 10- DN 150), pressure range: Cryogenic-Globe Valves with pneumatic actuator, PN 50 (DN 150=PN 40), “Fire safe” type test approval acc. to EN ISO 10497 • stainless steel body and top work • actuator – air opens, spring closes and live loaded gland packing • cleaned and degreased for oxygen service • the actuator is not cleaned and degreased for oxygen • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .165 F Type 01645 Technical Data Nominal Size DN 10 10 15 20 25 40 40 50 Threated Size inch ¼ 3 /8 ½ ¾ 1 1¼ 1½ 2 Face-to face dimension, mm Overall Length 70 70 85 100 115 130 130 155 Height, mm 270/370 Type 01 643 Technical Data Nominal Size DN 200 Face-to face dimension, mm Overall length 560 Height, mm 785 Globe valve HEROSE Type 01641 for cryogenic applications In flow direction, the valve with the nominal size DN 200 is conform to tightness class L1 up to 9 bar maximum differential pressure acc. to DIN 12567 for LNG use. This standard can also be used for the tightness class of other cryogenic gases. Type – 01641 stainless steel, size – DN 200, stainless steel body and live loaded gland packing, pressure range and size: Cryogenic Globe Valves, DN 200, PN 25. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • working temperature – -196...+120°C • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 Actuated Globe Valve HEROSE Type 01643 In flow direction, the valve with the nominal size DN 200 is conform to tightness class L1 up to 18 bar maximum differential pressure acc. to DIN 12567 for LNG use. This standard can also be used for the tightness class of other cryogenic gases. Available accessories/options (on request only): • Solenoid valve • Limit switch • Electropneumatic positioner etc. • Welded stainless steel stubs acc. to ISO 1127 or ASTM A312 • Actuator ”cleaned and degreased for oxygen service” • Valve with check or control disc (tapered design) Type – 01 643 stainless steel, size – DN 200, stainless steel body and top work. Actuator – air opens, spring closes or contrary ”live loaded” gland packing, pressure range: cryogenic-globe valves with pneumatic actuator – PN 25. “Fire safe” type test approval acc. to EN ISO 10497. Applications: approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • working temperature – -196...+120°C • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 Globe valve HEROSE Type 01 645 for cryogenic applications Type – 01 645 stainless steel, size – ½-2” (DN 10-DN 50), pressure range: cryogenicglobe and globe/check valves – PN 50. “Fire safe” type test approval acc. to EN ISO 10497 • approved for air gases, vapors and cryogenic liquefied gases incl. LNG • working temperature – -196...+120°C • stainless steel body and live loaded gland packing • cleaned and degreased for oxygen service • female thread connection (G) acc. to ISO 228/1 • female thread connection NPT acc. to ANSI B 1.20.1 ENERGY • SAFETY • COMPETENCE 2019-2020 166 . • .LNG F Type 01653 Technical Data Nominal Size DN 15 25 40 40 50 65 80 Threated Size inch ½ 1 1½ 1½ 2 2½ 3 Face-to face dimension, mm Overall Length 85 115 130 130 155 205 245 Height, mm 395 444 441 441 420 470 500 Type 01655 Technical Data Nominal Size DN 10 10 15 20 25 40 40 50 Threated Size GW ¼” 3 /8” ½” ¾” 1” 1¼” 1½” 2” Face-to face dimension, mm Overall Length 70 70 85 100 115 130 130 155 Height, mm 140 140 140 140 140 175 175 175 Type 01651 Technical Data Nominal Size DN 10 15 15 20 25 32 40 40 50 65 80 100 Face-to face dimension, mm Overall Length 70 85 85 100 115 115 130 130 155 205 245 280 Height, mm 140 140 140 140 140 170 175 175 200 260 310 350 Globe valve HEROSE Type 01 651 for cryogenic applications Type – 01 651 stainless steel, size – ½-4” (DN 10-DN 100), pressure range: cryogenic-globe and globe/check valves – PN 50. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapours and cryogenic liquefied gases incl. LNG. Working temperature – -196...+120°C, recommended working temperature – -60...+120°C. Actuated trailer valve HEROSE Type 01653 for cryogenic applications Type – 01653 stainless steel, size – ½-3” (DN 10- DN 80), pressure range: cryogenic-globe valves with pneumatic actuator – PN 50, “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. Stainless steel body and top work. Working temperature – -196°...+120°C, ambient temperature actuator – -50...+70°C. Air pressure for operation 6.0 bar g (maximum 10.0 bar g)/push-in connection 8 mm. • stainless steel body and top work • live loaded gland packing • cleaned and degreased for oxygen service • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • actuator – air opens, spring closes “live loaded” gland packing • “cleaned and degreased for oxygen service ” • the actuator is not cleaned and degreased for oxygen • maximum working pressure of the valve depending on nominal size • butt weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 • socket weld connection for stainless steel pipes acc. to ISO 1127 or ASTM A312 Globe valve HEROSE Type 01655 for cryogenic applications Type – 01655 stainless steel, size – ½-5” (DN 10-DN 50), pressure range: cryogenicglobe and globe/check valves – PN 50, “Fire safe” type test approval acc. to EN ISO 10497. Working temperature – -196...+120°C, recommended working temperature – -60...+120°C. Approved for air gases, vapours and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • live loaded gland packing • cleaned and degreased for oxygen service • female thread connection (G) acc. to ISO 228/1- • female thread connection NPT acc. to ANSI B 1.20.1 Available options (on request only): • female thread connection (R) acc. to ISO 7-Rc • valve with control disc (tapered design) LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .167 F Type 03641 Technical Data Nominal Size DN 15 20 25 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 140 150 160 200 230 290 310 350 550 Height, mm 270/370 Type 03641 ANSI Technical Data Nominal Size DN 15 20 25 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 140 150 160 200 230 290 310 350 597 Height, mm 270/370 Globe valve HEROSE Type 03641 / DIN Flange for cryogenic applications Type – 03641 stainless steel, size – DN 15-DN 150, pressure range: cryogenic-globe and globe/check valves – PN 40, “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • “live loaded” gland packing • “cleaned and degreased for oxygen service ” • working temperature – -196...+120°C • flanged connection acc. to DIN EN 1092-1 PN 40 Globe valve HEROSE Type 03641 / ANSI Flange for cryogenic applications Type – 03641 stainless steel, size – DN 15-DN 150, pressure range: cryogenic-globe and globe/check valves – class 300. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapours and cryogenic liquefied gases incl. LNG. Working temperature – -196...+120°C. • stainless steel body and top work • live loaded gland packing • cleaned and degreased for oxygen service • flanged connection acc. to ANSI B16.5 class 300 Available options (on request only): • extension H up to 900mm • valve with control disc (tapered design) ENERGY • SAFETY • COMPETENCE 2019-2020 168 . • .LNG F Type 03643 ANSI Technical Data Nominal Size DN 15 20 25 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 140 150 160 200 230 290 310 350 577 Height, mm 370 370 375 420 425 510 575 635 685 Type 03643 ANSI Technical Data Nominal Size DN 15 20 25 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 140 150 160 200 230 290 310 350 597 Height, mm 370 370 375 420 425 510 575 635 685 Actuated globe valve HEROSE Type 03643 / ANSI flange class 150 for cryogenic applications Type – 03643 stainless steel, size – DN 15-DN 150. Cryogenicglobe valves with pneumatic actuator – class 150. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • actuator – air opens, spring closes or contrary” live loaded ” gland packing • ”cleaned and degreased for oxygen service” – the actuator is not cleaned and degreased for oxygen • working temperature – -196...+120°C • flanged connection acc. to ANSI B16.5 class 150 Actuated globe valve HEROSE Type 03643 / ANSI Flange Class 300 for cryogenic applications Type – 03643 stainless steel, size – DN 15-DN 150. Cryogenicglobe valves with pneumatic actuator – class 150. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • actuator – air opens, spring closes or contrary” live loaded ” gland packing • ”cleaned and degreased for oxygen service” – the actuator is not cleaned and degreased for oxygen • working temperature – -196...+120°C • flanged connection acc. to ANSI B16.5 class 300 For both executions there are Available accessories: • solenoid valve • limit switch • electropneumatic positioner etc. Available options (on request only): • actuator – ”cleaned and degreased for oxygen service” • electric actuator • valve with check disc • valve with control disc (tapered design) LNG 2019-2020 ENERGY • SAFETY • COMPETENCE . • .169 F Type 03643 DIN fl. Technical Data Nominal size DN 15 20 25 40 50 65 80 100 150 Face-to-face dimension, mm Overall Length 140 150 160 200 230 290 310 350 550 Height, mm 370 370 375 420 425 510 575 635 685 Type 03643 DIN fl. Technical Data Nominal size DN 15 20 25 40 50 65 80 100 150 Face-to face dimension, mm Overall Length 140 150 160 200 230 295 310 350 510 Height, mm 370 370 375 420 425 510 575 635 685 Actuated Globe Valve HEROSE Type 03643 / DIN Flange for cryogenic applications Type – 03643 stainless steel, size – DN 15-DN 150, pressure range: cryogenic-globe valves with pneumatic actuator – PN 40, “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • actuator – air opens, spring closes or contrary ”live loaded” gland packing • ”cleaned and degreased for oxygen service” – the actuator is not cleaned and degreased for oxygen • working temperature – -196...+120°C • flanged connection acc. to DIN EN 1092-1 PN 40 Actuated globe valve HEROSE Type 03643 / DIN flange for cryogenic applications Type – 03643 stainless steel, size – DN 15-DN 150, pressure range: cryogenic-globe valves with pneumatic actuator – PN 16. “Fire safe” type test approval acc. to EN ISO 10497. Approved for air gases, vapors and cryogenic liquefied gases incl. LNG. • stainless steel body and top work • actuator – air opens, spring closes or contrary ”live loaded” gland packing • ”cleaned and degreased for oxygen service” – the actuator is not cleaned and degreased for oxygen • working temperature – -196...+120°C • flanged connection acc. to DIN EN 1092-1 PN 16 For both executions there are Available accessories: • solenoid valve • limit switch • electropneumatic positioner etc. Available options (on request only): • actuator – ”cleaned and degreased for oxygen service” • electric actuator • valve with check disc • valve with control disc (tapered design) ENERGY • SAFETY • COMPETENCE 2019-2020 170 . • .LNG F Type PY4 Extended Technical Data Nominal Size DN 8 12 15 20 25 32 40 50 Face-to face dimension, mm Overall Length 65 65 70 85 100 110 125 150 Height, mm 226,5 226,5 230 278,9 283 322,5 327,5 345,8 Type PY4 Extended Technical Data Nominal Size DN 8 12 15 20 25 32 40 50 Face-to face dimension, mm Overall Length 65 65 70 85 100 110 125 150 Height, mm 70 70 73 91 95 111 116 137 Type PY4 non-extended Technical Data Nominal Size DN 65 80 100 150 Face-to face dimension, mm Overall Length 180 210 230 290 Height, mm 171 182 204 270 Ball valve Type PY4 extended for cryogenic applications Type – PY4 stainless steel / extended ball valve, size – ¼-2” (DN 8-DN 50), pressure range: • to DN 20 – 100 bar • to DN 32 – 70 bar • to DN 50 – 50 bar Temperature range – -196...+190°C. • stainless steel extended spindle • 3-piece cryogenic ball valve complete with live loaded packing and pressure relief hole. • fire-safe • cleaned & packed for oxygen service Ball valve Type PY4 non-extended for cryogenic applications Type – PY4 stainless steel / non-extended ball valve, size – 2½-6” (DN 65-DN 150), pressure range: • to DN 80 – 40 bar • to DN 150 (reduced bore only)– 25 bar Temperature range – -50...+190°C. • stainless steel non-extended spindle • 3-piece low temperature ball valve complete with live loaded packing and pressure relief hole • fire-safe, 3-way valves and end connection options • cleaned & packed for oxygen service Ball valve Type PY4 non-extended for cryogenic applications Type – PY4 stainless steel / non-extended ball valve, size – DN8-DN 50), pressure range: to DN 20 – 100 bar; to DN 32 – 70bar; to DN 50 – 50 bar. Temperature range – -50...+190°C. • stainless steel non-extended spindle • 3-piece low temperature ball valve complete with live loaded packing and pressure relief hole • fire-safe, 3-way valves and end connection options • cleaned & packed for oxygen service Options: full and reduced bore, actuation, double block & bleed, fire-safe, 3-way valves and end connection options. Available connections: butt weld, socket weld, BSP/NPT threated. Into aircraft pressure refuelling couplings. Hydrant dispenser intake couplings. Inline pressure control/deadman valves. Tank bottom loading automatic high level cut off systems. Fuel hydrant pit valves. Pressure contol venturis. Unisex couplings. Digital pressure control systems. Full range of spare parts in stock. EI 1581 approved filter water separator vessels and replacement elements. EI 1590 approved microfilter vessels and replacement elements. EI 1583 approved water absorbing monitor vessels and replacement elements. Clay filter vessels and replacement cartridges. Industrial filter elements, band filters and precoat filters. Electronic water monitoring systems. Electronic filter differential pressure monitoring and control systems. Minimonitor and multi minimonitor ‘Millipore’ type contamination test kits and consumables including colormetric and gravimetric capsules. Direct reading filter differential pressure gauges. Fuel sampling probes and test fittings. Spring rewind bonding reels. Tank floating suction assemblies. Aqua Glo kits for the measurement of water concentration in hydrocarbon fuels. Complete range of fuel quality checking equipment Aircraft refuelling hoses to ISO 1825. Trigger nozzles for aviation refuelling and general petroleum duty. Flexible pipework connections. Hose end fittings and reducers. Copper braid cored clear PVC and high visibility green covered bonding cable. Steel cored clear PVC covered bonding cable. Heavy duty bonding clips, a wide range is held in stock. Tanker earthing sockets/suzie cables and bolt on earth pins. Static earth system continuity testers. Hand rewind lanyard reels for aviation refuelling vehicles. Steel cored red PVC covered aviation lanyard cable with or without fitted ends and carbine hook. Hand rewind electric deadman reels for aviation refuelling vehicles. Deadman handswitches, coiled twin core orange suzie cables and associated weatherproof plugs and sockets. Battery isolation switches, boost plugs and sockets for aviation refuelling vehicles. ATEX approved lamps with clear or coloured lenses for use on aviation refuelling vehicles. Automatic air eliminators. Aviation hydrant dispenser air\fuel sense hose. Hosereels, hand and power rewind. Fuel sample collection and recovery tanks and complete systems, mobile or fixed. Pit flags and flag poles for the clear identification of aviation fuel hydrant pits during refuelling operations. High visibility hydrant dispenser intake hose sleeves. Jet A1 and Avgas colour coded hose sleeves to identify the fuel grade during overwing aviation refuelling. Sandwich pattern non return valves in Aluminium, Carbon Steel, Ductile Iron and Stainless Steel. Sandwich pattern butterfly valves, in Ductile Iron, Steel, Stainless Steel and Aluminium. Basket strainers in Carbon Steel and Stainless Steel. Composite wire reinforced hoses for tanker and rail car loading and offloading. Sight flow indicators for use in pipework systems. Available in Carbon Steel or Stainless Steel, flanged or threaded. Kamlok couplings in Aluminium, Stainless Steel and Brass. Threaded BSP hose couplings, dust\drip caps and connectors in Aluminium, Gunmetal and Stainless Steel. Pressure gauges manufactured from Stainless Steel, dry or Glycerine filled. De-aerator vessels and high capacity air release heads. Clear glass jars for fuel sampling. Wire carrying cages for glass jars. Stainless Steel buckets for fuel sampling, 8, 10, 12 or 15 litre capacity with bonding wire and clip. Brass heavy duty bonding clips/cables for sampling buckets and aviation refuelling nozzles. Hydrometers and thermometers for fuel density measurement and associated ASTM density correction tables. Hydrometer jars, glass and plastic. Water detector capsules and syringes. Water finding paste and paper for fuel systems. Fuel finding dip paste. Fuel sample retention and transport containers, 1 litre and 5 litre capacity, epoxy lined tinplate, available with associated transport cartons. IATA approved for transport of fuel samples by air. Fuel sample retention containers, epoxy lined tinplate, wire sealable for general fuel sample retention. Fuel contamination test kits and colormetric/gravimetric capsules and membranes. Tank dip tapes. Tank sample thief, Stainless Steel, 1 litre. Pressure test pumps and associated threaded adapters. Emcee fuel conductivity meters. Sealing wire, lead seals and sealing pliers. Stainless Steel locking wire. Nitrile gloves for fuel handling and equipment maintenance duties. Self adhesive decals and tapes for fuel grade marking on pipelines and tanks. Water Detector Capsules  Syringe, 5ml Nylon, reusable, for use with water detector capsules Water finding paper, 3/8" wide by 5.1/2" long Water finding paste, Kolor Kut  Single test membranes, Colourmetric contamination testing,     complete with support pads, GTP1983   Plastic monitors, non castellated, loaded with single membranes for Colourmetric testing and support pads, GTP1985     Plastic monitors, non castellated, loaded with Matched Weight membranes for Gravimetric testing and support pads, GTP1986    ASTM colour standards book Glass jar, square, 3.5 litre capacity, clear, wide neck, with screw cap and seal Special packing for glass jar Wire cage for 3.5 litre glass jar, plastic coated, with carrying     handle Stainless Steel bucket, 12 litre, with base ring, graduated, with bonding wire and clip Sample retention container, 1 litre, cylindrical, Tinplate epoxy lined internally, 2" Trisure closure, IATA approved Sample retention container, 5 litre, cylindrical, Tinplate epoxy lined internally, 2" Trisure closure, IATA approved Hydrometer, BS718 M50SP, 0.775 to 0.825, Jet A1, complete with C of C Hydrometer, BS718 M50SP, 0.700 to 0.750, Avgas, complete with C of C Hydrometer jar, glass, with pouring spout, 65mm diameter by 350mm long Thermometer ASTM12C/ IP64C, minus 20 to plus 102 degC, blue spirit filled  Bonding cable, Copper core, clear PVC cover Bonding cable, Copper core, high visibility green transparent PVC cover Bonding clip, Raco 70mm, Brass with insulated grips Electric deadman handswitch,  Deadman switch replacement Reed switch element Coiled suzie cable (approx. 14m fully extended) Niphan 2 pin plug (with strain relief gland fitted) Syringe, 5ml Nylon, reusable, for use with water detector capsules Syringe, 5ml PE, no internal seal, for use with water detector capsules Syringe, 5ml Nylon, reusable, reverse action (one handed operation) for use with water detector capsules Water finding paper, 3/8" wide by 5.1/2" long Water finding paste, Kolor Kut  Fuel finding ( Ullage ) paste, Kolor Kut  Fuelstat Resinae Plus Anti-Icing additive test kit Single test membranes, Colourmetric contamination testing, complete with support pads, GTP1983   Matched weight membrane pairs, Gravimetric contamination testing, GTP1984   Plastic monitors, non castellated, loaded with single membranes for Colourmetric testing and support pads, GTP1985     Plastic monitors, non castellated, loaded with matched weight      membranes for Gravimetric testing and support pads, GTP1986    ASTM colour standards book Tweezers, membrane handling, locking Contamination test kit, Mini Monitor, Gammon 10 litre sampling bottle. graduated, bonded Hydrometer, BS718 M50SP, 0.850 to 0.900, complete with C of C Hydrometer jar, glass, with pouring spout, 65mm diameter by 350mm long Hydrometer jar, plastic, with pouring spout, 55mm diameter by 345mm long Hydrometer jar, plastic, with overspill cup, 43mm diameter by 385mm long, GTP1073 Thermometer ASTM12C/ IP64C, minus 20 To plus 102 degC,   complete with C of C Thermometer ASTM12C/ IP64C, minus 20 to plus 102 degC, blue spirit filled (non hazardous), complete with C of C Thermometer IP53C, 0 to plus 80 degC, complete with C of C Thermometer IP53C, 0 to plus 80 degC, blue spirit filled (non      hazardous), complete with C of C Thermometer IP49C, minus 15 To plus 40 degC, complete with      C of C Thermometer IP49C, minus 15 to plus 40 degC, blue spirit filled (non hazardous), complete with C of C Thermometer IP39C minus 1 to plus 38 deg C, 0.1 deg C steps 450mm long, complete with C of C Thermometer ASTM63C, minus 8 to plus 32 deg C, 0.1 deg C steps 384mm long, complete with  C of C Density correction calculator disc, suitable for JET A1 and Avgas DIFFERENTIAL PRESSURE GAUGE GAMMON 0-30 PSI (0-2 BAR) - PUSH BUTTON IN FRONT 3/4'' GENUINE APOLLO SPRING RETURN BALL VALVE F/F BSP BOX OF 100 COLORIMETRIC MEMBRANES+100 SUPPORT PADS BOX OF 48 MATCHED WEIGHT MONITORS GAMMON GTP-1986 TEST KIT MICROBMONITOR 2 5 TEST KIT IN A BOX 15M ORANGE COILED CÂBLE FOR DEADMAN HANDLE SYRINGE HOLDER FOR SHELL WATER DETECTOR TEST DIGITAL CONDUCTIVITY METER EMCEE 1152 KOLOR KUT WATER FINDING PASTE - 85GR KOLOR KUT FUEL INDICATING PASTE - JAR OF 62GR CARTER U/W NOZZLE MAINTENANCE TOOL BOX 20L HYDROCARBON SPILL KIT (FUEL & OIL) PNEUMATIC PRESSURE GAUGE TEST KIT CPGKITP WATER DETECTING PASTE BATCH 12 TUBES OF 85GR
